Samsung SGH-P408 Manuale utente

SGH-P408

WAP Browser

User’s Manual

Printed in Korea

Code No.: GH68-03547A

English. 05/2003. Rev. 1.0

World Wide Web

http://www.samsungmobile.com

* Some of the contents in this manual may differ from your phone,

depending on the software installed or your service provider.

Contents

About the WAP Browser. . . . . . . . . . . . . . 4

Setting Up the WAP Browser . . . . . . . . . . 5

Accessing the WAP Browser . . . . . . . . . . . . . 5

Configuring the WAP Browser. . . . . . . . . . . . 8

Getting Started. . . . . . . . . . . . . . . . . . . . 10

Starting the WAP Browser . . . . . . . . . . . . . 10

Exiting the WAP Browser . . . . . . . . . . . . . . 10

Using the WAP Browser . . . . . . . . . . . . . 11

Using the Soft Keys. . . . . . . . . . . . . . . . . . 11

Navigating the WAP Browser . . . . . . . . . . . 11

Entering Text, Numbers or Symbols . . . . . . 12

Using the WAP Browser Menus . . . . . . . 13

Using and Selecting Menu Options . . . . . . . 13

Reload . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Home. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Go to URL . . . . . . . . . . . . . . . . . . . . . . . . 14

Show URL . . . . . . . . . . . . . . . . . . . . . . . . 14

Edit Home . . . . . . . . . . . . . . . . . . . . . . . . 15

Inbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

What is WAP?

WAP (Wireless Application Protocol) is the

gateway to a new world of mobile data. It

provides a universal standard, enabling

you to access web-based interactive

information services and applications

directly from your mobile phone.

* All product names are

trademarks or registered

trademarks of their

respective owners.

Setting Up the WAP

Browser

Before using the WAP Browser, you must set the

parameters for the proxy server used by your

service provider.

Accessing the WAP Browser

To enter the WAP Browser menu to access the

WAP browser:

1. When the idle screen displays, press the

Menu soft key to enter menu mode.

About the WAP

Browser

Your phone comes equipped with a WAP

(Wireless Application Protocol) browser, making

it possible for you to access the Wireless Web.

The WAP browser allows you to:

• access up-to-the-minute information via your

phone.

• view specially designed text versions of

popular Internet sites including Yahoo!®, CNN

MobileSM and the Weather Channel®.

Browsing the wireless web using your phone is

unlike using your computer, in that site providers

have:

• selected only the critical aspects of their site

for wireless phone users.

• removed most graphics.

Each time you start the WAP Browser, the phone

connects to the Wireless Web and the service

indicator icon ( or ) appears on the display

to inform you that you are:

• connected to the Wireless Web.

• billed accordingly. (rates vary according to

your service option)

The WAP Browser ends the network connection

after a certain period of inactivity and

automatically reconnects as necessary. For this

reason, you may find that you are billed for

several network connections within a single

session. This is normal and is designed to

minimize your bill.

Service Provider

07:30

Fri 10 Jan

Menu Name

2. Press the

key until the Funbox

menu option is displayed, and then press

the Select soft key. You can also press the

key directly.

Network Se...

Select

Messages

Option Description

Home Connects the phone to the

network and loads the homepage

of the Wireless Web service

provider.

Favorite Allows you to store the URL

addresses of your favourite Web

sites. You can access this menu

directly by pressing and holding

the key while using the WAP

Browser.

Setting Up the WAP Browser Setting Up the WAP Browser

3. Press the

key one or more times

to highlight WAP Browser, then press the

Select soft key. You can also press the

key directly.

Funbox

Games

WAP Browser

Downloads

Select

4. Press the

key one or more times

to highlight the required option and then

press the Select soft key.

WAP Browser

Home

Favorite

http://

Settings

Clear Cache

Push Message

Select

Option Description

Favorite To store a URL address, select

(Continued) an empty location and enter the

address.

Three submenus are available:

• Goto URL: quicklyaccesses you

to the site.

• Edit: edits the selected

address.

• Erase: deletes the selected

address.

http:// Allows you to enter manually the

URL address of the Web site that

you wish to access. You can

access this menu directly by

pressing and holding the key

down in the WAP browser.

Settings Allows you to set up five proxy

servers for the WAP Browser.

Clear Clears the information stored

Cache in the cache (the phone’s

temporary memory used to store

the most recently accessed Web

pages).

Push Allows you to set whether or

Message not you will receive Web

messages from the server, and

read or delete the messages

received.

Setting Up the WAP Browser

Configuring the WAP Browser

To configure the WAP Browser:

1. In the WAP Browser menu, highlight

Settings using the and keys, and

then press the Select soft key. You can also

press the key directly.

2. Select a proxy server and enter the

parameters required. Contact your service

provider for details.

Parameter Description

Profile Name that you wish to assign

Name to the HTTP proxy server.

Homepage Address of your startup

URL homepage. When the default

homepage displays, you can

delete it using the Ckey and

enter your own choice.

Security Data transmission mode.

Choose Secure to protect

your data against

unauthorised access;

otherwise, choose Non-

Secure.

IP Address WAP gateway address required

to connect to the Internet.

Bearer Bearer to be used for each

type of network address

accessed: GPRS or Data.

The remaining options depend on the Bearer

setting, as indicated next page.

