Samsung SC-D903 Manuale utente

Connecting a Power Source

Camcorder Quick Start Guide AD68-00792V

Power Switch

1. Attach the battery pack to the camcorder.

2. Connect the AC Power adapter to an AC cord and connect

the AC cord to a wall socket.

3. Connect the DC cable to the DC jack socket on the

camcorder.

4. Turn the Camera power switch to off, and the charging indica-

tor will start to flash, showing that the battery is charging.

Battery charge time

SB - LS110 : Approx 1hr 40min

SB - LS220 : Approx 3hr 30min

MENU Button

MENU Selector

(MENU/VOLUME/MF)

1. Insert the Lithium battery with the positive ( ) terminal facing outward.

2. Insert a Cassette.

3. Select the appropriate OSD Language among English, French, Spanish,

Portuguese, German and Italian.

➀Press the MENU button.

➁Move the MENU SELECTOR to highlight INITIAL and push the MENU

SELECTOR.

➂Using the MENU SELECTOR, select the LANGUAGE.

➃Push the MENU SELECTOR to confirm the OSD Language.

➄To exit, press the MENU button.

●CLOCK SET

➀Press the MENU button.

➁Move the MENU SELECTOR to highlight INITIAL and push the MENU

SELECTOR.

➂Use the MENU SELECTOR to select CLOCK SET from the submenu.

➃Push the MENU SELECTOR to enter SETTING mode.

A blinking item indicates the item to be changed.

➄Using the MENU SELECTOR, change the year, month, day, and hour setting.

➅The word COMPLETE! will appear, and a few seconds later, the menu screen

will automatically return to the sub menu.

1. Connect a Power source to the camcorder.

2. Remove the LENS COVER.

3. Set the mode switch to the TAPE position.

4. Set the power switch to the CAMERA position.

5. To start recording, press the START/STOP button.

Preparation

Basic Recording

OMEGA 2-Quick Guide-(D903) 5/21/04 10:53 AM Page 1

S-VIDEO

MEMORY STICK

TAPE

MIC

A/V

DC IN

S-VIDEO

A/V

CAMCORDER

VIDEO

AUDIO(L)

AUDIO(R)

REC SEARCH FADE BLC

REV FWD

EASY

MULTI DISP.


TAPE PLAYBACK

1.Connect the camcorder to a TV with the AUDIO/VIDEO cable.

■The yellow plug : Video

■The white plug : Audio(L) - Mono

■The red plug : Audio(R)

Set the mode switch to the TAPE position.

3. Set the power switch on the camcorder to PLAYER mode.

4. Using the (FF) and (REW) buttons, find the first position

you wish to play back.

Press the (PLAY/STILL) button.

1. Turn the Power switch to OFF.

2. Insert the Memory Stick into the Memory Stick slot located on

the bottom of the camcorder, in the direction of the arrow.

Set the mode switch to MEMORY

STICK

4. Set the power switch to the CAMERA mode.

5. ■Still Image : ➀Press the PHOTO button lightly (about

halfway down), when the image you want

to record appears.

- If you do not wish to record, release the

PHOTO button, select the image again.

➁Press the PHOTO button fully down to

record a picture to the Memory Stick.

■MJPEG : ➀Press START/STOP button to start

recording. (up to 60 seconds)

DSC (Digital Still Camera) Recording

455

123

1. Turn the Power switch to OFF.

2. Insert the Memory Stick into the Memory Stick slot located

beneath the camcorder, in the direction of the arrow.

Set the mode switch to MEMORY

STICK

Set the power switch to the PLAYER mode.

5. Using the (FWD) and (REV) buttons, search for the

desired still images/moving pictures.

■Moving picture : Pressing (PLAY/STILL) plays back

the moving picture and will show the first scene as a still

image when playback ends.

DSC PLAYBACK

OMEGA 2-Quick Guide-(D903) 5/21/04 10:53 AM Page 2
