Saeco HD8944/08 Manuale utente

QUICK START GUIDE - 簡要說明

Before using the machine, please read the instruction manual completely.

Carefully read the safety regulations provided in the instruction manual.

使用本機之前請閱讀使用說明。

請仔細閱讀手冊中的安全準則。

The manufacturer reserves the right to make changes without prior notice.

製造商有權對本產品做出任何更改，恕不另行通知。

Type HD8943 / HD8944 - Cod.15002478 - Rev.00 - del 15-03-10

Type HD8943 / HD8944

ACCESSORIES  配件

Intenza water lter

Intenza 濾水器

Cleaning brush

清潔刷

Descaling solution

除鈣劑

Brew group lubricant

沖煮系統潤滑劑

Power cord

電源線

Water hardness tester

水質硬度測試

Brew group cleaning tablets

沖煮系統清潔劑

Pre-ground coee measuring scoop

預磨咖啡粉量匙

Milk carafe

鮮奶壺

Door opening button

服務門開啟按鈕

Power cord connector

電源線插槽

Power button

電源開關

Water tank

水箱

Coee bean hopper with lid

咖啡豆槽及蓋

Grinder adjustment

研磨調節

Control panel

操作面板

Milk carafe connector

鮮奶壺連介面

Dispensing spout

咖啡龍頭

Drip tray + grill

滴水盤 + 格柵

Cup-warming surface

咖啡杯加熱板

Pre-ground bypass doser

預磨咖啡粉區

Service door

服務門

SBS dial

SBS

Hot water/steam wand

熱水/蒸汽沖煮管

Full drip tray indicator

滴水盤滿水裝置

Brew group

沖煮系統

Used grounds drawer

咖啡渣槽 Liquid recovery tray

液體回收盒

Insert the carafe inclined towards the front.The

carafe base should be positioned on the hole

(E) located on the drip tray. Insert the carafe

by turning it towards the base through a round

movement (as shown in the gure), until it is

hooked to the hole (E) located in the drip tray.

The carafe will be naturally back in place.

令鮮奶壺向前傾斜。鮮奶壺的底部應當插入滴水盤插槽

（E）中。

如圖所示，將鮮奶壺以旋轉方式向

下插入咖啡機，直到和滴水盤插槽

（E）扣住。鮮奶壺將自然入位。

Remove the covers. Fill the hopper with

coee beans, then close the covers.

取下蓋子。添加咖啡豆。然後

關閉蓋子。

Insert the plug into the socket located on the

back of the machine and insert the other end

into a power outlet with suitable current.

將電源插頭插入咖啡機和相應

插座中（參見標籤上的規格資

料）。

Adjust the dispensing spout and place a cup

beneath it.

調節咖啡龍頭並放上杯子。

Set the power button to the“I”position. Press

the stand-by button to start the machine.

將電源開關置於 | 位置。按下

該按鈕啓動咖啡機。

(Only for beverages with milk) Rotate the

handle clockwise and press on the disen-

gage buttons to allow the lid removal.

（僅限含有鮮奶的飲品）順時

針方向旋轉手柄，按下解鎖按

鈕取出手柄。

Fill the carafe with cold milk. Fill milk to above

the“min”line, but do not exceed the“max”

level indicated on the carafe. Replace the lid.

加入鮮奶，超過最小刻度缐，

但是不要超出最大刻度缐。蓋

上鮮奶壺蓋。

STARTING THE MACHINE  啟動咖啡機

Before turning on the machine, make sure that the power button is set to“0”.

啟動咖啡機前，請確保電源開關位於 0 位。

Remove the covers. Remove the water tank.

打開蓋子。取出水箱。

Fill the tank with fresh drinking water. Do not ex-

ceed the“max”level indicated on the water tank.

Place the water tank back into the machine.

加入純淨飲用水（不要超出最大

水量線）。放好水箱和蓋子。

不使用鮮奶壺時或用完後，必須

將其放進冰箱保存。

When the carafe with milk is not going to

be used, or after using it, store it in the

refrigerator.

