Samsung BD-F8500M Manuale utente

BD-F8500M

BD-F8900M

E-MANUAL

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/register

imagine the possibilities

BD-HDD Combo

user manual

For more information on how to use

e-Manual (P. 9)

Figures and illustrations in this User Manual are

provided for reference only and may differ from

actual product appearance. Product design and

specifications may be changed without notice.

Available Recording Time for

internal HDD

You can record digital broadcast on the internal HDD

as below.

Depending on the actual broadcast, available

recording time may be different with the table shown

below.

In On Screen Display, you can check available

recording time as shown in "high" case in the table

shown below.

Broadcast

Type

Estimated

Bitrate

Recording Time

BD-F8500M BD-F8900M

8 Mbps

(Normal) 124 Hours 257 Hours

20 Mbps (High) 49 Hours 102 Hours

5 Mbps

(Normal) 199 Hourss411 Hours

10 Mbps (High) 99 Hours 205 Hours

| NOTE |

Since the product's Timeshift and other implemented

functions require a certain amount of HDD space allocated

internally, the total size shown in the "Storage Device

Manager" of Settings menu may differ from the HDD's

capacity shown in the manual.

Region Code

Both products and discs are coded by region.

These regional codes must match for a disc to play.

If the codes do not match, the disc will not play.

The Region Number for this product is displayed

on the rear panel of the product.

Disc Type Region

Code Area

Blu-ray Disc

Europe, Greenland, French

territories, Middle East, Africa,

Australia and New Zealand.

DVD-VIDEO

Europe, Japan, the Middle East,

Egypt, Africa, Greenland

Mexico, South America,

Central America, Australia,

New Zealand, Pacific Islands,

Caribbean

Logos of Discs the product can

play

Blu-ray Disc 3D Blu-ray Disc

BD-Live DivX

PAL broadcast System in U.K.,

France, Germany, etc.

Accessories

Check for the supplied accessories below.

• RF cable for TV

• Remote Control

• Batteries for Remote Control(AAA Size)

• Power cord

• User Manual

| 2English

Front Panel or Rear Panel

DISC TRAY

REMOTE CONTROL SENSOR

STOP BUTTON

OPEN/CLOSE BUTTON

POWER BUTTON

USB HOST

PLAY/PAUSE BUTTON

ANT OUT (TO TV)

ANT IN

DIGITAL AUDIO OUT

HDMI OUT

LAN

USB HOST

English 3|

| NOTE |

\If the remote does not operate properly:

-Check the polarity +/– of the batteries.

-Check if the batteries are drained.

-Check if the remote sensor is blocked by obstacles.

-Check if there is any fluorescent lighting nearby.

| CAUTION |

\Dispose of batteries according to local environmental

regulations. Do not put them in the household trash.

Installing batteries

Remote Control

Tour of the Remote Control

Press this to operate a TV.

Turn the product on and off.

Press to use Tools menu.

Return to the previous menu.

Press numeric buttons to operate options

or to access channels directly.

Use to enter the disc menu.

Press this to operate the product.

Press to move to the home screen.

Use to select menu items and change

menu value.

Turn the TV on and off.

Press to exit the menu.

Alternately selects Teletext, Double or Mix.

Use to enter the popup menu/title menu.

After setup, allows you to set the input

source on your TV.

Press this to display the playback information

during playing a content in Disc/USB or

display the information of TV channel.

Press to search backwards or forwards.

Press to skip backwards or forwards.

Stops playback or recording.

TV volume adjustment.

Mutes the speakers of your TV.

Displays channel lists on the screen.

Press this to pause a playback or pause the

Timeshift function.

Press this to play or start the Timeshift

function.

Press this to select a TV channel.

Displays the EPG (Electronic Programme

Guide.)

These buttons are used both for menus on

the product and also several Blu-ray Disc

functions.

FUNCTION

TV SOURCE

POWER

RECEIVER

DIGITAL

SUBTITLE

INPUT

1 2 3

4 5 6

7 8 9

PANDORA SUBTITLE

SUBTITLE

INPUT

DISC MENU TITLE MENU

POPUP

A B C D

BD TV

TV MUTE

TV SOURCE

TTX/MIX

REC

REC PAUSEWEB BROWSER

CH LIST HOME GUIDE

SMART HUB SEARCH E-MANUAL

SOCIAL

Press to open and close the disc tray.

Press to use Apps.

Press to search contents.

Press this to user web browser function.

Press this when you want to use 3D function.

Press this to enter the e-manual.

Press to use social TV.

Press this to pause during recording.

Press this to make a recording.

| 4English

Setting the Remote Control to Operate

Your TV

To determine whether your television is

compatible, follow the instructions below.

