OWNER’S

INSTRUCTIONS

AW0700A

AW0700B

AW0800A

AW1000A

AW1010A

AW1200A

AW1210A

AW1800A

WINDOW-TYPE

ROOM AIR CONDITIONER

( Cool )

DB68-01926A(2)

The following safety precautions must be taken when using your air conditioner.

Safety Precautions

1 The unit must be plugged into an independent circuit.

The air conditioner must be installed in accordance with national wiring regulations and

safety regulations wherever applicable.

2 Some installation locations may require installation of a short circuit breaker or grounding.

4 MAKE sure that the unit is correctly ventilated at all times :

do NOT place clothing or other materials over it.

5 NEVER spill any kind of liquid into the unit. Should this happen, unplug the unit and contact

an authorized service center.

6 Do NOT insert anything between the air outlet blades because the inner fan may be damaged

and could cause injury. Keep children away from the unit.

7 Do NOT place any obstacles in front of the unit.

8 Users of this product are cautioned not to attempt repairs.

Instead, they are requested to directly contact a designated service center or the outlet

at which the product was purchased.

9 Do not use an extension cord with this product.

10 The appliance is not intended for use by young children without supervision ;

young children should be supervised to ensure that they do not play with the appliance.

11 Never store or ship the air conditioner upside down or sideways to avoid damage to the

compressor.

3 If the supply cord is damaged, it must be replaced by a special cord or assembly available

from the manufacturer or its service agent.

The manufacturer does not assume responsibility for accidents or injury

caused by an incorrectly installed air conditioner. If you are unsure about

installation, contact an installation specialist.

CCAA

AAUU

UUTT

TTII

IIOO

OONN

E-2

Contents

◆PREPARING YOUR AIR CONDITIONER

■Safety Precautions ......................................................................................... 2

■Description of Eac Component .................................................................... 4

■Getting Started ............................................................................................... 5

◆OPERATING YOUR AIR CONDITIONER

■Cooling Your Room ........................................................................................ 6

■Ventilating Your Room .................................................................................... 7

■Switc ing t e Air Conditioner Off .................................................................... 8

■Selecting Energy Saving Mode ...................................................................... 8

■Adjusting t e Air Flow Direction Horizontally .................................................. 9

■Adjusting t e Air Flow Direction Vertically ...................................................... 9

◆RECOMMENDATIONS FOR USE

■Power Failure ................................................................................................. 10

■Temperature and Humidity Ranges ................................................................ 10

■Cleaning Your Air Conditioner ........................................................................ 11

■Solving Common Problems ............................................................................ 13

■Tec nical Specifications ................................................................................. 13

E-3

Air filter

(T e air filter is

located in inside.)

Air inlet (Inside)

Air outlet

T ermostat control

Operating mode

selection dial

Operating mode

selection dial

T ermostat control

Energy Saver switc

Swing switc

Outer air flow blades

(up/down orientation)

Air inlet (Outside)

Ventilation lever

Power plug (T e type of

power plug may

differ, depending on t e

local power supply.)

Inner air flow blades

(rig t/left orientation)

AW0700A/AW0700B/

AW0800A/AW1000A/

AW1200A/AW1800A

AW1010A/AW1210A

Description of Each Component

E-4

❄T e design and s ape are subject to

c ange, depending on t e model.

Gettin Started

You have just purchased a Samsung window-type room air conditioner which should be

installed following your Owner’s Instructions.

Your Owner's Instructions contain much valuable information on using your air conditioner.

Please take the time to read them as they will help you take full advantage of the unit's

features.

The illustrations in the step-by-step procedures use four different symbols:

E-5

PRESS PUSH IMPORTANT NOTE

☛

➢

Coolin Your Room

To control t e direction of t e air flow, refer to page 9.3

Turn t e operating mode selection dial and set it to “ HI COOL ” ,

“ MED COOL ” or “ LOW COOL ”.

Result: ◆ T e air conditioner starts up in cool mode.

➢

◆You can c ange modes at any time.

Turn t e THERMOSTAT control to t e desired position.

