XE 0085-02
MAxx1 ADDENDUM
Installation guide
123
456
789
*
0#
S
SK-0000011322-02 - June 2004
manuel.book Page 1 Mercredi, 23. juin 2004 9:32 09
manuel.book Page 2 Mercredi, 23. juin 2004 9:32 09
SK-0000011322-02 SAGEM SA document. Reproduction and disclosure forbidden. 1
E
S
WELCOME TO SAGEM SA MORPHOACCESS™ MAXX1
VERSION
Congratulations for choosing the high end and secured
SAGEM SA MorphoAccess™ terminal. MorphoAccess™ provides
an innovative and effective solution for access control or time and
attendance applications using Fingerprint Verification or/and
Identification.
Among a range of alternative biometric techniques, the use of
finger imaging has significant advantages: each finger constitutes
an unalterable physical signature which develops before birth and
is preserved until death. Unlike DNA, a finger image is unique to
each individual - even identical twins.
Although MorphoAccess™ terminal has an important sturdiness,
in order to obtain the best results of the fingerprint recognition, you
had to take care of the optronic sensor.
manuel.book Page 1 Mercredi, 23. juin 2004 9:32 09
2SAGEM SA document. Reproduction and disclosure forbidden. SK-0000011322-02
E
S
SAFETY INSTRUCTIONS
The installation of this product should be made by a qualified
service Person and should conform to all local codes.
It is strongly recommended to use a class II power supply at 12 V
±5% and 2.5 A/min according with Safety Electrical Low Voltage
(SELV). The 12 V power supply cable length should not exceed
3 meters.
This product is intended to be installed in accordance with the
NEC Class 2 requirements; or supplied by a listed external Power
Unit marked Class 2, Limited Power source, or LPS and rated 12 V
DC, 2.5 A minimum.
In case of building to building connection it is recommended to
connect 0 V to ground. Ground cable must be connected with the
terminal block board fixation screw marked with universal ground
symbol.
Europe: SAGEM SA hereby declares that the SAGEM SA
MorphoAccess™ has been tested and found compliant with the
below listed standards as required by the EMC Directive 89/336/
EEC: EN55022 (1994)/EN55024 (1998) and by the low voltage
Directive 73/23/EEC amended by 93/68/EEC: EN60950 (2000).
USA: This equipment has been tested and found compliant with
Class B digital device requirements, pursuant to part 15 of the
FCC Rules. These requirements are designed to ensure
reasonable protection against harmful RF interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may interfere with radio communications. If this
equipment interferes with radio or television reception - which can
be determined by disconnecting and re-connecting the unit - the
user is encouraged to try to correct the interference by one or more
of the following measures:
−Reorient or relocate the receiving antenna.
−Increase the separation between the equipment and receiver.
−Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
−Consult the dealer or an experienced radio/TV technician for
help.
manuel.book Page 2 Mercredi, 23. juin 2004 9:32 09
SK-0000011322-02 SAGEM SA document. Reproduction and disclosure forbidden. 3
E
S
Replacement of the battery located on the motherboard
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Must be disposed of properly.
ATTENTION
Il y a danger d’explosion s’il y a remplacement
incorrect de la batterie.
Remplacer uniquement avec une batterie du
même type ou d’un type équivalent recommandé
par le constructeur.
Éliminer de façon appropriée.
manuel.book Page 3 Mercredi, 23. juin 2004 9:32 09
4SAGEM SA document. Reproduction and disclosure forbidden. SK-0000011322-02
E
S
For systems placed in other building than supervisor one's, the
electrical security is guaranteed with an "earth connection" to the
terminal.
A cable terminal connected to "earth security reference" must be
tied to the fixation designed for (See bottom view).
F1
PS Relay Tamper-Switch
1
2
2
1
J8
WIEG IN
1
J5
1
WIEG OUT
J4
33
J9
J3
+
1
COM2
COM1LAN
1
1
J7J1
J110
Tamper
Switch
PSW1
PSW2 Earth
Security
Reference
Anti-theft
“Switch”
Cable
terminal
unavailable
manuel.book Page 4 Mercredi, 23. juin 2004 9:32 09
SK-0000011322-02 SAGEM SA document. Reproduction and disclosure forbidden. 5
E
S
GENERAL DESCRIPTIONS
Cable entry
Mounting keyhole
s
Metal chassis
Anti-theft switch
manuel.book Page 5 Mercredi, 23. juin 2004 9:32 09
6SAGEM SA document. Reproduction and disclosure forbidden. SK-0000011322-02
E
S
INSTALLATION PROCEDURE
Stage 1: Drilling the mounting holes for the metal chassis
assembly
Tamper switch and anti-theft function provide a part of the security
of the terminal.
Anti-theft function is realized with a block placed on the wall, and
hiding the opto light.
In order to satisfy the security profile of the MorphoAccess™
Maxx1 as a high level of security, a connection may be done
towards the supervisor system.
Only the connected mode provides the high security level
required for this terminal.
Standalone mode cannot be so secured.
a) Drill the 2 holes for the screws for the mounting keyholes so
that the cable entry is in a suitable position for your cabling,
using the dimensional drawing above (See the section Drilling
Te m p l at e ) .
b) Drill the hole for the third screw in the center of the slot so that
it is possible to correct the position later, if necessary.
c) The mounting screws must be 5 mm diameter maximum.
d) Drill the hole for the srew, for the anti-theft block, as mentioned
on the view.
Stage 2: Mounting the metal chassis assembly
a) Disconnect the ribbon cable between the motherboard and the
terminal block board so that the assembly shown above can be
detached from the rest of MorphoAccess™.
b) Pass the connecting cables through the cable entry.
c) Position the chassis assembly against the wall using the two
screws in the mounting keyholes.
d) Hold the chassis in place with a screw through the mounting
slot.
e) Adjust the position, and fix in place by tightening all three
screws.
manuel.book Page 6 Mercredi, 23. juin 2004 9:32 09
SK-0000011322-02 SAGEM SA document. Reproduction and disclosure forbidden. 7
E
S
f) Adjust the anti-theft block into the hole designed for, and fix in
place the screw.
Check that nothing is interfering with the switch and opto
component.
g) Connect cables to terminal blocks (see the detailed instructions
in the following sections).
Stage 3: Connecting the chassis assembly to the cover
assembly
No add-on.
manuel.book Page 7 Mercredi, 23. juin 2004 9:32 09
8SAGEM SA document. Reproduction and disclosure forbidden. SK-0000011322-02
E
S
Stage 4: Closing MorphoAccess™
1
2
Lip Catch for the cover
assembly lip Chassis assembly
Cover assembly
Fit the two secured assembly
screws. Use the special screw
driver provided with the MAxx1 terminals.
Assembled
MorphoAccessTM
When the ribbon cable has been
connected between the two
assemblies (see stage 3), the
cover assembly is fitted to the
chassis assembly.
1- The lip on the cover slides
behind the chassis, to fit over the
catch shown on the diagram above.
2- The cover is fitted onto the
chassis by rotating it.
