Samson GRAPHITE M32 Manuale utente
Quick Start Guide
2
Copyright 2015
V2
Samson Technologies
45 Gilpin Avenue
Hauppauge, New York 11788-8816
Phone: 1-800-3-SAMSON (1-800-372-6766)
Fax: 631-784-2201
www.samsontech.com
Apple, Mac, Mac OS, and iPad are trademarks of Apple Inc., registered in the U.S. and other
countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used
under license.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance instructions in the literature accompanying the appli-
ance.
ATTENTION
RISQUE D’ÉLECTROCUTION !
NE PAS OUVRIR !
WARNING
TO PREVENT FIRE OR SHOCK HAZARD. DO NOT USE THIS PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE
BLADE PLUG TO WIDE SLOT AND FULLY INSERT.
Graphite M32 · USB Keyboard Controller
3
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
CAUTION
Any changes or modifications to the construction of this device which are not expressly approved
by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
If you want to dispose this product, do not mix it with general household waste. There
is a separate collection system for used electronic products in accordance with legisla-
tion that requires proper treatment, recovery and recycling.
Private household in the 28 member states of the EU, in Switzerland and Norway may return
their used electronic products free of charge to designated collection facilities or to a retailer (if
you purchase a similar new one).
For Countries not mentioned above, please contact your local authorities for a correct method of
disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, re-
covery and recycling and thus prevent potential negative effects on the environment and human
health.
4
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-
ratus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
11. Unplug the apparatus during lightning storms, or when unused for long
periods of time.
12. Refer all servicing to qualified personnel. Service is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
13. This appliance shall not be exposed to dripping or splashing water and that no object filled
with liquid such as vases shall be placed on the apparatus.
14. Caution-to prevent electrical shock, match wide blade plug wide slot fully insert.
15. Please keep a good ventilation environment around the entire unit.
16. Always unplug cables by gripping the plug firmly, not by pulling on the cable.
Important Safety Information
Graphite M32 · USB Keyboard Controller
5
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Introduction
Thank you for purchasing the Samson Graphite M32, compact USB keyboard controller! The
Graphite M32 gives you the performance and production control to easily integrate with Windows
or Mac digital production workstations. The keyboard can also be powered directly by an Apple
iPad (using the Apple iPad Camera Connection Kit or Lightning to USB Camera Adapter, not
included), and can be used to control many iOS MIDI apps, like GarageBand. The Graphite M32
features a 32-key velocity-sensitive keyboard, an assignable Data fader, a Volume knob, pitch
bend and modulation strips. To take full advantage of the assignable functions, you will need to
download the free Graphite M32 editor from the Samson website (www.samsontech.com).
In these pages, you’ll find a detailed description of the features of the Graphite M32 keyboard
controller, as well as a guided tour of its control panel, and instructions for setup and use. You’ll
also find a warranty card enclosed. Please don’t forget to fill it out and mail it in so that you can
receive online technical support, and so that we can send you updated information about this
and other Samson products in the future.
We recommend you record your serial number in the space provided below, for future reference.
Serial number: ____________________________________________
Date of purchase: __________________________________________
With proper care and maintenance, your Graphite M32 will operate trouble-free for many years.
Should your keyboard ever require servicing, a Return Authorization (RA) number must be
obtained before shipping your unit to Samson. Without this number, the unit will not be accepted.
Please call Samson at 1-800-3SAMSON (1-800-372-6766) for an RA number prior to shipping
your unit. Please retain the original packing materials and, if possible, return the unit in its
original carton. If your Graphite M32 was purchased outside of the United States, contact your
local distributor for warranty details and service information.
