Russell Hobbs RHTTFZ1 Manuale utente

Model number(s):

RHTTFZ1 (B)

For Customer Services & Spare Parts please call 0345 2088750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

IMPORTANT:

RETAIN FOR FUTURE REFERENCE

Table Top Freezer

Instruction Manual

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Contents

Safety Instructions ………………………………………. 3-4

Electrical Safety ………………………………………. 4

Transportation & Handling ………………………………………. 5

Installing & Switch on your Appliance ………………………………………. 5

Before Switching On ………………………………………. 6

Product Overview ………………………………………. 7

Unit & Spare Parts ………………………………………. 7

Usage ………………………………………. 8

Temperature Selection ………………………………………. 8

Door Reversal ………………………………………. 9-10

Energy Saving Advice ………………………………………. 11

Freezer Storage Advice ………………………………………. 11

Power Failure ………………………………………. 12

Maintenance & Cleaning ………………………………………. 13-14

Internal Cleaning ………………………………………. 13

External Cleaning ………………………………………. 13

When not in Use ………………………………………. 13

Defrosting ………………………………………. 14

Trouble Shooting ………………………………………. 15-16

Connection to the Mains Supply ………………………………………. 17

Guarantee ………………………………………. 18

Technical Specification ………………………………………. 19

Safety Instructions

Important note: Please read this booklet before installing and switching on this

appliance. The manufacturer assumes no responsibility for incorrect installation

and usage as described in this booklet.

•This model uses natural refrigerant gas as part of its cooling system. This

gas is known as R600a (Isobutene) and is environmentally friendly but can be

combustible. Care should therefore be taken when handling or transporting the

product to ensure that none of the refrigeration circuit components are

damaged,

•Do not obstruct ventilation openings in the appliance

•The appliance must not be placed or rested on its power cord.

•Do not use mechanical devices or other artificial means to accelerate the

defrosting process, such as a heater or a hair dryer.

•Do not use electrical appliances in the refrigerator compartment of the

appliance.

•If this appliance is to replace an old refrigerator with a lock, the lock must be

removed as a safety measure before storing it or disposing of it. This is to

protect children from locking themselves inside the appliance.

•Old refrigerators and freezers contain insulation gases and refrigerant, they

must be disposed of properly. Contact your local authority or your dealer if

you have any questions. Please ensure that you do not damage the scrapunit

prior to being picked-up by the relevant waste disposal service.

•Do not use adaptors or extension leads when connecting the appliance to the

electrical power supply

•Do not plug in damaged plugs

•Do not pull, twist or damage the power cable.

•Do not plug-in or un-plug the appliance with wet hands to prevent electrical

shock.

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

•This appliance can be used by childrenaged from 8 years and above and

persons with reduced physical, sensoryor mental capabilitiesor lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children should not play with the appliance.

•This appliance is designed to be used by adults, do not allow childrento play

with the appliance or letthem hang over the door.

•Do not place explosive or flammable material in your appliance for your own

safety.

•Bottles containing a high percentage of alcohol must be sealedwell and placed

vertically in the refrigerator.

•Do not cover the body or the top of the appliance

•Fix down the accessories in the appliance during transportation to prevent

damage to them.

Electrical Safety

THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET

•Before switching on, make sure that the voltage of your electricity supply is the

same as that indicated on the rating plate. This product is designed to operate

on 220 –240V AC; 50Hz. Connection to any other power source may damage

the unit.

•This product may be fitted with a non re-wireable plug. If it is necessary to

change the fuse in the plug, the fuse cover must be refitted. If the fuse cover

becomes lost or damaged, the plug must not be used until a suitable

replacement is obtained.

•If the plug has to be changed because it is not suitable for your socket, or

becomes damaged in any way, it should be cut off and an appropriate plug

fitted following the wiring instructions below. This should be carried out by a

qualified electrician. The plug removed must be disposed of safely, as insertion

into a 13 Amp socket is likely to cause an electrical hazard.

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Transportation and Handling

For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold the

base and rear corners of cabinet. Lift the refrigerator carefully. Never use the door

handles for lifting. To move the refrigerator on a flat level surface, tilt it slightly

backwards and push backwards.

