Samsung DV331AE Series Manuale utente
* Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and
Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of
consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study
results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.
Signature Features
Sensor Dry
For the perfect dry every time
Detects the moisture level in the load
and adjusts the drying time to save
time and money.
Available Colors
Wrinkle Prevent Option
To reduce ironing time
Intermittently tumbles clothes at the
end of the drying cycle to help prevent
wrinkles from setting in.
Steam Drying Technology
Refresh and Wrinkle-Care
These cycles infuse clothes with steam
to reduce wrinkles, remove odors, and
refresh clothing.
Neat White
DV331AER
7.3 cu. ft. Capacity Electric Steam Dryer
Features
∙Steam Drying Technology:
-Steam Refresh: Freshens up
clothes and removes odors
-Steam Wrinkle-Care: Relaxes
wrinkles to reduce ironing
∙7.3 cu. ft. Capacity
∙9 Preset Drying Cycles
∙3 Options
∙4 Temperature Settings
∙ 4 Way Venting
Convenience
∙Sensor Dry – Detects Moisture and
Adjusts Drying Time
∙Reversable See Through Door
∙ Dryer Drum Light
∙Child Lock
∙Lint Filter Indicator
∙Remaining Time Display
∙Adjustable End of Cycle Signal
∙Optional Pedestals or Stacking
Kit Available
Ranked “Highest in Customer
Satisfaction with Clothes
Dryers” by J.D. Power and
Associates.*
(Shown with optional pedestal) 3 Options
9 Cycles
Tango Red
(shown)
Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2011 Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660. Tel: 800-SAMSUNG www.samsung.com. Samsung is a registered trademark of Samsung Electronics Co. Ltd.
Fabric Care
9 Preset Dry Cycles
Steam Refresh, Steam Wrinkle-Care, Normal,
Heavy Duty, Permanent Press, Delicates, Sanitize,
Time Dry, Quick Dry
3 Options
Mixed Load Bell, Wrinkle Prevent, Adjust Time
4 Temperature Settings
High, Medium, Low, Extra Low
4 Dry Levels
More Dry, Normal Dry, Less Dry, Damp Dry
3 Signal Sound Levels
Louder, Soft, Off
Accessories:
Stacking Kit: SK-3A1, SK-4A, SK-5A
Vent Kit: DV-1A
Pedestal: WE357A0R, WE357A0W
Warranty
One (1) Year All Parts and Labor
Two (2) Years Control Board
Product Dimensions + Weight
Dimensions: (WxHxD) 27" x 38 5⁄8" x 30 7⁄8"
Weight: 121.1 lbs / 55 kg
Shipping Dimensions + Weight
Dimensions: (WxHxD) 29 3⁄4" x 43 3⁄4" x 33 1⁄8"
Weight: 143.2 lbs / 65 kg
Color Model # UPC Code
Tango Red DV331AER 036725560796
Neat White DV331AEW 036725560802
Matching Washer
Tango Red WF331ANR 036725560772
Neat White WF331ANW 036725560789
Installing your dryer
Required Dimensions for Installation With Pedestal Required Dimensions for Installation
With Stacking Kit
* Required spacing ** External exhaust elbow requires additional space.
Minimum clearances
for closets and alcove:
Sides - 1 In.(2.5 cm)
Top - 17 In.(43.2 cm)
Rear - 4 In. (10.2 cm)
Closet Front - 2 In. (5.1 cm)
If the washer and dryer are
installed together, the closet
front must have at least a 72 in²
(465cm²) unobstructed air
opening. Your washer alone does
not require a specific air opening.
1 in.1 in. 27 in.
Recessed Area
2 in. 4 in.
17 in.
Side View Confined
27 in.
53 in.
Closet or Door
48 in.² *
24 in.² *
3 in.
3 in.
1 in. 5.5 in.**
2.5 in.
1 in. 27 in.
77.25
in.
6 in. *
4 in.
50.8 in. (129 cm) to clear open door
2. With optional pedestal base or stacking kit
1. Alcove or closet installation
Installation Options:
Stacked Side by Side On Pedestals Stacked Depth
(38 2⁄8”)
DV331AER
7.3 cu. ft. Capacity Electric Steam Dryer
30.875 in.
38.625
in.
30.875 in.
30.875
in.
* Samsung received the highest numerical score for clothes washers (2009-2010) and dryers (2008-2010) in the proprietary J.D. Power and
Associates Laundry Appliance StudiesSM. 2010 study based on 10,344 total responses measuring 17 brands and measures opinions of
consumers who purchased their washer or dryer from a retail store or their new-home builder during the previous 24 months. Proprietary study
results are based on experiences and perceptions of consumers surveyed in March-April 2010. Your experiences may vary. Visit jdpower.com.
