Samsung TL350 Manuale di istruzioni

This Quick Start Manual has been specially designed to guide

you through the basic functions and features of your device.

Please read the Quick Start Manual and User Manual carefully

to ensure safe and correct use.

Quick Start Manual

TL350

For more information, refer to

the User Manual included on the

supplied CD-ROM.

ENG / SPA

FOR TECHNICAL SUPPORT, PLEASE CALL 1-800-SAMSUNG (726-7864)

POR FAVOR LLAMAR 1-800-SAMSUNG (726-7864) PARA ASISTENCIA TECNICA

TL350_QSM_SEA.indb 3 2010-06-11 오후 6:28:16

EN-2

Health and safety informationContents

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach of

small children and animals. Small parts may cause choking

or serious injury if swallowed. Moving parts and accessories

may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1 m/

3 ft) to people or animals. Using the ﬂash too close to your

subject’s eyes can cause temporary or permanent damage.

Health and safety information 2

Camera layout ……………… 4

Setting up your camera …… 5

Unpacking ……………………… 5

Inserting the battery and

memory card …………………… 6

Charging the battery …………… 6

Turning on your camera………… 7

Selecting options ……………… 7

Capturing photos or videos 8

Playing ﬁles ………………… 9

Transferring ﬁles to a PC

(Windows) …………………… 10

Speciﬁcations ……………… 11

124

TL350_QSM_SEA.indb 2 2010-06-11 오후 6:28:16

EN-3

English

• Exercise caution when connecting cables or adapters

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

• Do not insert foreign objects into any of your camera’s

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

Protect batteries, chargers, and memory cards from

damage

• Avoid exposing batteries or memory cards to very

cold or very hot temperatures (below 0° C/32° F or

above 40° C/104° F). Extreme temperatures can

reduce the charging capacity of your batteries and

can cause memory cards to malfunction.

• Prevent memory cards from making contact with

liquids, dirt, or foreign substances. If dirty, wipe the

memory card clean with a soft cloth before inserting

in your camera.

Handle and dispose of batteries and chargers with

care

• Use only Samsung-approved batteries and chargers.

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

• Never place batteries or cameras on or in heating

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

Cautions

Handle and store your camera carefully and sensibly

• Do not allow your camera to get wet—liquids can

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

• Avoid using or storing your camera in dusty, dirty,

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

TL350_QSM_SEA.indb 3 2010-06-11 오후 6:28:16

EN-4

Mode dial

Shutter button

POWER button

Mini dashboard

Speaker

AF-assist light/timer lamp

Lens

Battery chamber cover

Camera layout

Recorder button

Function button

Playback button

(

Navigation button/OK button

)

MENU button

Tripod mount

Display

200 !

*& ^

) (

Flash

Microphone

Zoom button

Status lamp

HDMI port (Accepts HDMI cable)

Drive mode dial

USB and A/V port (Accepts USB

cable or A/V cable)

TL350_QSM_SEA.indb 4 2010-06-11 오후 6:28:17

EN-5

English

Setting up your camera

Unpacking

Camera AC adapter/USB cable

(AD44-00143A)/(AD39-00165A)

Rechargeable battery

(4302-001226)

Strap

(Black: AD63-02604A/

Silver: AD63-02596A)

Software CD-ROM

(User manual included)

(AD46-00337A)

Quick Start Manual

(AD68-04844A)

Optional accessories

Memory cards A/V cable

(AD39-00146A)

Battery charger

(AD44-00164A)

HDMI cable

(AD39-00179A)

TL350_QSM_SEA.indb 5 2010-06-11 오후 6:28:18

EN-6

Setting up your camera

Inserting the battery and memory card Charging the battery

Insert the battery

with the Samsung

logo facing down.

Insert the memory

card with the

gold-colored

contacts facing up.

Indicator light

▪Red: Charging

▪Green: Fully charged

Before using the camera for the ﬁrst time, you must

charge the battery.

▼

Removing the battery

▼

Removing the memory card

Push gently the card until the

card disengages from the

camera, and then pull it out of

the slot.

TL350_QSM_SEA.indb 6 2010-06-11 오후 6:28:19

EN-7

English

Press [POWER].

▪The initial setup screen appears when you turn on

your camera for the ﬁrst time.

Select a language, select a time zone, and set

the date and time.

Language

Time Zone

Date & Time

English

London

ExitMove

2010/01/01

In Shooting mode, press [m].

Rotate or press the navigation button to scroll

to an option or menu.

▪To move up or down press [D] or [c]. To move

left or right press [F] or [I].

▪Rotate the navigation button any direction.

Press [o] to conﬁrm the highlighted option

or menu.

▪Press [m] again to go back to the previous

menu.

Turning on your camera Selecting options

TL350_QSM_SEA.indb 7 2010-06-11 오후 6:28:19

EN-8

Taking a photo

Rotate the mode dial to t.

Align your subject in the frame.

Press [Shutter] halfway down to focus

automatically.

▪A green frame means the subject in focus.

00001

F2.4 1/60

Press [Shutter] all the way down to take the

photo.

Recording a video

Rotate the mode dial to v.

Align your subject in the frame.

Press (Recorder) to start recording.

▪Press [o] to pause or resume.

Press (Recorder) again to stop the

recording.

Note

Number of photos by resolution (for 1 GB SD)

Super

Fine Fine Normal RAW RAW +

S.Fine

RAW +

Fine

RAW +

Normal

180 328 451 41 31 37 39

201 363 497 42 32 37 40

220 392 531 42 33 38 40

235 420 568 42 34 38 40

235 419 568 42 34 38 40

319 542 707 43 36 40 42

471 746 928 44 39 42 43

645 967 1,161 45 41 43 44

1,056 1,331 1,458 46 43 44 44

These ﬁgures are measured under Samsung’s standard conditions. Your

results may vary depending on shooting conditions and camera settings.

Capturing photos or videos

TL350_QSM_SEA.indb 8 2010-06-11 오후 6:28:21

EN-9

English

Playing ﬁles

Viewing photos

Press [P].

Press [F] or [I] to scroll through ﬁles.

▪Press and hold [F] or [I] to scroll through ﬁles

quickly.

F2.4 1/60

Viewing videos

Press [P].

Press [o].

Use the following buttons to control playback.

[F]

Scan backward. The camera

scans backward in 2X, 4X, and 8X

increments when you press [F].

[o]Pause or resume playback.

[I]

Scan forward. The camera

scans forward in 2X, 4X, and 8X

increments when you press [I].

[Zoom] left

or right Adjust the volume level.

TL350_QSM_SEA.indb 9 2010-06-11 오후 6:28:21

EN-10

Transferring ﬁles to a PC (Windows)

Connect the camera to the PC with the USB

cable.

Note

Make sure that the PC Software option is set to On in the

settings menu.

Turn on the camera.

▪The computer recognizes the camera automatically.

▪For Windows Vista and Windows 7, select

Run iStudio.exe from the AutoPlay window.

Select a folder on your computer to save new

ﬁles.

▪If your camera has no new ﬁles, the pop-up window

for saving new ﬁles will not appear.

Select Yes.

▪New ﬁles will be transferred to your computer.

You can now use the Intelli-studio program.

Note

About Intelli-studio

Intelli-studio is a built-in program that allows you to play

back and edit ﬁles. You can also upload ﬁles to websites,

such as Flickr or YouTube.

TL350_QSM_SEA.indb 10 2010-06-11 오후 6:28:21