When the bearer is set to Data

Parameter Description

Password PPP server password.

Dial-up PPP server phone number.

Number

Data Call Data call type: Analogue or

Type ISDN

When the bearer is set to GPRS

Parameter Description

User Name User ID required to connect to

the GPRS network.

Password Password required to connect

to the GPRS network.

APN Access point name used for

the address of the GPRS

network gateway.

Note: The WAP Browser settings may vary,

depending on the service provider. Contact

your service provider for more information.

3. After selecting each of these settings, a

dialogue box displays; you can either enter

the information required or choose between

given options. When you are satisfied with

your input, press the OK soft key.

4. When you have finished configuring the WAP

Browser, press the key or the right soft

key.

Using the WAP

Browser

Using the Soft Keys

A bar containing browser commands is located

at the bottom of the WAP browser display. The

soft keys below the bar are used to

execute these commands. The two keys are

called soft keys because their function changes

depending on the WAP browser application in

use.

Navigating the WAP Browser

To Then

scroll through scroll to the required item

and select using the or key,

browser items and then press the OK soft

key to confirm the

selection.

return to the press the Back soft key or

previous page the key.

return to the select the Home menu

startup homepage option; for more

information about this

option, refer to page 13.

Getting Started

Starting the WAP Browser

To start the WAP Browser when the idle screen is

displayed, press the key or press the Menu

soft key, followed by the , and

keys.

A connection is established with your service

provider and the corresponding homepage

displays.

The content of the WAP Browser startup

homepage depends on your Wireless Web

service provider. To scroll through the screen,

use the or keys.

Note: To access the startup homepage from any

other screen in the WAP Browser, use the

Home option. For more information on the

WAP Browser menus, refer to page 13.

Exiting the WAP Browser

To exit the browser at any time, simply press the

key or close the phone.

Using the WAP Browser

Using the WAP

Browser Menus

Using and Selecting Menu Options

Various menu options are available when you are

using the WAP Browser to navigate the Wireless

Web.

To access a menu option, proceed as follows:

1. Press and hold the key.

A menu is displayed.

2. Highlight the required menu option by

pressing the or key.

3. Select the option by pressing the Select soft

key.

4. If necessary, select the secondary option

using the or key, and press the

Select soft key to confirm.

Note: The menus may vary, depending on your

version of the WAP browser.

Reload

This option reloads the current page.

Home

This option takes you back at any time to the

homepage of the Wireless Web service provider.

Entering Text, Numbers or Symbols

When you are prompted to enter text, the

current text entry mode is indicated on the

screen. The following modes are available:

Mode Description

Allows you to enter letters in the

alphabet. Press the corresponding key

until the required letter is displayed.

Allows you to enter numbers.

Note: To enter symbols, press the key until

the required symbol displays.

To Then

change modes press the key one or

more times.

enter the Chinese press and hold the key.

text

enter a space press the key.

edit text • set the cursor to the right

of the character to be

corrected.

• press the key as

required.

• enter the correct

character(s).

Using the WAP Browser Menus Using the WAP Browser Menus

Go to URL

This option allows you to enter manually the URL

address of the required Web page.

After entering an address, press the OK soft key

to go there directly.

Show URL

This feature displays the URL address of the site

to which you are currently connected. It also

enables you to declare the current site as the

startup homepage.

To Press the

declare the current Option soft key, select

page as your startup the Save to Home option

homepage and press Select.

set a bookmark for Option soft key, select

the current page the Save to Bookmark

option and press Select.

cancel your setting Back soft key.

Edit Home

With this feature, you can change the startup

homepage manually.

To change the homepage, enter the required

URL and press the OK soft key.

For more information on entering text, number

or symbols, refer to page 12.

Inbox

This menu allows you to read messages received

from the web server.

Altri manuali per SGH-P408

Indice

Altri manuali Samsung Telefono cellulare

Samsung

Samsung Galaxy S5 Active Manuale utente

Samsung

Samsung GT-S8300C Manuale utente

Samsung

Samsung SCH-A212 Manuale utente

Samsung

Samsung SM-T510 Manuale utente

Samsung

Samsung GT-S5312B Manuale utente

Samsung

Samsung GT-I9003 Manuale utente

Samsung

Samsung Spex SCH-r210 Series Manuale utente

Samsung

Samsung Galaxy A04S Manuale utente

Samsung

Samsung SM-N770F Manuale utente

Samsung

Samsung Alias 2 Manuale utente

Samsung

Samsung GT-E2152 Manuale utente

Samsung

Samsung SPH-N100 Manuale utente

Samsung

Samsung B2700 Manuale utente

Samsung

Samsung SGH-X640 Manuale utente

Samsung

Samsung SGH-I750 Series Manuale utente

Samsung

Samsung GT-I8530 Manuale utente

Samsung

Samsung GT-I9158V Manuale utente

Samsung

Samsung GT-M8800 Manuale utente

Samsung

Samsung SPHI500SS Manuale utente

Samsung

Samsung SM-F9360 Manuale utente

Samsung

Samsung SA-N9001 Istruzioni per l'installazione

Samsung

Samsung SCL22 Manuale utente

Samsung

Samsung Impression SEGA877RBAATT Manuale utente

Samsung

Samsung SM-G530MU Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