Available Colors
(Shown with optional pedestal) 3 Options
9 Cycles
Signature Features
Sensor Dry
For the perfect dry every time
Detects the moisture level in the load
and adjusts the drying time to save
time and money.
Wrinkle Prevent Option
To reduce ironing time
Intermittently tumbles clothes at the
end of the drying cycle to help prevent
wrinkles from setting in.
Neat White
DV331AGR
7.3 cu. ft. Capacity Gas Steam Dryer
Tango Red
(shown)
Steam Drying Technology
Refresh and Wrinkle-Care
These cycles infuse clothes with steam
to reduce wrinkles, remove odors, and
refresh clothing.
Features
∙Steam Drying Technology:
-Steam Refresh: Freshens up
clothes and removes odors
-Steam Wrinkle-Care: Relaxes
wrinkles to reduce ironing
∙7.3 cu. ft. Capacity
∙9 Preset Drying Cycles
∙3 Options
∙4 Temperature Settings
∙ 3 Way Venting
Convenience
∙Sensor Dry – Detects Moisture and
Adjusts Drying Time
∙Reversable See Through Door
∙ Dryer Drum Light
∙Child Lock
∙Lint Filter Indicator
∙Remaining Time Display
∙Adjustable End of Cycle Signal
∙Optional Pedestals or Stacking
Kit Available
Ranked “Highest in Customer
Satisfaction with Clothes
Dryers” by J.D. Power and
Associates.*
Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2011 Samsung Electronics America, Inc. 85 Challenger Road Ridgefield Park, NJ 07660. Tel: 800-SAMSUNG www.samsung.com. Samsung is a registered trademark of Samsung Electronics Co. Ltd.
Fabric Care
9 Preset Dry Cycles
Steam Refresh, Steam Wrinkle-Care, Normal,
Heavy Duty, Permanent Press, Delicates, Sanitize,
Time Dry, Quick Dry
3 Options
Mixed Load Bell, Wrinkle Prevent, Adjust Time
4 Temperature Settings
High, Medium, Low, Extra Low
4 Dry Levels
More Dry, Normal Dry, Less Dry, Damp Dry
3 Signal Sound Levels
Louder, Soft, Off
Accessories:
Stacking Kit: SK-3A1, SK-4A, SK-5A
Vent Kit: DV-1A
Pedestal: WE357A0R, WE357A0W
Warranty
One (1) Year All Parts and Labor
Two (2) Years Control Board
Product Dimensions + Weight
Dimensions: (WxHxD) 27" x 38 5⁄8" x 30 7⁄8"
Weight: 121.1 lbs / 55 kg
Shipping Dimensions + Weight
Dimensions: (WxHxD) 29 3⁄4" x 43 3⁄4" x 33
1⁄8"
Weight: 143.2 lbs / 65 kg
Installing your dryer
Required Dimensions for Installation With Pedestal Required Dimensions for Installation
With Stacking Kit
* Required spacing ** External exhaust elbow requires additional space.
Minimum clearances
for closets and alcove:
Sides - 1 In.(2.5 cm)
Top - 17 In.(43.2 cm)
Rear - 4 In. (10.2 cm)
Closet Front - 2 In. (5.1 cm)
If the washer and dryer are
installed together, the closet
front must have at least a 72 in²
(465cm²) unobstructed air
opening. Your washer alone does
not require a specific air opening.
1 in.1 in. 27 in.
Recessed Area
2 in. 4 in.
30.875 in.
17 in.
Side View Confined
27 in.
38.625
in.
53 in.
Closet or Door
48 in.² *
24 in.² *
3 in.
3 in.
1 in. 5.5 in.**
2.5 in.
1 in. 27 in.
6 in. *
4 in.
30.875 in.
30.875
in.
50.8 in. (129 cm) to clear open door
2. With optional pedestal base or stacking kit
1. Alcove or closet installation
Installation Options:
Stacked Side by Side On Pedestals Stacked Depth
(38 2⁄8”)
DV331AGR
7.3 cu. ft. Capacity Electric Steam Dryer
Color Model # UPC Code
Tango Red DV331AGR 036725560819
Neat White DV331AGW 036725560826
Matching Washer
Tango Red WF331ANR 036725560772
Neat White WF331ANW 036725560789
77.25
in.