1. Turn your television on.

2. Point the remote control towards the

television.

3. Press the TV button to set the TV mode.

4. Press and hold the TV POWER button, and

then enter the two-figure code in the table

to the right that corresponds to the brand of

your television by pressing the appropriate

number buttons.

If your television is compatible with the

remote control, it will Turn off.

The remote is now programmed to operate

the TV.

| NOTE |

\If several codes are listed for your television brand, try

each one in turn until you find one that works.

\If you replace the remote control’s batteries, you must set

the brand code again.

You can control certain functions of your TV with

this remote control.

Button Function

TV POWER Used to Turn the television on and off.

Number Used to input number directly.

TV VOL +/– Used to adjust the volume of the

television.

TV MUTE Used to toggle the sound on and off.

PROG (

)Used to select the desired channel.

TV SOURCE Used to select an external source

connected to the TV.

| NOTE |

\The functions listed above will not necessarily work on all

televisions. If you encounter problems, use the TV remote

control.

TV Control Codes

Brand Code

SAMSUNG

TV POWER+01, +02,

+03, +04, +05, +06,

+07, +08, +09

AIWA TV POWER+82

ANAM

TV POWER+10, +11,

+12, +13, +14, +15,

+16, +17, +18

BANG &

OLUFSEN TV POWER+57

BLAUPUNKT TV POWER+71

BRANDT TV POWER+73

BRIONVEGA TV POWER+57

CGE TV POWER+52

CONTINENTAL

EDISON TV POWER+75

DAEWOO

TV POWER+19, +20,

+23, +24, +25, +26,

+27, +28, +29, +30,

+31, +32, +33, +34

EMERSON TV POWER+64

FERGUSON TV POWER+73

FINLUX TV POWER+06,

+49, +57

FORMENTI TV POWER+57

FUJITSU TV POWER+84

GRADIENTE TV POWER+70

GRUNDIG TV POWER+49,

+52, +71

HITACHI TV POWER+60,

+72, +73, +75

IMPERIAL TV POWER+52

JVC TV POWER+61, +79

TV POWER+06, +19,

+20, +21, +22, +78

LOEWE TV POWER+06, +69

LOEWE OPTA TV POWER+06, +57

MAGNAVOX TV POWER+40

METZ TV POWER+57

MITSUBISHI TV POWER+06,

+48, +62, +65

MIVAR TV POWER+52, +77

NEC TV POWER+83

NEWSAN TV POWER+68

Brand Code

NOBLEX TV POWER+66

NOKIA TV POWER+74

NORDMENDE TV POWER+72,

+73, +75

PANASONIC TV POWER+53,

+54, +74, +75

PHILIPS TV POWER+06,

+55, +56, +57

PHONOLA TV POWER+06,

+56, +57

PIONEER TV POWER+58,

+59, +73, +74

RADIOLA TV POWER+06, +56

RADIOMARELLI TV POWER+57

RCA TV POWER+45, +46

REX TV POWER+74

SABA

TV POWER+57,

+72, +73, +74,

+75

SALORA TV POWER+74

SANYO

TV POWER+41,

+42, +43, +44,

+48

SCHNEIDER TV POWER+06

SELECO TV POWER+74

SHARP

TV POWER+36,

+37, +38, +39,

+48

SIEMENS TV POWER+71

SINGER TV POWER+57

SINUDYNE TV POWER+57

SONY TV POWER+35, +48

TELEAVA TV POWER+73

TELEFUNKEN TV POWER+67,

+73, +75, +76

THOMSON TV POWER+72,

+73, +75

THOMSON ASIA TV POWER+80, +81

TOSHIBA

TV POWER+47,

+48, +49, +50,

+51, +52

WEGA TV POWER+57

YOKO TV POWER+06

ZENITH TV POWER+63

English 5|

Connections

Connecting to a TV

Connecting to an Audio System

Method 1 Connecting to an HDMI supported AV receiver

• Use an HDMI cable (not included)

Method 2 Connecting to an AV receiver with Optical input

• Use an Optical Cable (not included)

• You will hear sound only through the front two speakers with Digital Output set to PCM.

Method 2

Method 1

Audio/Video

Audio

Video

To ANT INPUT

To TV

RF cable

To ANT IN

| 6English

Network Connection

You can connect your product to your network

router using one of the methods illustrated below.

Wired Network

| NOTE |

\Internet access to Samsung’s software update server

may not be allowed, depending on the router you use or

your ISP’s policy. For more information, contact your ISP

(Internet Service Provider).

\DSL users, please use a router to make a network

connection.

\To use the AllShare function with your PC, you must

connect your PC.

Wireless Network

| NOTE |

\If the wireless router supports DHCP, your product can

use a DHCP or static IP address to connect to the wireless

network.

