Samsung EE-P5400 Manuale utente

USER MANUAL

EE-P5400

04/2021. Rev.1.0

www.samsung.com

Table of Contents

English

Français

Deutsch

Italiano

Svenska

Norsk

Suomi

Dansk

Português

English

Read me st

Please read this manualbefore using the device to ensure safe and properuse.

Images may di er in appearance from the actual product. Content is subjectto change

without prior no ce.

Before using the Mul portAdapter, make sure the mobile device you want to connect to

is compa ble with this Mul port Adapter.

Instruc onal icons

Warning: situa ons thatcould causeinjury to yourselfor others

Cau on: situa ons that could cause damage to your device or other equipment

No ce: notes, usage ps,or addi onalinforma on

Device layout

Mobile device

connector

Type-C port (External Power Jack)

USB-A port

HDMI port

RJ45 port (Ethernet)

English

USB-A port

Getting started

Package contents

Check the product box for the following items:

•

Device

•

Chargers are sold separately.

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

Appearances and speciﬁcations are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

sing

the

vic

Connec ng to a mobile device

Plug the mobile device connector into the mul purpose jack on the mobile device.

Connect a charger to the external power jack on the Mul portAdapterand use the ports

for each ports’designed func on.

Use only Samsung-approvedchargersthat support PowerDelivery feature (5V/3 A or

higher).

Do not use the Mul port Adapter by connec ng it to a computer using a data cable.

This may damage the connected computer.

English

sing

the

devic

•You can charge the mobile device using the charger (sold separately).

•If charger is not connected, there may be restrictions on the use of the product.

•The mobile device can be updated to the latest

• When the mobile device is connected tothe Adapter,the

increases.

•Charging the mobile device through the Adapter may take longer than

charging it directly.

•Tosave energy, unplug the charger when not in use. The charger does not have a

power switch, so you must unplug the charger from the electric socket when not in

use to avoid power.The charger should remain close to the electric socket

and easily accessible whilecharging.

•This is aType-C 5-in-1 hub with HDMI, 2 USB-A, RJ45 and Type-C femaleport,

(PC/Laptop/Mobilephone,etc.),especially for those host with a single Type-C

port. This hub can outputHDMI video with max 4k/60Hz and at the meanwhile

transferUSB 3.1 data with max 5Gbps. 2 USB-A ports allow you to connect 2 USB

devices simultaneously. RJ45 port allows the host to get access to Gigabit

Ethernet. Besides, the Type-C femalesupports PD 3.0 with max 100W PD Charging

or allows you to connect a USB Type-C device.

•Some features may not work properly if the charger is not connected while

•Be aware that if system is not when

your smartphone to external storage, such as HDD, it may requiredata to be

Samsung is not responsible for losses,including loss of data,

from the misuse of external storage devices.

English

sing

the

devic

Connec ng to an HD TV

Use the HDMI port on the Mul portAdapter to view videos and other media stored on the

mobile device via a compa ble HD TV.

Connect an HDMI cable (sold separately) to the HDMI port on the Mul portAdapterand

on the HDTV.

Connect the HDMI cable directly to the HD TV. If it is not directly connected,media

might not displayproperly.

For more details about connec ng the HDMI cable, see the TV’s user manual.

The TV screen instantly displays what is on the mobile device’s screen.

Do not unplug the charger while using the Mul port Adapter. The connected

devices may be reconnected.

If theTV has mul pleHDMI ports, use any ofthem. Ensure theTV se ngs havethe

right HDMI port selected. For more details, see the TV’s user manual.

Any incoming calls or messages freeze media output. Media restarts after

interrupted ac ons arecomplete.

Connec ng to a USB device

Connect a USB device such as a mouse or keyboard to the USB port on the Mul port Adapter.

Do not connect any other devices except a USB device (under 5 V/900 mA).This may

damage thedevice.

Do not unplug the charger while using the Mul port Adapter. Doing so may cause

data loss stored in the connected device.

English

Appendix

Troubleshoo ng

Before contac ng a Samsung Service Centre, please a empt the following solu ons. Some

situa ons may not apply to your device.

Your Mul port Adapter does not work

Disconnect the mobile device and the charger from your Mul port Adapter and try to

connectagain.

English

This manualis protected underinterna onalcopyright laws.

No part of thismanual may be reproduced,distributed, translated, or transmi ed in anyform

or by any means, electronic or mechanical,including photocopying, recording,or storing

in anyinformationstorage and retrievalsystem,withouttheprior wri en permissionof

SamsungElectronics.

Trademarks

SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.

All other trademarks and copyrights are the property of their respec ve owner