6
Features
The Samson Graphite M32 utilizes state-of-the-art technology and is engineered to the finest
detail. Here are some of its main features:
• 32-key velocity-sensitive keyboard
• Volume knob and Data slider
• Pitch Bend and Modulation ribbon strips
• CC Mode to set keys to send control change messages
• Program mode for sending program change information
• Compact design, perfect for live performance and studio applications
• Dedicated Octave up, Octave down, and Sustain buttons
• USB plug and play and bus powered
System Components
• Samson Graphite M32 USB Keyboard
• One (1) USB Cable
• Graphite M32 Owner’s Manual
Minimum System Requirements
Windows (PC)
• Windows XP/Vista/Win 7/Win 8
• 800MHz or higher, 256MB RAM or larger, USB port
Mac OS
• Mac OS X 10.4.9 or higher
• 733MHz or higher, 512MB RAM or larger, USB port
Apple iPad
• iOS v4.2 or higher
Graphite M32 · USB Keyboard Controller
7
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Quick Start
1. Connect the Graphite M32 to your computer or iPad* using the supplied USB cable. The
unit will receive power and transmit MIDI data via the USB connection.
If the Graphite M32 is connected to a non-powered USB hub, it may not receive enough
power to turn on. It is recommended that you connect the Graphite M32 directly to your
computer or to a powered USB hub.
2. Launch your DAW or virtual instrument software.
3. Set the Graphite M32 as the MIDI Input and MIDI Output device.
*To connect directly to an iPad, you will need to use the Apple iPad Camera Connection Kit or
Lightning to USB Camera Adapter (not included).
Computer
8
1. VOLUME Knob - This knob is preset from the factory to send MIDI volume (CC #7) mes-
sages. The VOLUME knob can be assigned to control different MIDI parameters using the
computer editor.
2. DATA Slider - This slider is preset from the factory to send MIDI pan (CC #10) messages.
The DATA slider can be assigned to control different MIDI parameters using the computer
editor.
3. OCTAVE +/– Buttons - Press the OCTAVE buttons to shift the octave of the keyboard up or
down a maximum of four octaves, to extend the range of the keyboard. Each time you press
the OCTAVE button, the range of the keyboard shifts up or down 12 notes. The buttons
blink progressively faster as the keyboard’s octave shifts in each direction. Press both but-
tons to set the keyboard to the default range.
4. SUSTAIN Button - Press this button to sustain (hold) currently held notes. Release the but-
ton to stop notes from being held.
5. CC Button - When pressed, the keyboard sends a control change message. The CC button
can be assigned using the Graphite M32 computer editor.
6. PROG Button - Press this button to send program change information via the Function keys
(0–9). Press the key labeled ENTER to send the desired program change message. When
the PROG button is pressed, the button lights red and the keys will not send note informa-
tion.
7. PITCH BEND Ribbon Strip - Slide your finger to raise or lower the pitch of notes played on the
keyboard.
8. MODULATION Ribbon Strip - Slide your finger to send modulation messages. Modulation is
usually used to add vibrato or other expressive effects to a sound being played.
Front Panel Controls and Functions
Graphite M32 · USB Keyboard Controller
9
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
9. Function Keys - In PROG mode, the last 11 keys of the keyboard are assigned to numerical
digits (0–9), and ENTER. To Send a program change message, press the PROG button,
then enter the program number by pressing the numbered keys. When the program number
is entered, press the ENTER key to transmit the program number information. The Graphite
M32 will exit the program mode, and the Function keys will transmit note information.
10. Keyboard - 32-note velocity sensitive keyboard.
11. USB Connection - Connect the included USB-mini cable from this port to the USB connec-
tion on a computer to provide power to the keyboard, as well as to send and receive MIDI
data.
Front Panel Controls and Functions
10
Editing Parameters
The Graphite M32 features controls which settings can be customized using the Graphite M32
computer editor, which can be found on the Samson website (www.samsontech.com). The fol-
lowing information outlines the available parameters for each control that can be adjusted.
Assignable Volume Knob
Control Change: Sets the control change number that the knob will transmit.
MIDI Channel: Sets the specific MIDI channel that the knob will use to transmit data.
Assignable Data Slider
Control Change: Sets the control change number that the slider will transmit.
MIDI Channel: Sets the specific MIDI channel that the encoder will use to transmit data.
Modulation Strip
Control Change: Sets the control change number that the Modulation strip will transmit.
MIDI Channel: Sets the specific MIDI channel that the Modulation strip will use to transmit data.
CC Button
Control Change: Sets the control change number that the CC keys will transmit.
MIDI Channel: Sets the specific MIDI channel that the CC keys will use to transmit data.
Value: Sets the control change value the button will transmit.