\Set your wireless router to Infrastructure mode. Ad-hoc

mode is not supported.

\The product supports only the following wireless security

key protocols:

-WEP (OPEN/SHARED), WPA-PSK (TKIP/AES),

WPA2-PSK (TKIP/AES)

\Select a channel on the wireless router that is not

currently being used. If the channel set for the wireless

router is currently being used by another device nearby, it

will result in interference and communication failure.

\If you select the Pure High-throughput (Greenfield)

802.11n mode and set the Encryption type on your router

or router to WEP, TKIP or TKIP-AES (WPS2Mixed), the

product will not support a connection in compliance with

new Wi-Fi certification specifications.

\If your router supports WPS (Wi-Fi Protected Setup),

you can connect to the network via PBC (Push Button

Configuration) or PIN (Personal Identification Number).

WPS will automatically configure the SSID and WPA key

in either mode.

\Wireless LAN, by its nature, may cause interference,

depending on the operating conditions (router

performance, distance, obstacles, interference by other

radio devices, etc).

To use the AllShare function with your PC, you must connect

your PC.

Broadband

service

Wireless Router

Broadband

service

Broadband

service

Broadband modem

(with integrated router)

Broadband

modem

Router

English 7|

The Setup Procedure

• The Home screen will not appear if you do not

configure the initial settings.

• The OSD (On Screen Display) of this product may

change after you upgrade the software version.

• The access steps may differ depending on the menu

you selected.

Turn on your TV after connecting the player.

When you connect the player to a TV for the first

time, player turns on automatically and the Initial

Settings screen appears.

Start the Initial Settings Procedure.

| NOTE |

\When the product is connected to the TV for the first

time, the product turns on automatically. This is normal

operation.

\Password : Enter the desired 4-digit password using the

number buttons.

-Default password is set to 0000.

The Home Screen

Apps : Access various for pay or free-of-charge

applications.

Photos,Videos & Music : Play videos, photos

or music content from Disc, USB, PC or mobile

devices.

Settings : Set various functions to suit your

personal preferences.

Schedule Manager : Reserve the desired TV

programmes.

Navigation Help : Displays remote control buttons

available.

Web Browser : Access the internet using the Web

Browser application.

Recommended Apps : Access recommended

applications directly.

Movies & TV Shows : Download movies and TV

Shows from the Internet.

| NOTE |

\Depending on your country, this menu may not

be supported.

| NOTE |

\In the Home menu screen, it will switch to DTV Channel

mode after 3 minutes. When accessing the Settings

menu, the screen saver will be activated after 5 minutes.

Saves power by turning off product automatically when

no user operation is received for 4 hours. If "Auto Power

Off" menu is set to Off, the power will not turn off

automatically .

Movies & TV

Shows

Apps Photos,

Videos &

Music

Web Browser

Schedule Manager

Settings

Go to Apps and connect to the network

to get recommended apps.

Samsung Account

Screen Mirroring

| 8English

Accessing the Settings Screen

1. Select Settings on the Home screen, and

then press vbutton.

The Settings screen appears.

2. To access the Settings menus, sub-menus,

and options, please refer to the remote

control illustration and the setting table.

Buttons on the Remote Control used

for the Settings menu

1HOME Button : Press to move to the Home screen.

2RETURN Button : Return to the previous menu.

v(Enter) / DIRECTION Buttons :

• Press ▲▼◄► to move the cursor or select an

item.

• Press the vbutton to activate the currently

selected item or confirm a setting.

4EXIT Button : Press to exit the current menu.

How to use the e-Manual

E-MANUAL

You can find instructions about your

product's features in the e-Manual

in your product. To use, press the

E-MANUAL button on your remote

control.

Press the ▲▼◄► buttons to

highlight a category, and then press

the vbutton.

The E-manual Screen

1Home : Moves to the e-Manual home screen.

2Index : Displays the index screen.

3Search : Allows you to search for information by

entering words.

4Try Now : Allows you to go to corresponding OSD

menu.

| NOTE |

\This function is not enabled in some menus.

\If displayed E-manual page on your TV screen is

incomplete and partially hidden, set the Smart Hub

Screen Size to Size 1.

