Samsung SMART HOME DONGLE Manuale utente
Samsung SMART HOME
DONGLE
User manual
HD39J1230GW
• These safety precautions are for owner’s safety and preventions of property damage.
Therefore, please read this manual thoroughly before using your product.
SMARTdongle_EN.indd 1 2015-12-23 오후 7:10:45
2
What is SMART HOME DONGLE? ..................................... 3
Application of SMART HOME DONGLE ............................ 3
Installation of SMART HOME DONGLE ........................... 4
Installing SMART HOME DONGLE ....................................... 4
Installation of Smart Home App ...................................... 4
Setting the network ............................................................. 5
Specication of wired/wireless router for Samsung
SMART HOME donlge ................................................................ 6
Downloading Samsung Smart Home App .................... 7
Registering Samsung account ............................................... 7
Downloading Samsung Smart Home App ...................... 8
Registering the product ........................................................... 9
Specication ......................................................................... 17
Open Source Announcement .......................................... 17
Safety information ............................................................. 18
Troubleshooting .................................................................. 21
Contents
SMARTdongle_EN.indd 2 2015-12-23 오후 7:10:45
3
What is SMART HOME DONGLE?
SMART HOME DONGLE is an optional device to operate Wi-Fi function or run Samsung SMART HOME App by
mounted on Smart READY appliances of Samsung Electronics Co., Ltd. (not provided)
Application of SMART HOME DONGLE
• Use SMART HOME DONGLE for Samsung Smart READY appliances.
A port of Samsung Smart READY
appliance
SMARTdongle_EN.indd 3 2015-12-23 오후 7:10:45
4
Installation of SMART HOME DONGLE
Installing SMART HOME DONGLE
• Install the dongle at the given position of each
Samsung Smart READY appliance.
• Refer to the appropriate manual of Samsung Smart
READY appliances for the installation position.
• Download a manual of each appliance at www.
samsung.com and refer to it.
• Refer to an application manual or a user manual
of each Smart READY appliance for using the
application.
Installation of Smart Home App
[Setting the network]
Connect the wired/wireless router to the
SMART HOME DONGLE wirelessly.
[Registering Smart Home Service]
Register the service using Smart Home app
on your Smartphone.
SMARTdongle_EN.indd 4 2015-12-23 오후 7:10:45
5
Setting the network
Note
• For the certication and cipher type of wired or wireless router, recommended use WPA/TKIP or WPA2/AES. It
does not support a new Wi-Fi certied specication and non-standard Wi-Fi certication type.
• The quality of wireless network connection can be affected by surrounding wireless circumstance.
• If an internet service provider registered the user's PC or MAC address (Identication number) of the modem
permanently, the SMART HOME DONGLE cannot be connected to the Internet. Please contact the internet
service provider and inquire about the internet connection process to connect a device (e.g. SMART HOME
DONGLE) to the Internet.
• The Internet may not be connected due to the rewall. Please contact the internet service provider and request
the solution.
• If you followed what the internet service provider directed but cannot still connect the internet, please contact
the service center.
SMARTdongle_EN.indd 5 2015-12-23 오후 7:10:45
6
Specication of wired/wireless router for Samsung SMART HOME donlge
LAN port on the
wall
LAN cable
Wired/wireless router
(supports DHCP server)
• Please refer to the user manual for installation of
your wired/wireless router.
• Specication of wired/wireless router for Samsung
SMART HOME DONGLE
• Samsung SMART HOME DONGLE supports the
IEEE802.11 b/g/n(2.4GHz), Soft-AP method
communication protocol.
(Samsung Electronics recommends use of
IEEE802.11n.)
• If the wired/wireless router is not a Wi-Fi certied
product, it may not be connected to the SMART
HOME DONGLE.
SMARTdongle_EN.indd 6 2015-12-23 오후 7:10:45
7
Downloading Samsung Smart Home App
Registering Samsung account
• Before using the Samsung Smart Home App, register the Samsung account.
Note
Samsung account
login screen(iphone)
• If you run the Samsung Smart Home App but the auto login
is not set, the Samsung account screen appears only one
time in the initial process.
SMARTdongle_EN.indd 7 2015-12-23 오후 7:10:45
8
Downloading Samsung Smart Home App
• You can download the Samsung Smart Home App by searching "Samsung Smart Home" on Play store, Galaxy
Apps and iPhone App Store.
Note
• Samsung Smart Home app supports android operating system 4.0(ICS) or higher and is optimized with
Smasung Smart phones (Galaxy S or Note series). If you run the App using a Smartphone manufactured by
other companies, some functions may operate differently.
• For iPhone users, iOS7 or higher supports the App.
• Samsumg Smart Home App is subject to change without notice for product improvement purposes.
SMARTdongle_EN.indd 8 2015-12-23 오후 7:10:45
9
Registering the product
• Before using the Samsung Smart Home App, register
the product to the Samsung Smart Home Service.
Android
b
a
1
1 Search(a) or select(b) the
user's country and press
the Save button.
SMARTdongle_EN.indd 9 2015-12-23 오후 7:10:45
10
2
2 Select the Samsung Smart
READY appliance icon,
which will be registered.
d
c
3
3 Enter(c) the password of
wireless router which will
be connected and then
press the Next button.
– If you want to change
the connected router,
press the icon(d) and
select AP name of the
wireless router.
Note
• When the guidance screen
for changing the network
setting appears, uncheck
the box that says 'Smart
network switch'.
SMARTdongle_EN.indd 10 2015-12-23 오후 7:10:45