2 31

7 8

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

ESPRESSO

STOP

COFFEE

ESPRESSO

STOP

COFFEE

ESPRESSO

STOP

COFFEE

ESPRESSO

STOP

COFFEE

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

Press the espresso or long espresso button.

Press once for 1 cup and twice for 2 cups.

If you wish to save the quantity of espresso

being brewed, press and hold for 3 seconds.

按下與所需飲品相關聯的按

鈕。按 1 下為 1 杯，按 2

下為 2 杯。

如果需要記憶份量信息，請按

下並保持 3 秒鐘。

The machine starts grinding the selected

coee quantity.

開始研磨咖啡，準備沖煮。

Coee brewing can be stopped at any time by

pressing the“STOP COFFEE”button.

Press“STOP COFFEE”to save the quantity.

可以隨時按下 STOP COFFEE 按

鈕來終止該項操作。

按下 STOP COFFEE 按鈕，記憶

咖啡份量。

Cappuccino button

卡布奇諾按鈕

Cleaning cycle button

清潔程式按鈕

Stand-by button

待機按鈕

咖啡粉量選擇按鈕

Opti-dose button Function buttons

功能按鈕

Hot water button

熱水按鈕

Espresso button

義式濃縮咖啡按鈕

拿鐵瑪奇朵按鈕

Latte macchiato button

義式淡咖啡按鈕

Long espresso button

Cafe Latte button

拿鐵咖啡按鈕

Special beverage button

特別飲品按鈕

CONTROL PANEL  操作面板

The control panel has been designed to allow an ergonomic use of all machine functions.

操作面板符合人體工程學設計，可以控制本咖啡機所有功能。

ESPRESSO / LONG ESPRESSO  義式濃縮咖啡/義式淡咖啡

Place a cup under the dispensing spout

and rotate the upper part of the carafe

clockwise.

放進鮮奶壺並按順時針方向旋

轉手柄。

Press the button corresponding to the

desired beverage.

按下與所需飲品相對應的按

鈕。

The machine starts brewing. It grinds the

coee and heats up for milk dispensing.

咖啡機開始準備工作。

The machine allows dispensing an ad-

ditional quantity of milk if the“More Milk”

button is pressed.

按下該按鈕後，咖啡機可以沖

煮額外量的鮮奶。

The machine brews the coee.

咖啡機沖煮咖啡。

At the end remove the cup with the bever-

age and replace the upper part of the milk

carafe.The rinse cycle begins.

(see the manual on page 17).

結束後，將手柄放在待機位置

上，開始沖洗程式。

（參閱手冊第 17 頁）

CAPPUCCINO / LATTE MACCHIATO / CAFE LATTE  卡布奇諾/拿鐵瑪奇朵/拿鐵咖啡

WARNING: DISPENSING MAY BE PRECEDED BY SHORT SPURTS OF HOT WATER AND SCALDING IS POSSIBLE.

開始和結束沖煮時，可能會產生蒸汽和鮮奶液滴，有燙傷的危險。

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

CAPPUCCINO

FAST

MILK HEATING UP…

ECO MODE ON STOP

MILK

CAPPUCCINO

FAST

MILK HEATING UP…

ECO MODE ON STOP

MILK

CAPPUCCINO

STOP

MILK

CAPPUCCINO

STOP

MILK

CAPPUCCINO

STOP

COFFEE

CAPPUCCINO

STOP

COFFEE

Place a container beneath the hot water/

steam wand.

在熱水沖煮管下方放置一個器

皿。

Press the hot water button to dispense the

programmed quantity.

Press the special beverage to access the

menu.

按下該按鈕進入選項。

按下該按鈕沖煮預設份量的熱

水。

When hot water dispensing is complete,

remove the container. Repeat the process to

dispense another dose.

Place a container beneath the hot water/

steam wand.

在蒸汽沖煮管下方放置一個器

皿。

Press the special beverage button to dispense

steam. Repeat the process to dispense

another dose.

按下該按鈕沖煮蒸汽。完成後重

複該操作，再沖煮一份蒸汽。

完成後取出器皿。重複操作再沖

煮一杯熱水。

HOT WATER DISPENSING  沖煮熱水

WARNING: DISPENSING MAY BE PRECEDED BY SHORT SPURTS OF HOT WATER AND SCALDING IS POSSIBLE.

