Samsung FIRENZE2-R Manuale utente

If there are the Contents not included in this book, please refer to K-zone Service Manual

SAMSUNG R40 FEATURES

SERVICEManual

SENS R40 plus

FIRENZE2-R

NT-R40FYxx/xxx

NP-R40FYxx/xxx

1. Simple & Essential Note PC

-. New ATI technology.

-. Wide and Gloss LCD (15.4")

2. High Performance &

Convenient Management function.

-. High-Performance Dual Core

-. Powerful connectivity.

- Contents -

1. Precautions

1) General After-Sales Service Precautions

2) Safety Precautions

3) Ground

4) Static Electricity Precautions

2. Introduction and Specification

1) Introduction

2) Specification

3) Specification comparison between R50 and R65.

4) Wireless LAN Specification

5) Option list

6) The seperate sale list

3. Function

1) Construction of System

2) Keyboard

3) MIO

4) Multi Card Slot

5) PC Card Slot

6) Description of Main board

4. Disassembly and Reassembly

1) Disassembly and Reassembly of R40

5. Troubleshooting

1) General

2) Debugging Flow Chart

3) System Diagnosis

4) Hardware Troubleshooting

5) Device Settings Related Software Diagnosis

6) CPU Fan Control Problems

7) Battery Use Time

6. Exploded view

1) Exploded view of R40 plus

7. Schematic

1) SYSTEM

8. System Block Diagram

1) Block diagram

9. System Wire Diagram

1) R40 plus System

2) LCD

10. Part list

1) SYSTEM

11. References

1) Model Numbering Rule

2) CPU Code table

3) Glossary

4) Hardware Upgrade

- This Document can not be used without Samsung's authorization -

2- 1

2. Introduction and Specification

1) Introduction

(1) High Performance Note PC

- Intel® Core™ 2 Duo Processor

- Intel® Core™ Duo Processor

- Intel® Pentium Dual Core™ Processor

- Intel® Celeron® M Processor

-Wireless LAN (Option), Bluetooth (Option).

(2)ConvenientAV

-Offer of Integrated Multi-Media Program, AVStation.

Users can enjoy Music, Picture and Movie with AVStation conveniently.

(3) Prudent Design for easy use.

-MIO button and Hotkey to execute rapidly.

-Use of Various memory card through Multi card slot

-Good feeling and design through the Flat type touchpad.

- This Document can not be used without Samsung's authorization -

2- 2

2. Introduction and Specification

2) Specification

Processor and Motherboard P50 / R65

CPU

Intel® Core™ 2 Duo Processor

Intel® Core™ Duo Processor

ntel® Pentium Dual Core™ Processor

Intel® Celeron® M Processor

Intel® Core™ 2 Duo Processor

Intel® Core™ Duo Processor

Intel® Pentium Dual Core™ Processor

Intel® Celeron® M Processor

Speed

4MB (Core2 Duo T7xxx)

2MB (Core2 Duo T5xxx ~ Core Duo T2xxx)

1MB (Pentium Dual Core, Celeron M)Intel Celeron M Processor (1.60GHz)

Intel Dual Core Processor T2300(1.66GHz) ~ T2700(2.33GHz)

Cache 4MB (Core2 Duo T7xxx)

2MB (Core2 Duo T5xxx ~ Core Duo T2xxx)

1MB (Pentium Dual Core, Celeron M)

Chipset RC410MD/ME + SB450

BIOS 8 Mbit, Flash upgradable

Thermal Design Performance MAX. 38W

Memory 　

Memory/Max.Memory 512MB / Max.4GB

Memory type PC2-4200(533MHz) / PC2-5300(667MHz)

DDR2 SODIMM

Memory Modules 256MB, 512MB, 1GB SODIMM

Sockets 2-slot SODIMM's

Display and Graphics

LCD 15.4" WXGA (Glare/Non-Glare)

LCD Vendor

Samsung AMLCD (LTN154X3-L03)

AU LCD(B154EW02)

CPT LCD(CLAA154WB05A)

15.4" WXGA

LCD Size 344x222x6.2mm(HxVxT)

LCD Viewable Area 331.2 x 207.0mm (HxV)

LCD Resolution 1,280 x 800 x 262,144 color (32bit)

Dot Pitch 0.25875 x 0.25875mm (HxV)

Contrast Ratio typ. 300:1

Brightness typ. 200 (cd/m2)

