Samsung DV361EWBE Manuale utente

FEATURES

• 7.3 Capacity (cu.ft / DOE)

• Powder Coat Drum

• 4 Way Venting

• Heating Element: 5300W/

22,000 BTU/Hr

• Cycle Time (AHAM 8lbs): 42 min.

• LED display (red)

• Outer door trim: white

• Door handle: inner pocket

CONVENIENCE

• Reversible See-through Door

• Dryer Drum Light

• Child Lock

• Lint Filter Indicator

• 7 Preset Dry Cycles and 4 Options

• 4 Dry Levels

• 4 Temperature Settings

• 3 Timed Settings

• 2 Signal Level Settings

DV361EWBE

Samsung Front Load Electric Dryer

Capacity that fits more — so you can fit more in your day

Big enough to handle a king-size comforter, our large capacity dryer allows you to do fewer loads,

so you can ﬁnish your family's laundry faster.

4 Temperature settings

The DV361 comes with 4 temperature settings: High, Medium, Low, Extra Low to assure the most

efﬁcient drying results.

Peace of mind with NSF® certified sanitization cycle

Samsung’s NFS certiﬁed washers eliminate 99.9% of household bacteria from laundry.

SIGNATURE FEATURES

Ranked “Highest in Customer

Satisfaction with Clothes Dryers”

by J.D. Power and Associates.*

(5 Consecutive Years) * Samsung received the highest numerical score for clothes dryers in the proprietary J.D. Power and Associates 2008-2012 Laundry Appliance

Studies.SM 2012 study based on 9,339 total responses measuring 12 brands and measures opinions of consumers about their dryer obtained

new in the past 24 months. Proprietary study results are based on experiences and perceptions of consumers surveyed in January-February 2012.

Your experiences may vary. Visit jdpower.com.

White

Available colors

7.3 Capacity (Cu.ft/DOE)

Powder Coat Drum

4 Way Venting

7 Preset dry cycles:

Normal, Heavy Duty, Permanent Press, Delicates,

Time Dry, Air Fluff, Wrinkle Release

4 Options:

Mixed Load Bell, Wrinkle Prevent, Adjust Time,

Child Lock

4 Dry levels:

More Dry, Normal Dry, Less Dry, Damp Dry

4 Temperature settings:

High, Medium, Low, Extra Low

3 Timed settings:

60 min, 40 min, 20 min

2 Signal Level settings: On/Off

Warranty

One (1) Year Parts and Labor

Two (2) Years Control Board

Product dimensions & weight (WxHxD)

Dimensions: 27" x 383/8" x 311/8"

Weight: 118.9 lbs

Shipping dimensions & weight (WxHxD)

Dimensions: 293/8" x 41" x 332/8"

Weight: 127.8 lbs

Color Model # UPC Code

White DV361EWBEWR 036725591141

Matching Washer

White WF361BVBEWR 036725590939

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

DV361EWBE

Samsung Front Load Electric Dryer

INSTALLING YOUR DRYER

Required dimensions for installation with pedestal Required dimensions for installation with

stacking kit

* Required spacing ** External exhaust elbow requires additional space.

Minimum clearances

for closets and alcove:

Sides - 1 in.(2.5 cm)

Top - 17 in.(43.2 cm)

Rear - 4 in. (10.2 cm)

Closet Front - 2 in. (5.1 cm)

If the washer and dryer are

installed together, the closet

front must have at least a 72 in.2

(465 cm2) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

Recessed Area

17"

Side View Conﬁned

Closet or Door 31 1/8"

2. With optional pedestal base or stacking kit

1. Alcove or closet installation

INSTALLATION OPTIONS:

Stacked On Pedestals Stacked DepthSide by Side

(38 1/4")

31 1/8"

38 3/8"

2 1/2"

50 13/16" to clear open door

27"

52 3/8"

48"2*

24"2*

1" 5 1/2"** 1" 27"

6"*

1" 27" 2" 31 1/8"

77 1/2"
