Samsung SR-W04B Manuale utente

Main Pa

Safet

Precautions

Safety Precautions

During Installation

During Operating

Others

Regulatory

Features

Exterior

System Requirements

Features

Installing DVD±R/RW Drive and

Connectin

Cables

Installing Drive

Connecting Cables

Installing Software and Confirming The

Installation

Software Setup

Firmware Upgrade

Confirming the Installation of DVD±R/RW

Installing the MS-DOS device driver

How To Use The DVD±R/RW Drive

How to Use the Drive

When the on/off Light Blinks

How to Use DVD-R and Other Discs

Deletin

Utilities

Troubleshootin

Product S

ecifications

Storin

/Cleanin

Drive and Disc

Cleaning the Drive

Storing the Disc

Cleaning the Other Discs

Brief Instructions For Using CD

Software

Software Programs

Nero Express 6

WinDVD Creator

WinDVD Recoder

DVD Copy

Index

This symbol indicates explanations about extremely dangerous matters. If users ignore this

symbol and handle the device the wrong way, serious injury or death could result.

This symbol indicates explanations about dangerous matters. If users ignore this symbol and

handle the device the wrong way, damage to home or property could result.

Important to read and understand at all times

Do not disassemble

Always make sure that the disc does not have a crack before use. If the disc has a crack (especially

around the center hole), it is recommended to make a copy immediately and use the copy instead.

When a cracked disc is used continuously, the size of the crack is likely to grow and this will eventually

result in irreparable damage to the disc.

Safety Precautions

Do not drop the drive, and protect it from severe shocks.

- It can damage the drive or cause it to malfunction.

Do not place the drive in direct sunlight.

Avoid low or high temperature environments.

Avoid high-humidity environments.

During Installation

Handle with caution to prevent damage from external shock.

Do not drop the drive, and protect it from severe shocks.

- It can damage the drive or cause it to malfunction.

Do not move the drive while in operation and do not attempt to open

the disc tray by force.

Make sure to close all working programs before attempting to open the

tray and always use the open/close button.

Do not insert a pin into the emergency opening while in operation.

Do not insert hands in the tray while in operation.

This may cause damage to the product or human body

Do not use cracked, distorted or damaged discs.

In particular, a disc with a crack on the inner tracks may break

while in use.

During Operating

Never allow food particles or foreign substances to enter the drive

casing.

To protect against the risk of fire, do not spill such liquids as

alcohol and benzene on the drive.

Do not disassemble, attempt to repair or modify the device

without express approval as directed in the manual.

- To reduce the risk of damage, electric shock, and fire.

Others

Safety Approval

Regulation Name Country Remark

UL USA UL1950

CSA Canada CSA950, CAN/CSA-C22.2, NO.950-95

TUV Germany EN60950+ALL, EN60825-1 : 1994+ALL

CE EU IEC60825-1 : 1994+All, EN60950 : 1992+A4

CB Certificate World IEC60825, IEC60950

DHHS USA DHHS RULES 21 CFR CHAPTER 1, SUB CHAPTER J

GOST Russia

EMC Compliance

Regulation Name Country Remark

MIC Korea EMI Class B

BSMI TAIWAN CNS 13438(6357), 86.05.257

FCC USA FCC part 15

CE EU EN55022 : 1998, EN55024 : 1998, EN61000-3-2/3 : 1995

Other(Customer's Option)

Regulation Name Country Remark

C-Tick Australia AS/NZS3548 : 1997

SEMKO Sweden EN60950

Regulatory

DVD±R/RW Drive, screw, I/F cable, and audio cable

Blank discs: DVD-R, and DVD+R

Software Programs: Nero Express 6.0, WinDVD Creator, WinDVD Recorder, DVD Copy, In CD, DirectX

9.0, Acrobat Recorder 5.0

We recommend that you use cable that comes with the purchase of the drive for stable performance.

Exterior

You need to have an IBM-compatible PC with the following specifications.

Item Description

OS Microsoft Windows 98/2000/Me/XP(SP 1.0 or higher)

CPU 500MHz or greater IBM-compatible PC

RAM 128Mbytes or greater

HDD Access time 19 msec, transfer speed 6 Gbps or faster

Others Software program for recording for Samsung DVD±R/RW Drive

System Requirements

Versatile Multimedia Features

DVD-R: Read/Write DVD-RW:

Read/Write/Rewritable

DVD+R: Read/Write DVD+RW:

Read/Write/Rewritable

CD+R: Read/Write CD+RW:

Read/Write/Rewritable

Supports Read (playback) for various types of discs

See table below for details

Disc Type Writable Rewritable Read

CD-Stamp × × O

CD-R O × O

CD-RW (O) O O

DVD

DVD-Stamp × × O

DVD-R

4.7GB (FOR GENERAL Ver 2.0) O × O

4.7GB

(FOR AUTHORING : Disc-at Once mode) × × O

3.95GB

(FOR AUTHORING : Disc-at Once mode) × × O

DVD-RW

4.7GB(For General Ver 1.0) × × O

4.7GB(For General Ver 1.1) (O) O O

DVD+R 4.7GB (Basic Ver 1.0) O x O

DVD+RW 4.7GB (Basic Ver 1.1) (O) O O

Writable : write once, read many times.

Rewritable : write data one or more times.

Buffer underrun prevention technology

This technology eliminates Buffer underrun Error

Recommended Disc Types

CD-R Media (16x/8x/4x)

Mitsubishi, Taiyo-Yuden, Mitsui, Ricoh, Fujifilm, Sony, Hitachi Maxell, Memorex, RITEK, CMC, P.V.C,

JVC, SKC, ACER, Prime Disc, TDK

CD-RW Media (10x/4x)

Ricoh, Mitsubishi, ACER, OPTROM, Memorex, P.V.C, RITEK, CMC, LEADDATA, GigaStorage,

Prodisc, Fornex, Sumsung, Philips

DVD-R Media (4x/2x, 4.7GB For General DISC)

Mitsubishi, Taiyo-Yuden, Panasonic, Hitachi Maxell, TDK, PVC, Fuji Film, Ritek, Verbatim

DVD-RW Media (2x/1x)

JVC, Pioneer, Mitsubishi, TDK, Verbatim

DVD+R Media (4x/2.4x)

RICOH, Mitsubishi, TDK, Verbatim, Taiyo-Yuden, Sony, Hitachi Maxell

DVD+RW Media (2.4x)

RICHO, Mitsubishi, TDK, Verbatim

Reading / Recording Speed

Reading Speed(MAX)

DVD-ROM (12x), CD-ROM (40x), DVD-R (5x), DVD-RW (5x), DVD+R (5x), DVD+RW (5x) CD-R

(40x), CD-RW (32x)

Recording Speed(MAX)

DVD-R (4x), DVD-RW (2x), DVD+R (4x), DVD+RW (2.4x),CD-R (16x), CD-RW (10x)

Features

Ultra Speed CD-RW DISC(24X higher) does not support Reading / Recording.

We recommend using the 'Recommended Disc Types'.

When you use the other disc, may affect Reading / Recording of the data.

Features