You must select the COOL mode if you wish to adjust the:

◆ Cooling temperature

◆ Fan speed when Cooling

Possible temperatures: Can be set between 64°F and 84°F.

Result: T e air conditioner starts cooling if t e room temperature is

ig er t an t e selected temperature.

E-6

81˚F ~ 73˚F

73˚F

~ 64˚F

84˚F

~ 81˚F

Ventilatin Your Room

If the air in your room is stale, you can ventilate the room using the

Fan feature.

Turn t e operating mode selection dial and set it to “HI FAN” or “LOW FAN”

position.

Result: ◆ T e air conditioner starts up in fan mode.

➢

◆ HI FAN : T e fan turns rapidly.

◆ LOW FAN : T e fan turns slowly.

◆ You can c ange modes at any time.

To control t e direction of t e air flow, refer to page 9.

If you wis to disc arge stale air, pus t e ventilation lever on t e front

of t e unit to t e rig t and open position ( ).

Result:

T e air inside t e room circulates and stale air is disc arged

outside.

Ot erwise, pus t e ventilation lever to t e left and closed position ( ).

Result:

T e air simply circulates inside t e room.

E-7

Switchin the Air Conditioner Off

To switc t e unit off, simply set t e operating mode selection dial to t e

OFF position.

Result: T e air conditioner stops operating.

You can switch the air conditioner off whenever you want.

If you wish to save energy when using the air conditioner,

select the energy saving mode by using the Energy Saver switch.

This feature is normally used when the room is unoccupied.

To turn off t e energy saving feature, set t e Energy Saver switc to t e

OFF position.

Result:

T e fan runs at all times, w ile t e compressor cycles on and off.

To select t e energy saving mode, set t e Energy Saver switc to t e ON

position.

Result:

T e fan and compressor cycle on and off simultaneously.

T is results in wider variations of room temperature and umidity.

If you want to run t e air conditioner in Fan mode, do not turn t e

Energy Saver switc on. T e Fan mode will not operate w en t e

Energy Saver switc is in t e ON position.

➢

Selectin Ener y Savin Mode (AW1010A/AW1210A)

E-8

To stop t e blades moving left and rig t, set t e Swing switc to t e

position.

Set t e Swing switc to t e position.

Result:

T e inner blades swing automatically left and rig t.

To stop t e blades in a specific position and orient t e air flow in t e

corresponding direction, simply set t e switc to t e position w en

t e blades are in t e desired position.

➢

Adjustin the Air Flow Direction Horizontally

Adjustin the Air Flow Direction Vertically

The inner air flow blades on the rigth side of the unit can be adjusted to direct the air

flow to the left, right or straight, thus increasing the efficiency of the air conditioner.

T e side by side air direction louvers are controlled by a lever.

T ey regulate air disc arge to t e left, rig t or straig t.

The outer air flow blades can be adjusted to control the vertical air

flow direction.

RECOMMENDATION When...

Cooling

Adjust the blades to face...

Upwards.

AW1010A/AW1210A

AW0700A/AW0700B/AW0800A/AW1000A/AW1200A/AW1800A

Adjust t e air flow blades to t e desired position, by pus ing t em

upwards or downwards.

◆

If you orient t e air flow blades downwards and t e unit operates

in Cool mode for long periods of time, dew may:

Form on t e surface of t e blades

Drip from t e blades

➢

E-9

Power Failure

Temperature and Humidity Ran es

If the air conditioner is used at... Then...

Hig er temperature T e automatic protection feature may be triggered

and t e air conditioner stopped.

Lower temperature A water leakage or some ot er malfunction may appen

if t e eat exc anger freezes.

Hig er umidity levels Water may condense on and drip from t e surface of t e unit

if it is used for long periods.

The following table indicates the temperature and humidity ranges

within which the air conditioner can be used.

Mode Indoor

Temperature Outdoor

Temperature Indoor Humidity

Cooling 70°F to 90°F approx. 70°F to 110°F approx. 80% or less

If a power failure occurs, t e air conditioner is switc ed off.

W en t e power comes back on, t e air conditioner starts up again

automatically.
