Sakar 76379 Manuale utente

Users Manual

76379 Owner’s Manual

Windows and the Windows logo are registered trademarks of Microsoft Corporation.

All other trademarks are the property of their respective.

Introduction

Thank you for your purchase of our digital camera. This unit

can be used as a web cam (camera to use to chat over the

Internet), or it can also be used as a low-resolution digital

camera. This camera is equipped with an 8MB built-in

SDRAM, therefore you are able to use it to take up to 117

low-resolution photos under QVGA mode. Although the

clarity may not be flawless, the Digital Camera quality is the

best for its value.

Please note that in order to speak with friends and

colleagues over the Internet, you will need a PC headset

and microphone. Any standard PC headset will operate with

this digital camera and is available at your local computer

retailer.

Package Contents:

●Digital Camera ●Users Manual

●Software CD ●USB Connector Cable

To Know Digital Camera

A. Viewfinder

B. Indicator light

C. Flashing Selection Button

D. Start/Shutter Button

E. Hanging Strap Hole

F. LCD

G. Delete Button

H. Function Button

I. Battery Box

J. Flash Lamp

K. Lens

L. USB Port

Replacing the Batteries

When the batteries power is low, press the shutter

button and you will hear a beeping sound. If you want to

replace the batteries, you must use two AA batteries.

Please be sure to download all photos, which are stored

inside of the camera, as they will be lost when the batteries

are removed.

1. Open the battery compartment.

2. Load the batteries correctly (please check that the

batteries are placed inside with the proper polarity).

3. Close the battery box cover.

zIf you do not use this camera for a long period, please

remove take out of the batteries to avoid the

discharging or corrosion of the batteries.

zPlease don’t put batteries into a fire to avoid explosion,

subsequent injury to you or others around you.

Do not mix old and new batteries. Do not mix alkaline, standard

(carbon zinc), or rechargeable (nickel cadmium) batteries.

Auto Energy-Save Mode

In order to conserve battery power, if the camera is not

used within 60 seconds after powering on, the camera will

automatically enter into energy saving mode. This will

prolong the life of the batteries. To wake up the camera

from the energy saving mode, simply press the Shutter

button.

IMPORTANT NOTE: TO ACHIEVE THE BEST CLARITY,

MAKE CERTAIN THAT THECAMERA IS

5 FEET WAY FROM THE SUBJECT

BEING PHOTOGRAPHED WHEN

TAKING PICTURES.

76379 Software Installation

IMPORTANT: Before attempting to install the software,

make sure that you do not have the camera or the USB

cable attached to your computer. This will affect the

install process and will cause your installation to fail.

Do not connect the cable to the computer until the

entire installation process of both PhoTags Express

and the Camera Driver has been completed. We

suggest you follow the step by step instructions that

will appear on your screen during the installation

process.

SECTION ONE- Software & Camera Driver Installation

1. Insert the CD into your CD-Rom drive. Make sure

that your camera is not connected to the

computer.

2. You will be prompted to select an installation

language. Select the language you want.

3. On the “Install your camera software” screen,

select your camera model from the drop down list

and click the “Install” button to install PhoTags

Express followed by the installation of PhoTags

WebCam Express and your camera driver.

4. On the “PhoTags Express" screen, click the

“Next” button.

5. Please

review the license terms and click the “Agree”

button to continue.

6. Let the “PhoTags Express” installer create the

folder where the program will be installed to, and

then click “Install”

7. Click “Finish” to let the “PhoTags Express”

installer finish the installation program.

8. This will automatically launch the Install shield for

the camera driver. Click “Next” to continue.

9. Once the program has finished installing you will

have to restart your computer.

10. Congratulations!! You have successfully installed

the “PhoTags Express” software, the “PhoTags

WebCam Express” and the Camera driver.

SECTION TWO – TAKING PHOTOS

Please be sure that the batteries are functional prior to you

using this camera to take photos. If you want to take photos:

1. Hold down the Shutter Button for 5 seconds to

wake up the Camera, the LCD at the back of the

camera will be active. The LCD display will show the

status of resolution and then show the number of

photos taken. Then you may download them into your

PC.

2. Find the image you would like to shoot and center the

image in the viewfinder.

3. Hold the camera steadily, and press the shutter button

to take photos (For optimum quality, please make

sure the subject is 5 feet from the camera lens.)

4. When you hear the buzzer beep once, (which

indicates that you have just taken a photo), you can

continue taking other photos;

5. If you press the Shutter button once and the buzzer

rings out twice, then you cannot take any photos at

this moment. Please download the photos into the PC

first. Alternatively, you can use the “Delete Button” to

select “ ” (to delete all of the photos in the cameras

memory) or “ ” (to delete the last photo taken) in

order to continue using the camera. When you see

either the ” or symbols, press the shutter button and

you will delete your photo or photos.

Note: When taking photos, the louder sound indicates a

successful photo taken; a lower sound beep indicates

the last photo taken was not taken properly.

Wake Up the Camera

If the digital camera is in the energy saving mode, please

hold down the Shutter Button for 5 seconds to wake up the

camera from energy saving mode in order to use the

camera.

Functions Shown on the LCD Display

Note: After turning the power on, the LCD display will show

the resolution setting (Hi / Lo) for 3 seconds, then

show how many photos you have already taken.

In order to conserve battery power (you will change the

batteries less often) the camera has a built-in power saving

mode. When the camera is in power saving mode, hold

down the shutter button for 5 seconds to “wake up” the

camera from the power saving mode.

Turn the camera on

Load the batteries and hold down the Start/Shutter Button

for 5 seconds or connect to computer via USB cable directly,

and the camera will start to work.

Using the Flash

This camera also has a built in flash. You’ll get best results

if you use the flash indoors only. There is strong possibility

that if used outdoors, the light will overexpose the photo.

1. Push the “Flashing Selection Button” to the side close

to “ ”, the flash lamp will start to be recharged and

after a few seconds the indicator will light up.

2. once the indicator light turns red, you can take pictures

with a flash by pressing the shutter button.

3. Now you can take digital photos in low light, and at

night. It should be noted, however, that if there is an

ample of light, your camera will not use a flash when

you take a picture, as it is not necessary.

Delete single photos

1. Press the Delete Button to select “ ” icon shown on the

LCD display.

2. Press the Shutter Button once within 5 seconds to

delete the last photo taken.

Delete all photos

1. Press the Delete Button to select “ ” icon shown on the

LCD display.

2. Press the Shutter Button once within 5 seconds to

delete all photos, which stored inside the camera.

Note: If you don’t press the shutter button within 5 seconds,

the operation for deleting photos will be not executed,

and the camera will return to the normal working status.

Photo Resolution Selection

Note: The resolution status will always show on the LCD

display in small character.

1. Press “Function button” to select “Hi” or “Lo”

character show on LCD.

2. “Hi” means VGA mode 640*480 pixels; “Lo” means

QVGA mode 320*240 pixels.

3. You can press the “Function Button” to switch

between the “Hi” and “Lo” mode. The Hi mode will

allow you to take 32 photos and the Lo mode will

allow you to take 117photos.
