Samsung SC-D6040 Manuale utente

Camcorder Quick Start Guide

1. Attach the Battery Pack to the Camcorder.

2. Connect the AC Power Adapter to an AC Cord and connect

the AC cord to a wall socket.

3. Connect the DC Cable to the DC Jack Socket on the

Camcorder.

4. Turn the Camera Power Switch to off, and the charging indica-

tor will start to flash, showing that the battery is charging.

Battery charge time

SB - LS110 : Approx. 2hr

SB - LS220 : Approx. 3hr 30min

Connecting a Power Source

Preparation

Basic Recording

OFFOFF

OFF

Power Switch

1 2

1. Insert the Lithium battery with the positive (+) terminal facing downward.

2. Insert a Cassette.

3. Select the appropriate OSD Language among English, French, Spanish, German

or Italian.

Press the MENU button.

Move the cursor to highlight INITIAL and press the OK button.

Using the DOWN button, select the LANGUAGE.

Press the OK button and select your language then press the OK button.

To exit, press the MENU button.

● CLOCK SET

Press the MENU button.

Move the cursor to highlight INITIAL and press the OK button.

The cursor is on the CLOCK SET menu. Press the OK button.

A blinking item indicates the item to be changed.

Using UP and DOWN button, change the value then press the OK button to

set.

The word COMPLETE! will appear, and a few seconds later, the menu

screen will automatically return to the sub menu.

1. Connect a Power source to the camcorder.

2. Remove the LENS COVER.

3. Set the Power Switch to the REC position.

4. To start recording, press the START/STOP button.

OFF

AD68-00779V

3 4

OFF

OFFOFF

OFF

MENU button

OK button

UP button

DOWN button

1.Connect the camcorder to a TV with the AUDIO/VIDEO cable.

The yellow plug : Video

The white plug : Audio(L) - Mono

The red plug : Audio(R)

2. Set the Power Switch to the PLAY position.

3. Using the (FF) and (REW) buttons, find the first position

you wish to play back.

Press the (PLAY/STILL) button.

OFF

TAPE PLAYBACK

DSC Recording

DSC PLAYBACK

OFF

1 2

1. Turn the Power switch to OFF.

2. Insert the Memory Card into the Memory Card slot located on

the side of the Camcorder, in the direction of the arrow.

3. Set the Power Switch to

(CAMERA)

4. Turn the Mode Dial to the

(PROGRAM)

mode to take Still

Images.

To take motion clips, turn the Mode Dial to the

(MOVIE).

5. Still Image :

Press the PHOTO button to record a picture.

Motion Clip :

Press the START/STOP button to start

recording.

1. Turn the Power switch to OFF.

2. Insert the Memory Card into the Memory Card slot located on

the side of the Camcorder, in the direction of the arrow.

3. Set the Power Switch to

(CAMERA)

4. Turn the Mode Dial to the

(PLAY)

mode.

5. Still Image :

Using the 5-Way Button, browse your Still Images.

MPEG4 : Press the (PLAY/STILL) button to start play

back. You can use the (FF) and (REW)

buttons during the MPEG play back.

Press the (STOP) button to stop the play back.

S-VIDEO

Multi-AV

AUDIO(R)

AUDIO(L)

VIDEO

1 2 3

OFF

STOP

REW

PLAY/STILL

MOVIE


OFF

1 2

5-Way Button
