Samsung Multifunction Xpress C48 series Manuale utente

Samsung Multifunction Xpress

C48x series

C48xW series

C48xFN series

C48xFW series

BASIC

User’s Guide

BASIC

User’s Guide

This guide provides information concerning the installation, basic operation

and troubleshooting on windows.

ADVANCED

This guide provides information about the installation, advanced configuration, operation

and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 5

Features by model 7

Useful to know 12

About this user’s guide 13

Safety information 14

Machine overview 20

Control panel overview 24

Turning on the machine 28

Installing the driver locally 29

Reinstalling the driver 31

2. Menu Overview and Basic Setup

Menu overview 33

Machine’s basic settings 37

Media and tray 39

Basic printing 52

Basic copying 58

Basic scanning 62

Basic faxing 63

Using USB memory device 67

3. Maintenance

Ordering supplies and accessories 73

Available supplies 74

Available maintenance parts 75

Storing the toner cartridge 76

Redistributing toner 77

Replacing the toner cartridge 79

Replacing the imaging unit 81

Replacing the waste toner container 83

Monitoring the supplies life 85

Setting the toner low alert 86

Cleaning the machine 87

Tips for moving & storing your machine 91

4. Troubleshooting

Tips for avoiding paper jams 93

Clearing paper jams 94

Understanding the status LED 101

Understanding display messages 103

BASIC

5. Appendix

Specifications 111

Regulatory information 120

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 5

• Features by model 7

• Useful to know 12

• About this user’s guide 13

• Safety information 14

• Machine overview 20

• Control panel overview 24

• Turning on the machine 28

• Installing the driver locally 29

• Reinstalling the driver 31

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature (see "Eco

printing" on page 55).

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 215).

• To save paper, you can print on both sides of the paper (double-sided

printing) (Manual) (see "Using advanced print features" on page 215).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

• We recommend using recycled paper for saving energy.

Fast high resolution printing

• You can print in a full range of colors using cyan, magenta, yellow, and black.

• You can print with a resolution of up to 2,400 x 600 dpi effective output (600

x 600 x 2 bit).

• Fast, on-demand printing.

Convenience

• Simply touch your cell phone on the NFC tag on your printer and get the

print job done (see "Using the NFC feature" on page 173).

• You can print on the go from your smartphone or computer using Samsung

Cloud Print apps (see "Samsung Cloud Print" on page 184).

• You can print on the go from your smartphone or computer using Google

Cloud Print enabled apps (see "Google Cloud Print™" on page 187).

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 243).

• Samsung Easy Printer Manager and Printing Status is a program that

monitors and informs you of the machine’s status and allows you to

customize the machine’s settings (see "Using Samsung Easy Printer

Manager" on page 252 or "Using Samsung Printer Status" on page 255).

• Samsung Easy Document Creator is an application to help users compile

and share large documents or other scanned or faxed information digitally.

(see "Using Samsung Easy Document Creator" on page 254).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 113).

• Print watermark: You can customize your documents with words, such as

“CONFIDENTIAL” (see "Using advanced print features" on page 215).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 215).

• You can print in various operating systems (see "System requirements" on

page 116).

• Your machine is equipped with a USB interface and/or a network interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or

Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 155.

Features by model

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Supported, Blank: Not supported)

Operating System C48x series C48xW series C48xFN series C48xFW series

Windows ●●●●

Mac ●●●●

Linux ●●●●

Features by model

Software

You can install the printer driver and software when you insert the software CD into your CD-ROM drive.

For Windows, select the printer driver and software in the Select Software to Install window.

Software C48x series C48xW series C48xFN series C48xFW series

SPL printer driver ●●●●

PCL printer driver ●●●●

PS printer drivera●●●●

XPS printer drivera●●●●

Samsung Easy

Printer Manager

Scan to PC settings ●●●●

Fax to PC settings ● ●

Advanced Setting ●●●●

Samsung Easy Document Creator ●●●●

Samsung Easy Color Managera●●●●

Samsung Printer Status ●●●●

Samsung Printer Center ●●●●

SyncThru™ Web Service ●●●

Features by model

(●: Supported, Blank: Not supported)

Samsung Eco Driver Packb●●●●

Samsung Stylish Driver Packc●●●●

SyncThru™ Web Service ●●●●

Fax Samsung Network PC

Fax

● ●

Scan Twain scan driver ●●●●

WIA scan driver ●●●●

a. Download the software from the Samsung website and install it: (http://www.samsung.com > find your product > Support or Downloads). Before installing, check whether your

computer’s OS support the software.

To use the

Easy Eco Driver

features, the

Eco Driver Pack

must be installed.

c. The printer driver includes a user interface that is optimized for touchscreens. To use this UI, click Samsung Printer Center > Device Options and then select Stylish User Interface

(see "Using Samsung Printer Center" on page 246).

Software C48x series C48xW series C48xFN series C48xFW series

Features by model

Variety feature

(●: Supported, Blank: Not supported)

Features C48x series C48xW series C48xFN series C48xFW series

Hi-Speed USB 2.0 ●●●●

Network Interface Ethernet 10/100 Base TX

wired LAN

●●●

Network Interface 802.11b/g/n wireless LANa

a. Depending on your country, wireless LAN card may not be available. For some countries, only 802.11 b/g can be applied. Contact your local Samsung dealer or the retailer where you

bought your machine.

● ●

NFC (Near Field Communication) ● ●

Mopria™ ●●●

Samsung Cloud Print ●●●

Google Cloud Print™ ●●●

AirPrint ●●●

Eco printing (Control panel) ●●●

Duplex (2-sided) printing (Manual)b

b. Windows only.

●●●●

USB memory interface ●●●

Automatic Document Feeder (ADF) ● ●