開始沖煮時，熱水可能濺出，存在燙傷危險

STEAM DISPENSING  沖煮蒸汽

WARNING: DISPENSING MAY BE PRECEDED BY SHORT SPURTS OF HOT WATER AND SCALDING IS POSSIBLE.

開始沖煮時，熱水可能濺出，存在燙傷危險。

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

ESPRESSO

MACCHIATO

STEAM

AMERICAN

COFFEE

HOT

MILK

ESPRESSO

MACCHIATO

STEAM

AMERICAN

COFFEE

HOT

MILK

按下該按鈕沖煮蒸汽。完成後重

複該操作，再沖煮一份蒸汽。

MAINTENANCE DURING OPERATION  運行過程中的維護

Operations to be performed with machine turned on when the following messages are displayed:“Empty coee grounds drawer”and/or“Empty drip tray”.

出現 EMPTY COFFEE GROUNDS DRAWER 和 EMPTY DRIP TRAY 訊息時，在開機狀態下執行下列操作。

Press the button and open the service door.

按下該按鈕，打開服務門。

Remove the drip tray and used grounds

drawer.

取出滴水盤及咖啡渣槽。

Empty the used grounds drawer and the drip

tray, wash and replace back into machine.

倒空咖啡渣槽及滴水盤；用純淨

水沖洗並放回原位。

GENERAL MACHINE CLEANING  咖啡機常規清潔

The cleaning procedure described below must be carried out at least once a week.

下列清潔操作每週至少執行一次。

Take out the water tank and wash it with

fresh water.

取出水箱，用乾淨的水清洗。

Turn o the machine and unplug it.

關閉咖啡機並拔掉電源插頭。

Remove the drip tray.

取出滴水盤。

Remove the dispensing spout and wash it

under running water.

取出咖啡龍頭，用乾淨的水清

洗。

Clean the pre-ground bypass doser with a

dry cloth.

使用乾布擦淨預磨咖啡粉區。

Clean the steam wand and the display with

a dry cloth.

使用濕布清潔蒸汽沖煮管和顯

示幕。

4 5 6

1 2 3

MACHINE WARNINGS  咖啡機警示訊息

Message How to Reset the Message 訊息如何令訊息復位

CLOSE HOPPER DOOR

Close the coee bean hopper lid.

CLOSE HOPPER DOOR

閉合咖啡豆槽蓋，以便沖煮飲

品。

ADD COFFEE

Fill the coee bean hopper with coee beans.

ADD COFFEE

將咖啡豆加入咖啡豆槽。

INSERT BREW GROUP

Insert the brew group back in place.

INSERT BREW GROUP

將沖煮系統插入專用位置。

INSERT GROUNDS DRAWER

Insert the used grounds drawer.

INSERT GROUNDS DRAWER

重新裝上咖啡渣槽。

EMPTY COFFEE GROUNDS DRAWER

Open the service door and empty the liquid

recovery tray, located under the brew group,

and the used grounds drawer.

The used grounds drawer must be emp-

tied only when the machine requires it

and with the machine on.

EMPTY COFFEE GROUNDS DRAWER

打開服務門蓋並清空沖煮系統下

的咖啡渣槽和沖煮系統。

注意事項：僅在咖啡機要求且

處於開機狀態時方可進行該項

操作。

CLOSE FRONT DOOR

Close the service door.

CLOSE FRONT DOOR

為了使咖啡機正常運轉，應當關

閉服務門。

REFILL WATER TANK

Remove the water tank and rell it with fresh

drinking water.

REFILL WATER TANK

取出水箱並裝滿純淨飲用水。

EMPTY DRIP TRAY

Open the service door and empty the liquid

tray, located under the brew group, and the

used grounds drawer.

EMPTY DRIP TRAY

打開服務門蓋並清空沖煮系統下

的咖啡渣槽和沖煮系統。

ROTATE THE MILK CARAFE DISPENSING

SPOUT INTO BREWING POSITION

ESC

A beverage with milk has been selected. Press

the“ESC”button to cancel the selection.

