Sailor SP3110 Manuale utente
SAILOR, THE GREAT EUROPEAN
SAILOR SP3110
THE PORTABLE VHF
TRANSCEIVER
FOR GMDSS
PWR
CH
VOL
SQ
A B 16
VOL
LO
SP3110
28442A
MONITOR
LAMP
PTT
CALL
Monitor switch for listening-in on
a channel, irrespective of the
squelch level setting.
Backlight switch, used to turn-on
the illumination of the display
and/or the keyboard, depending
on programming.
PTT switch.
(Call switch, for selective calling.)
Microphone
SP3110
SP3110
Display read-out
SQ
HI VOL
DUP
TX
LO
1 2 3 4 5
101112 9 7 6
28443
8
1. HIgh - LOw, TX power level indicators.
2. TX on indicator, (carrier is transmitted).
3. DUPlex channel indicator.
4. Volume indicator, on in high level AF
power mode.
5. VOLume sign, the two digits below indicate
the actual volume setting.
6. 8 alpha-numeric digits, used for channel
number indication etc.
7. Squelch sign, the two digits above indicate the
actual squelch setting.
8. Battery low indicator.
9. Keyboard lock indicator.
10.Individual call alarm indicator.*
11.AF-mute indicator.*
12.Tone system ON indicator.*
* Functional only in conjunction with
optional tone module for selective calling.
SP3110
Contents
Page
Introduction 1
Emergency 3
Batteries 4
Operator's guide 5
Quick channel programming 7
Additional features 8
Installation 10
Rechargeable batteries 11
Mounting of clip 13
Removing clip 14
1 SP3110
Introduction
SP3110, your new VHF-transceiver, is approved
to fulfil the GMDSS-requirements to portable
VHF-transceivers, and so it is a part of the
required safety equipment to be used in an
emergency situation.
However, the best way to guarantee functional-
ity in an emergency, is to use the equipment in
the daily work on-board, as a useful communica-
tion media.
This is possible, due to a unique concept, with
the PRIMARY EMERGENCY BATTERY, stored
for the emergency, and a SECONDARY RE-
CHARGEABLE BATTERY for daily use of your
new portable VHF-transceiver.
This concept secures at least 8hours operation
time, even at minus 20 C° at sea.
ECI has developed the first portable VHF-
transceiver to be used as you normally use a
telephone.
This feature gives you a much better com-
munication quality in noisy surroundings.
SP3110 2
Furthermore, you have all the international
simplex channels, quick selection of distress ch.
16 and two additional user programmable
channels, and a lot of other useful features.
3 SP3110
Emergency
Procedure for SP3110.
If an emergency situation forces you to leave the
ship, do as follows:
1. Remove the top-seal of the orange emer-
gency battery package.
2. Insert the battery package into the handheld
transceiver unit.
3. Push the - button,
until the radio turns on, indicated by channel
read-out in the display.
4. Push the
16
- button to ensure that the
channel for distress traffic is active.
NOTE !
Due to battery storage effects, the turn-on time
may be extended compared to normal condi-
tions. If Battery seal is broken for test, fill in label
on battery.
SP3110 4
Batteries
This unit has been delivered with two types of
battery packages :
* An orange PRIMARY EMERGENCY BAT-
TERY package, to be used in an emergency,
as indicated by its colour.
* A black SECONDARY RE-CHARGEABLE
BATTERY for daily use of the equipment.
Replacement of battery package :
* Press the two stainless steel locks on each
side of the battery package with your thumb
and indexfinger and pull out the battery.
28468
* Insert the new battery package into the
bottom of the transceiver and press it
upwards until it snaps in with a “click”.
5 SP3110
Operator's guide
Press.....
Until unit turns ON/OFF, indicated by the
display readout.
To lock keyboard, indicated by
To unlock keyboard, disappears.
To select loudspeaker operation, .
To select telephone-mode operation.
To turn on keyboard beep-function.
To turn off keyboard beep-function.
To change setting of a selected function,
Default: Volume level function.
PWR
To select Tx power level function.
CH
To select Channel selection function.
SQ
To select Squelch level function.
VOL
To select Volume level function.
