Samsung NX-N2 Manuale utente
User Manual
NX-N2
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00400A-00
Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
4 Copyright
5 Icons used in this manual
5 Symbols for safety precautions
6 Securing the Installation Space
6 Precautions for storage
7 Safety Precautions
7 Electricity and Safety
8 Installation and Safety
10 Operation and Safety
PREPARATIONS 14 Checking the Components
14 Checking the Components
16 Parts
16 Front view
18 Reverse Side
19 Installation
19 Attaching the cradle
20 Attaching Products
21 Anti-theft Lock
USING "PCOIP" 22 What is a "PC over IP"?
23 Connection to Use "PCoIP"
23 Connection Using the DP Cable
24 Connecting to a Secondary Monitor
25 Connecting to Headphones
25 Connecting a Microphone
26 LAN Connection
27 Connecting USB Devices
28 Connecting the Power
29 Connect to the host PC using a LAN
cable
Table Of Contents
Table Of Contents 3
30 "PCoIP"
30 On Screen Display (OSD)
30 Connect Screen
31 OSD Options Menu
32 Configuration Window
46 Diagnostics Window
50 Information Window
52 User Settings Window
59 Password Window
61 Wake On LAN
62 Wake on USB
63 OSD Logo Upload
64 Firmwre Update
TROUBLESHOOTING
GUIDE
65 Requirements Before Contacting
Samsung Customer Service Center
65 Check the following.
SPECIFICATIONS 66 General
67 Power consumption
APPENDIX 68 Contact SAMSUNG WORLD WIDE
74 Responsibility for the Pay Service
(Cost to Customers)
74 Not a product defect
74 A Product damage caused by customer's fault
74 Others
76 Correct Disposal
76 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
76 Correct disposal of batteries in this product
INDEX
4
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2014 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
The SAMSUNG logo is a registered trademark of Samsung Electronics.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
(b) you bring the unit to a repair centre and there is no defect in the product
(i.e. where you have failed to read this user manual).
The amount of such administration charge will be advised to you before any work or home visit is
carried out.
5
Before Using the Product
Before Using the Product
Icons used in this manual
Symbols for safety precautions
The following images are for reference only. Real-life situations may
differ from what is shown in the images.
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
6
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire and
damage the product. Be sure to allow the amount of space as shown below or greater when installing
the product.
The exterior may differ depending on the product.
This product can be installed in portrait or landscape orientation.
Precautions for storage
For information on how to clean the inside of the product, contact the service center (page 69) first.
(A service fee will be charged.)
3.93 inches
(10 cm)
3.93 inches
(10 cm)
3.93 inches
(10 cm)
3.93 inches
(10 cm)
3.93 inches
(10 cm)
7
Before Using the Product
Before Using the Product
Safety Precautions
The following images are for reference only. Real-life situations may differ from what is shown in
the images.
Electricity and Safety
Warning
Do not use a damaged power cable or plug, or a loose power socket.
An electric shock or fire may result.
Do not plug many products into the same power socket.
Otherwise, the socket may overheat and cause a fire.
Do not touch the power cable with wet hands.
Otherwise, an electric shock may result.
Insert the power cable all the way in so it is not loose.
An unstable connection may cause a fire.
Ensure you connect the power cable to a grounded power socket.
(type 1 insulated devices only).
An electric shock or injury may result.
Do not bend or pull the power cable with force. Do not weigh the power cable
down with a heavy object.
A damaged power cord may cause an electric shock or fire.
Do not place the power cable or product near heat sources.
An electric shock or fire may result.
If the power cable pins or power outlet is covered with a foreign substance (dust,
etc.), wipe it off using a dry cloth.
Otherwise, a fire may result.
!
!
!
8
Before Using the Product
Before Using the Product
Caution
Installation and Safety
Warning
Do not unplug the power cable when the product is in use.
The product may become damaged by an electric shock.
Do not use the power cable for products other than authorized products supplied
by Samsung.
An electric shock or fire may result.
Keep the power socket where the power cable is connected unobstructed.
If any problem occurs in the product, unplug the power cable to completely
cut the power to the product.
You cannot cut the power off completely using only the power button on the
product.
Hold the plug when disconnecting the power cable from the power socket.
An electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
Otherwise, a fire may result.
Avoid installing the product in a narrow space with bad ventilation, such as a
bookshelf or wall closet.
Otherwise, a fire may result due to an increased internal temperature.
Keep the plastic packaging bag for the product in a place that cannot be reached
by children.
Children may suffocate.
!
!
9
Before Using the Product
Before Using the Product
Caution
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.).
The product may fall and break or cause a personal injury.
Using the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
An electric shock or fire may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
Otherwise, the product lifespan may be reduced, or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
Edible oil, such as soybean oil, can damage or deform the product. Do not install
the product in a kitchen or near a kitchen counter.
Take care not to drop the product when moving it.
Otherwise, product failure or personal injury may result.
Put down the product carefully.
The product may fall and break or cause a personal injury.
10
Before Using the Product
Before Using the Product
Operation and Safety
Warning
Installing the product in an unusual place (a place exposed to a lot of fine dust,
chemical substances, extreme temperatures or a significant presence of
moisture, or a place where the product will operate continuously for an extended
period of time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Center (page 69) before
installation if you want to install the product at such a place.
Do not leave or install the product on the floor.
Abrupt force such as kicking or extra weight such as stepping on the
product may cause a product failure or personal injury.
High voltage runs through the product. Do not attempt to disassemble, repair, or
modify the product on your own.
An electric shock or fire may result.
Contact Samsung Customer Service Center (page 69) for repair.
Before moving the product, turn off the power and disconnect the power cable
and all other connected cables.
Otherwise, the power cord may be damaged and a fire or electric shock may
result.
If the product generates a strange noise, a burning smell, or smoke, remove the
power cable immediately and contact Samsung Customer Service Center
(page 69).
An electric shock or fire may result.
Ensure children do not sit on the product or kick the product.
The product may fall, and your child may become injured or seriously
harmed.
If the product falls or the exterior is damaged, power off the product, remove the
power cable, and contact Samsung Customer Service Center (page 69).
Otherwise, an electric shock or fire may result.
Do not sit on the product.
The product housing or connectors may get damaged or personal injury may
result.