This unit is heavy and could cause injury –ensure there is adequate people

present to move the appliance.

Installing and Switching on Your Appliance

•Operating voltage for your appliance is 220-240Vat 50Hz.

•Before plugging in the power supply, ensure that the voltage on the rating label

corresponds to the working voltage of your electrical system in your home.

•Insert the plug into an efficient Ground (Earth) connection. If the socket hasno

Ground (Earth) contact or the plug does not match, we suggestyou call an authorised

electrician for assistance.

•Place your appliance in an area that is not exposed to direct sunlight.

•Your appliance should be placed at least 10cm away from stoves, ovens and other

heating cores.

•This appliance should never be used outdoors or left in the rain.

•When your appliance is placed nextto achest freezer or freezer, there should be at

least 10cms betweenthem to prevent humidityon the outer surface.

•Do not place anything on your appliance and install the unit in a suitable place so that

there is at least 30cm clearance above the appliance.

•If placing your appliance nextto kitchen cabinets, leave 5cm betweenthem.

•The rear of the appliance should be at least 6cm away from the back wall.

•The appliance must be used in the vertical position and on a flat surface.

•To level the appliance, use the adjustable feet on the appliance.

•Do not place your appliance on a carpeted surface as this will prevent adequate

ventilation.

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

•This appliance should only be placed on a flat, firm surface.

•Choose a dry and well-ventilated space.

•The appliance should be positioned so that the plug is easily accessible.

•If you need help or are unsure how to install the unit, please contact

Customer Services on 0345 208 8750 or visit www.productcare.co.uk.

Before Switching On

•Before using your appliance, add a teaspoon of bicarbonate of soda to warm

water and with a damp cloth wipe down all parts of the new appliance, then

repeat the process with a clean damp cloth and dry. (ensure the appliance is

not connected to the power when performing this task).

•Remove all transport tapes and foam protection pieces . Clean the interior with

a cloth dampened in lukewarm soap and water. Wipe with clean water and

wipe dry.

•There may be an odour when you first switch on the appliance, it will disappear

when the appliance starts to cool.

•When the appliance has been positioned, adjust the feet to ensure the unit is

stable. This is essential to ensure quiet running and proper door opening

/closing.

•Connect to the electrical socket but do not switch the power to the refrigerator

on for at least 3 hours. The coolant within the product needs time to settle after

it has been transported and put in to position, failure to do this will affect the

cooling performance of your appliance.

•Once the appliance has settled locate the thermostat knob on the product and

set to “NORMAL" position and switch on the power. The compressor will begin

to work. Close the door

•You may hear faint gurgling or bubbling sounds when the refrigerant is pumped

to the cooling system and through the coils or tubing at the rear of the

appliance. When the compressor is in operation you may hear a slight whirring

sound or pulsating noise. The thermostat controls the operation of the

compressor, and you may hear a slight click as it cycles in and out.

•To save energy, you should minimize the frequency and duration of door

opening.

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Unit Parts & Spare Parts

Before installation, check that all parts detailed in the product overview are

present. If any parts are missing, please contact the Product Care Customer Service

team on 0345 208 8750 or visit us at www.productcare.co.uk

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Product Overview

1. Cabinet

2. Wire Rack (Shelf)

3. Side

4. Adjustable feet

5. Door Hinge and Cover

6. Door

7. Door Gasket

8. Thermostat

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Allow to stand for a minimum of 3 hours before plugging in to the mains

The temperature in the appliance is controlled by the temperature control knob

located on the door frame. Rotate the control knob left or right to regulate the

temperature inside the freezer.

On the temperature control, MIN is the warmest setting and MAX is the coldest

setting. Under normal conditions the temperature control should be set at

NORMAL. Once the temperature control has been set, close the door and plug

in the appliance. We recommend that the door is not opened for a minimum of

4 hours to allow the appliance to reach the standard operating temperature.

Note: The standard operating temperature for the freezer compartment should

be between -18°C and -25°C.

