Safe Fleet RVS-7065620 Manuale utente

Reverse With Condence ™ 1

Backup Camera System

For Dodge Promaster Vans

RVS-7065620

Instruction Manual

RVS Systems

Introduction...............................03

SafetyInformation..........................04-06

Before Beginning Installation. . . . . . . . . . . . . . . . . . . . . . . 07

InstallationGuide.......................... 08-09

DistanceGridLines...........................10

InstallationandWire.........................11-13

MonitorSpecications..........................14

Camera.............................15-16

Troubleshooting.............................17

Warranty&Disclaimer........................ 18-19

TABLE OF CONTENTS

Reverse With Condence ™ 3

NOTE! Please read all of the installation instructions

carefully before installing the product. Improper

installation will void manufacturer’s warranty.

Congratulations on purchasing a RearView Backup

Camera System!

With this manual you will be able to properly install and

operate the unit.

The Backup Camera System is intended to be installed as a

supplement aid to your standard rear view mirror that already exists

in your vehicle. The Backup Camera System should not be used as a

substitute for the standard rear view mirror or for any other mirror

that exists in your vehicle.

In some jurisdictions, it is unlawful for a person to drive a

motor vehicle equipped with aTV viewer or screen located forward of

the back of the driver’s seat or in any location that is visible, directly

or indirectly, to the driver while operating the vehicle.

INTRODUCTION

RVS Systems

Please read the entire manual and follow the instructions and

warnings carefully. Failure to do so can cause serious damage and/or

injury, including loss of life. Be sure to obey all applicable local

trac and motor vehicle regulations as it pertains to this product.

Improper installation will void manufacturer’s warranty.

• The Rear View Camera System is

designed to help the driver safe-

ly detect people and/or objects

helping to avoid damage or injury.

However, you the driver, must use it

properly. Use of this system is not a

substitute for safe, proper or legal

driving.

• Never back up while looking at the

monitor alone. You should always

check behind and around the vehi-

cle when backing up, in the same

way as you would if the vehicle did

not have the Rear View Camera

System.Ifyoubackupwhilelooking

only at the monitor, you may cause

damage or injury. Always back up

slowly.

•The Rear View Camera System is

not intended for use during exten-

sive back-up maneuvers or backing

into cross trac or pedestrian walk-

ways.

•Please, always remember, the area

displayed by the Rear View Camera

Systemis limited. Itdoes notdisplay

the entire panorama that is behind

you.

USAGE:

SAFETY INFORMATION

Reverse With Condence ™ 5

•Electric shock or product

malfunction may occur if this

product is installed

incorrectly.

• Use this product within

the voltage range specied. Failure

to do so can cause

electronic shock or product

malfunction.

• Take special care when

cleaning the monitor.

•Make sure to rmly ax the prod-

uct before use.

• If smoke or a burning smell

is detected, disconnect the

system immediately.

•Where the power cable may touch

a metal case, cover the cable with

friction tape. A short circuit

or disconnected wire may cause a

re.

• While installing the Rear View

System be careful with the wire

positioning in order to avoid wire

damage.

• The Rear View System should only

be used when the vehicle is in

reverse.

• Do not watch movies or

operate the monitor while driving;

as it may cause an

accident.

• Do not install the monitor

where it may obstruct drivers

view or obstruct an air bag

device.

• Dropping the unit may cause

possible mechanical failure.

INSTALLATION:

SAFETY INFORMATION

RVS Systems

IN NO EVENT SHALL SELLER OR MANUFACTURER BE

LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF

ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM

ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.

SAFETY INFORMATION

If you have questions about this product, contact:

RVS Systems

1797 Atlantic Avenue

Brooklyn, NY 11233

Tel: 1.888.881.2601

Reverse With Condence ™ 7

Before drilling please check that no cable or wiring is on the other side

of the wall. Please clamp all wires securely to reduce the possibility

of them being damaged while vehicle is in use. Keep all cables away

from hot or moving parts and electrical noisy components.

We recommend doing a benchmark test before installation

to insure that all components are working properly.

Step 1: Choose the monitor and camera locations.

Step 2: Install all cables in vehicle, when necessary a 0.8 (20mm)

hole should be drilled for passing camera cable through vehicles

walls. Install split grommets where applicable.

Step 3: Once all cables and wiring have been properly routed, perform

a system function test by temporarily connecting the system. If the

system seems to not be operating properly see troubleshooting (page

17).

BEFORE YOU BEGIN

RVS Systems

Replacement Monitor

The mirror monitor replaces the existing van mirror. Carefully remove

the mirror o the“pin”. Slide the replacement mirror on to the pin and

secure it with the screw provided (already in the screw hole). Dier-

ent cars have dierent brackets. Depending on your vehicle make and

manufacturer. There are many methods to remove the original rear-

view mirror, however, please don’t force the mirror o the bracket.

The manufacturer will not be responsible for damage caused to your

car by incorrect mirror installation. Figure 1.1

Camera & Cable

Be sure to position the cable properly. The aviation camera cable uses

aircraft grade connectors which means the camera cable can be ex-

posed to all weather elements. Do not run the cable over sharp edges,

do not kink the cable and keep away from HOT and rotating parts.

Fasten all cables and secure all excess cable. Camera mounts under

third brake light for factory like install. Figure 1.2

INSTALLATION GUIDE

Reverse With Condence ™ 9

Wiring

Connect the camera to the power harness, then plug into the AV2 in-

put. Connect the RED 12V power wire to an ignition power source and

the BLACK 12V ground wire to a chassis ground. The GREEN wire is the

REVERSE trigger wire. Connect this wire to the vehicle’s backup light

circuit to activate the rear-view image whenever the vehicle shifts into

reverse. To connect a second camera, connect it to AV1 input. It can be

turned on by pressing the power button on the monitor. Figure 2.1,

Figure 2.2

Precautions for use of Mirror Monitor

I. The Mirror Monitor is made of glass. Do not subject it to a

mechanical shock by dropping it from a high place, etc.

II. Do not apply excessive force to the monitor surface or the

adjoining areas since this may cause the color tone to vary.

III. Clean with a soft dry cloth and/or Windex only.

IV. Do not attempt to disassemble the mirror monitor.

Safety

• Before drilling, be sure no cable or wire is on the other side.

• Feed as much cable as possible into vehicle & clamp securely.

This reduces the possibility of cable being hooked or snagged.

INSTALLATION GUIDE + TIPS

RVS Systems

Generally, to help drivers estimate the distance from obstacles, there are

three lines for reference- red, yellow, and green. Those three lines are dis-

played on the monitor when car is reversing. The green line is 3M from the

back of the car and the yellow line is 6.5 ft. The distant red line is 1M from

the backside of car while the close red line is 0.4M. Both reference lines on

the left and right should leave 0.2M space from the car.

Distance grid line accuracy may vary based on your camera angle. Adjust

the distance grid lines to t your application.

DISTANCE GRID LINES

Accuracy

Distance Grid Lines
