16-Channel Stand-Alone Digital Video Recorder
SVR-1630 480fps Live Display & 240fps Recording
POS/ATM Transaction Information Text Recording
Expandable up to 4TB of Storage Capacity
Flexible Backup Solutions : R-HDD, Optional CD-RW, USB
IMSProgram:Monitor&Manageupto32DVRs/512Channels
DualMonitorforSingleChannelMonitoringandPlayback
Utilizing Samsung's renowned digital technology and many years of experience in world's security market,
our engineers have developed a powerful and versatile DVR in a compact solution.
With new video compression technology and increased recording speed integrated with Samsung's new
IMS (Intergrated Management Solution), the SVR-1630 is truly new standard in stand-alone DVR!
Multi-site Monitoring Program
The SVR-1630 supports a wide range of network connections
including LAN and XDSL. Users can conveniently monitor and
manage DVRs from anywhere in the world. Moreover,
Samsung's powerful IMS program (SVR Manager) has an
amazing capacity to connect up to 32 DVRs and manage 512
Channels simultaneously. Some of the features include :
Live & Playback in multi-screen formats.
Search by time / Event
Advanced menu setup
PTZ control
Network backup Remote System Diagnosis
DVRs from remote sites will automatically report any
pre-defined parameters to IMS. Some of the parameters
contain
Poweron/off, Config Changed,
Powerinterupted, Video loss, etc
Frame Rate SetupSVR Manager System log screen
Incorporating the highly efficient Differential Wavelet algorithm, the SVR-1630 achieves exceptional video quality
while maintaining average file size of 5KB. Furthermore, hardware based video processing allows outstanding
recording speed of 240fps which will accommodate all aspects of recording requirement.
As a standard, the SVR-1630 is available with Removable-HDD. As an
option, CD-RW can be supplemented. In addition, the unit also
enables copying of limited files to external USB memory sticks.
The SVR-1630 is pre-equipped with IEEE-1394 port. Therefore, if long-term archiving is required, storage capacity is
easily expandable up to 4TB using optional HDD-Bay (SVR-1630S).
For convenience, the unit adopts FAT32, one of the
major Windows formats. Thus, it is possible to
playback recorded images from external HDDs
through any Windows based PCs.
The Unit is shipped POS - and ATM - ready via RS-232C. POS/ATM transaction information can be archived along
with corresponding video data and is searchable through the use of the SVR manager software.
(This capability makes them particularly suited to venues with cash registers and casinos.)
USB Memory Stick
POS
SVR-1630S HDD-Bay (up to 4EA) IEEE-1394
16 Channel Display Quick Setup
ATM
CD-RWR-HDD
240fps
480fps Live display &240fps Recording
Expandable up to 4TB of Storage Capacity
POS/ATM Transaction Information Text Recording
Flexible Back up Solutions
ATM Receipt
Features SVR-1630
Video Input 16 CH
Video Output Monitor A (Mux) 2 BNC, S-Video, VGA
Monitor B (Spot) 1 BNC
Compression Wavelet
Speed 480 fps
Display Resolution 720 x 486
Multi Screen 1, 4, 9, 16CH
Digital Zoom 2X
Speed 240 fps
Recording Resolution 720 x 243
Type Schedule, Event (Motion, Sensor, Text)
Standard Installed 120GB / 250GB (Selectable)
HDD Expand (Option) 2 HDDs (1 Internal, 1 R-HDD)
Max. 4TB with Extra HDD-Bay (SVR-1630S)
Backup/Copy R-HDD, IEEE-1394, USB, CD-RW (Option)
External Interface 2 IEEE-1394, 1 USB
Serial Interface RS-485/422, RS-232C
Text Data Recording with Images POS / ATM
Alarm Sensor In 16
Relay Out 4
Audio Input / Output 1CH / 1CH
Interface 1 RJ-45 (10/100 Base-T)
Network Protocol TCP/IP, DHCP, PPPoE
S/W SVR Manager
Remote Control Control up to 16 DVRs
OSD (On Screen Display) Multi-language
Temperature Operation 5°C ~ 40°C
Range Storage -10°C ~ 50°C
Dimensions(mm) / Weight 420(W) x 88(H) x 421(D) / Appr. 8Kg (1 HDD)
Power Source / Consumption AC 100-240V~, 50/60Hz / Max. 75W (1 HDD)
Specifications
System Configuration
Dimensions
Front/Rear View
SVR-1630
16-Channel Stand-Alone Digital Video Recorder
Design and specifications are subject to change without notice.
www.samsungcctv.com
I.D-0507
DISTRIBUTEDBY
SAMSUNG OPTO-ELECTRONICS AMERICA, INC.
ELECTRONIC IMAGING DIV.
40 Seaview Drive, Secaucus, NJ 07094, U.S.A
Tel : +1-201-902-0347 Fax : +1-201-902-0429
SAMSUNG OPTO-ELECTRONICS UK, LTD.
Samsung House, 1000 Hillswood Drive,
Hillswood Business Park Chertsey, Surrey KT16 OPS
Tel : +44-1932-45-5308 Fax : +44-1932-45-5325
SAMSUNG TECHWIN MOSCOW OFFICE
Korp 14, 37-A, PR-KT, Lenningradsky,
Moscow 125167, Russia
Tel : +7-95-258-9296, 9298 Fax : +7-95-258-9297
TIANJIN SAMSUNG OPTO-ELECTRONICS CO., LTD.
7 Pingchang Rd., Nankai Dist. Tianjin 300190, P.R China
Tel : +86-22-2761-4724(33821) Fax : +86-22-2761-6514
145-3, Sangdaewon 1-dong, Jungwon-gu,
Seongnam-si, Gyeonggi-do 462-703, Korea
Tel : +82-31-740-8137~8140 Fax : +82-31-740-8145
SAMSUNG TECHWIN CO., LTD.