Usage

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Door Reversal

You will need to tilt the freezer backward to access the lower hinge which holds

screws. Do not tilt more than 45 degrees and do not lay the freezer flat on its side.

Reversing the door:

1. Remove the top plastic hinge cover and set aside

2. Unscrew the two screws from the metal bracket and set aside.

3. Remove the three plastic inserts on the opposite side of the freezer and door.

Now fix the top door bracketto this side using the screws that was previously

removed. Replace the plastic hinge cover.

For Customer Services & Spare Parts please call 0345 208 8750

Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm

or visit us at www.productcare.co.uk

Door Reversal

4. Remove the adjustable footat the bottom of the freezer and set aside.

5. Unscrew the two screws holding the bottom door hinge and carefully moving it

across to the opposite side and fix into position. Care must be taken as the door will

be loose. Once this has been completed screw in the adjustable footto the

opposite side of the freezer.

Check that the door opens and shuts correctly after you have completed the door

reversal process.

The appliance must now be upright for a minimum of 3 hours before turning it on.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Russell Hobbs Congelatore

Russell Hobbs

Russell Hobbs RHUCFZ3 Manuale utente

Russell Hobbs

Russell Hobbs RHBI55FZ122 Manuale utente

Russell Hobbs

Russell Hobbs RH180FFFF55 Manuale utente

Russell Hobbs

Russell Hobbs RH47UCFF1 Manuale utente

Russell Hobbs

Russell Hobbs RHTTFZ1-EU Manuale utente

Russell Hobbs

Russell Hobbs RH55LF142 Manuale utente

Russell Hobbs

Russell Hobbs RHCF200 Manuale utente

Russell Hobbs

Russell Hobbs RHUCFF48(B) Manuale utente

Russell Hobbs

Russell Hobbs RH90FF176-WD Manuale utente

Russell Hobbs

Russell Hobbs RHUCFZ55-H Manuale utente

Russell Hobbs

Russell Hobbs RH55FZ142 Manuale utente

Russell Hobbs

Russell Hobbs RHCF418 Manuale utente

Russell Hobbs

Russell Hobbs RH99CF1001 Manuale utente

Russell Hobbs

Russell Hobbs RH55FF173B Manuale utente

Russell Hobbs

Russell Hobbs RH50FF144-MD Manuale utente

Russell Hobbs

Russell Hobbs RHCF103 Manuale utente

Russell Hobbs

Russell Hobbs RHCF300 Manuale utente

Russell Hobbs

Russell Hobbs RH55UCFZ6 Manuale utente

Russell Hobbs

Russell Hobbs RHBI7030FFE1 Manuale utente

Russell Hobbs

Russell Hobbs RHCF60 Manuale utente

Russell Hobbs

Russell Hobbs RHCF300-ML Manuale utente

Russell Hobbs

Russell Hobbs RH54FR3FZ146B Manuale utente

Russell Hobbs

Russell Hobbs RH115 Manuale utente

Russell Hobbs

Russell Hobbs RHCF99 Manuale utente

Manuali Congelatore popolari di altre marche

Siemens

Siemens GU..D SERIES Manuale utente

Omcan

Omcan FR-CN-0155 Manuale utente

Beko

Beko FNE290E24W Manuale utente

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuale utente

Electrolux

Electrolux EUF2042AOX Manuale utente

Dometic

Dometic CoolFreeze CFX95DZ Manuale utente

Electrolux

Electrolux EUF7000W1 Manuale utente

Polar Electro

Polar Electro CT330 Manuale utente

MPM

MPM MPM-145-SK Series Manuale utente

SAF

SAF PRESTOTIG 200AC/DC Guida rapida

Zanussi

Zanussi ZFT11407WA Manuale utente

AEG

AEG A63190GT Manuale utente

AEG

AEG A81000TNW0 Manuale utente

Matsui

Matsui MUC50S15E Manuale utente

NEFF

NEFF G4344X8 Manuale utente

Frigidaire

Frigidaire FV 1246 H Manuale utente

Frigidaire

Frigidaire FFC13K1AW Manuale utente

Electrolux

Electrolux EU 2400C Manuale utente