FUNCTION

TV SOURCE

POWER

RECEIVER

DIGITAL

SUBTITLE

INPUT

1 2 3

4 5 6

7 8 9

PANDORA SUBTITLE

SUBTITLE

INPUT

DISC MENU TITLE MENU

POPUP

A B C D

BD TV

TV MUTE

TV SOURCE

TTX/MIX

REC

REC PAUSEWEB BROWSER

CH LIST HOME GUIDE

SMART HUB SEARCH E-MANUAL

SOCIAL

2 4

Display

3D Settings

TV Aspect Ratio 16:9 Original

BD Wise Off

Resolution Auto

DTV Smart Resolution Off

Movie Frame (24fps) Auto

Smart Hub Screen Size Size 1

Display

Audio

Broadcasting

Network

Smart Features

System

Support

Settings

Connection

Setting

Display

Audio

Broadcasting

Networks

Smart Features

System

Support

Media Play

DTV Functions

Setting > System

System

Setup

Sets the channels and the time when setting up this product for the frist

time or when resetting it.

You can select the language you prefer for the On-screen menu, disc menu,

etc.

Language

Try Now

1 2

Home

Index

English 9|

Troubleshooting

If the BD-HDD combo seems to have a problem, first try this list of possible problems and solutions.

If none of these troubleshooting tips apply, visit “www.samsung.com”, then click on Support, or call

Samsung customer service centre.

PROBLEM SOLUTION

The screen is blocked • If the HDMI output is set to a resolution your TV cannot support (for

example, 1080p), you may not see a picture on your TV.

• Press the

(STOP) button (on top panel) for more than 5 seconds with

no disc inside on the home screen. All settings will revert to the factory

settings.

• When the factory default settings are restored, all stored user BD data is

deleted.

Forgot password • Press the

(STOP) button (on top panel) for more than 5 seconds with

no disc inside on the home screen. All settings including the PIN will revert

to the factory settings. Don’t use this unless absolutely necessary.

• When the factory default settings are restored, all stored user BD data is

deleted.

Repairs

If you contact us to repair your product, an administration fee may be charged if either:

1. An engineer is called out to your home at your request and there is no defect in the product.

2. You bring the unit to a repair centre and there is no defect in the product.

We will provide you with the amount of the administration fee before we make a home visit or begin any

work on your product.

We recommend you read this manually thoroughly, search for a solution on line at www.samsung.com,

or contact Samsung Customer Care before seeking to repair your product.

| 10 English

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Lettore Blu-ray

Samsung

Samsung BD-P4600 Manuale utente

Samsung

Samsung UBD-M9700 Istruzioni per l'installazione

Samsung

Samsung BD-P4600 Manuale utente

Samsung

Samsung BD-E6100 Manuale utente

Samsung

Samsung BD-D7500 Manuale utente

Samsung

Samsung BD-F6500 Manuale utente

Samsung

Samsung BD-D5700 Manuale utente

Samsung

Samsung BD-D5100 Manuale utente

Samsung

Samsung BD-C8800A Manuale utente

Samsung

Samsung BDP1600 - Blu-Ray Disc Player Manuale utente

Samsung

Samsung BD-C5900 Manuale utente

Samsung

Samsung BD-P3600A Manuale tecnico

Samsung

Samsung BD-1590C-XAC Manuale utente

Samsung

Samsung BD-H5500 Manuale utente

Samsung

Samsung BD-D6700 Manuale per l'uso e la cura

Samsung

Samsung BDP1600 - Blu-Ray Disc Player Manuale utente

Samsung

Samsung BD-J5700 Manuale utente

Samsung

Samsung BD-D7500 Manuale utente

Samsung

Samsung BD UP5000 - Blu-Ray Disc And HD DVD Player Manuale utente

Samsung

Samsung UBD-M8500 Manuale utente

Samsung

Samsung BD-C6500 Manuale utente

Samsung

Samsung BD-D5500 Manuale utente

Samsung

Samsung BD-D7000 Manuale tecnico

Samsung

Samsung BD-EM57 Manuale utente

Manuali Lettore Blu-ray popolari di altre marche

Philips

Philips BDP3380K Manuale utente

Sharp

Sharp BD-HP17U - AQUOS 1080p Blu-ray DiscTM Player Manuale utente

Pioneer

Pioneer BDP-140 Manuale di installazione e funzionamento

LG HLX50W Manuale utente

Sony

Sony BDP-S300 - Blu-Ray Disc Player Manuale utente

Marantz

Marantz UD9004 Manuale utente

Panasonic

Panasonic DMR-HCT230 Manuale utente

LG BD611 Manuale utente

Panasonic

Panasonic Diga DMR-PWT420 Manuale utente

LG BD611 Manuale utente

Marantz

Marantz BD7004 Guida rapida

Kogan

Kogan KABRP3DWFIA Manuale utente

Toshiba

Toshiba BDX2700 Manuale utente

Philips

Philips BDP7100 Manuale utente

LG UBK80.DUSALLK Manuale utente

Sony

Sony BDP-S185 Manuale utente

Pioneer

Pioneer BDP-LX91 Manuale utente

Sharp

Sharp BD-HP90RU Manuale utente