ROTATE THE MILK CARAFE DISPENSING

SPOUT INTO BREWING POSITION

ESC

選擇了一種含有鮮奶的飲品。按

ESC 按鈕取消選擇。

ROTATE THE MILK CARAFE DISPENSING

SPOUT INTO RINSING POSITION

ESC

The carafe rinse function has been selected.

Press the“ESC”button to cancel the selection.

ROTATE THE MILK CARAFE DISPENSING

SPOUT INTO RINSING POSITION

ESC

選擇了鮮奶壺沖洗功能。按 ESC

按鈕取消選擇。

PLACE MILK CARAFE

IN ITS HOUSING

ESC

An operation has been selected that requires

dispensing milk from the milk carafe. Press the

“ESC”button to cancel the selection.

PLACE MILK CARAFE

IN ITS HOUSING

ESC

選擇了需要鮮奶壺沖煮的操作。

按 ESC 按鈕取消選擇。

17/05/09

04:17 pm

USER

BENERAGE

SETTINGS

SELECTED

USER

Perform a descaling cycle on the machine.

Damages caused by failure to descale the

machine are not covered by warranty.

17/05/09

04:17 pm

USER

BENERAGE

SETTINGS

SELECTED

USER

咖啡機要求執行除鈣程式。因未

能定期除鈣而導致的損壞不屬於

保固範圍。

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

Flashing red light. Machine in Stand-by.

Press the “ ”button.

17/05/09

04:17 pm

USER

BEVERAGE

SETTINGS

SELECTED

USER

指示燈閃爍紅光。咖啡機處於待

機狀態。

按下按鈕。

RESTARTTO SOLVE

THE PROBLEM

(E xx)

An event has occurred which requires the

machine to restart.Take note of the code (E xx)

shown at the bottom.

Switch o the machine, wait 30 seconds and

then switch it on again. If the problem persists,

contact an authorized service center.

RESTARTTO SOLVE

THE PROBLEM

(E xx)

出現情況要求重新啓動咖啡機。

請記錄下方顯示的故障代碼（E

xx）。

關閉咖啡機，等待 30 秒鐘之後

重新開機。若出現相同問題，請

與服務中心聯繫。

Altri manuali per HD8944/08

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Saeco Macchina per il caffè

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

Saeco

Saeco Magic Cappuccino Plus Sin017XNI Manuale utente

Saeco

Saeco EXPRELIA HD8854 Manuale utente

Saeco

Saeco Spidem Villa 15000567 Manuale utente

Saeco

Saeco Odea Giro Plus Istruzioni operative

Saeco

Saeco INTELIA EVO HD8753 Manuale utente

Saeco

Saeco Phedra Evo D.A. 5P2015 Guida all'installazione

Saeco

Saeco GrabBaristo HD8964 Manuale utente

Saeco

Saeco Minuto Manuale utente

Saeco

Saeco RI8329/09 Manuale utente

Saeco

Saeco Incanto HD8917 Manuale utente

Saeco

Saeco PRIMEA LINE Manuale operativo

Saeco

Saeco Exprelia EVO Manuale utente

Saeco

Saeco Intuita HD8750 Manuale utente

Saeco

Saeco Gran Crema Sin010 Manuale utente

Saeco

Saeco SUP 021 Manuale utente

Saeco

Saeco HD8914 Manuale utente

Saeco

Saeco RI9822/43 Istruzioni operative

Saeco

Saeco PRIMEA TOUCH CAPPUCCINO Manuale utente

Saeco

Saeco Intelia Deluxe HD8902 Manuale utente

Saeco

Saeco XSMALL HD8644 Istruzioni per il montaggio

Saeco

Saeco XELSIS SM7686 Manuale utente

Saeco

Saeco Intelia Evo Bella HD8770 Manuale utente

Saeco

Saeco PRIMEA LINE 2007 Manuale operativo

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

DeLonghi

DeLonghi DC300 Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

DeLonghi

DeLonghi ECI341 Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente

LAVAZZA

LAVAZZA CLASSY PLUS Manuale utente