Weight typ. 550g

Response time typ. 25msec

- This Document can not be used without Samsung's authorization -

2- 3

2. Introduction and Specification

Graphics Controller　ATI Radeon Xpress 1250M

ATI ATI RS600ME

Video Memory 32MB / 256MB

Max.Resolution for LFP LVDS 1,280 x 800 x 32Bits color (WXGA)

Max.Resolution for External

Monitor 1,920 x 1,440 (CRT)

Max.Resolution for LFP LVDS 1400 * 1050 x 32Bits color (SXGA+)

Audio

Sound Azalia

Controller Realtek ALC262C

Conversion Built-in high performance 20-bit ADC & 24-bit DAC

Internal Interfaces Embedded 2 stereo speakers

Speaker Power Rating 2 Speakers x 2 Watt with enclosure each

External Interfaces Microphone, Headphone

Controls Keyboard volume control, EDS enable / disable

Storage

Hard Disk Drive 9.5mmH 2.5" HDD, Removable

Supports SMART UltraDMA-33/66/100 support

Average Access Time 13m sec.

Speed 5400rpm/SATA

Capacity 60 / 80 / 100 / 120 / 160 GB (5400rpm, 9.5mmH 2.5" HDD SATA)

Optical Disk Drive DVD / Combo / Super Multi DUAL LAYER (12.7mm)

Type Fixed type (Factory Option)

S/W supplied Power DVD Player , Burning function in Windows XP

Security RPC-II Regional Encoding

Optical Driver Modules

DVD ROM Drive 1 Factory Option(ONLY FOR KOR)

Module type Fixed 12.7mm Slim

Speed 24x CD :

TEAC,

DV-28EN

Average Access Time CD 110ms Typ

Weight 165g or less

- This Document can not be used without Samsung's authorization -

2- 4

2. Introduction and Specification

Combo Drive 2 Factory Option

Module type Fixed 12.7mm Slim

Speed 8x DVD-ROM, 24x RW, 24x CD-R, 24x CD :

Teac, DW-224E-C

Average Access Time DVD 110ms Typ., CD 90ms Typ.

Weight 190g or less

S/W supplied Power DVD Player (5.0), Nero Burning or equivalent S/W

Security RPC-II Regional Encoding

Super Multi Dual Layer 1 Factory Option

Module type Fixed 12.7mm Slim

Speed 5x DVD-RAM, 8x DVD±R 2.4x DVD+R DL, 4x DVD±RW,24x CD-R,

16x CD-RW, 8x DVD, 24x CD : TEAC DV-W28EA

Average Access time DVD 130ms Typ., CD 130ms Typ.

Weight 190g or less

S/W supplied Power DVD Player (5.0), Nero Burning or equivalent S/W

Security RPC-II Regional Encoding

Super MultiDual Layer 2 Factory Option

Module type Fixed 12.7mm Slim

Speed 5x DVD-RAM, 8x DVD±R 2.4x DVD+R DL, 4x DVD±RW,24x CD-R,

10x CD-RW, 8x DVD, 24x CD : Matsubshita UJ-840B

Average Access Time DVD 180ms Typ., CD 150ms Typ.

Weight 190g±10g

S/W supplied Power DVD Player (5.0), Nero Burning or equivalent S/W

Security RPC-II Regional Encoding

Network Tools

Fax/Modem 56Kbps / V.92 Azalia Modem

Chipset SV92A1

Features RJ11 Output

LAN 10/100 Ethernet UTP (Factory option)

Chipset Broadcom BCM4401

Features RJ45 Output

802.11bg Wireless LAN Atheros

Type Minicard

Chipset Atheros

Antenna Integrated 1 Antenna

Bluetooth BCM92045NMD : Factory Option

Type USB daughter card with integrated PIFA antenna

Chipset Broadcom BCM2045

Standard version 2.0

- This Document can not be used without Samsung's authorization -

2- 5

2. Introduction and Specification

I/O Interface

PC CardBus Slots 1 PCMCIA Type II slot

Controller Ricoh R5C843

Support 32bit CardBus cards

I/O Ports 　

USB Port 4(USB2.0)

Video Port 1

TV-out connector S-VHS

Audio Jacks HeadPhone-out ,Optical S/PDIF, MIC-in

Modem / LAN RJ11, RJ45

Power 1(5pie)

Input Devices 　

Key board 88KEY(KR/US), 89KEY(UK/FR/GM/SP)

　Travel length 2.6mm/ Key Pitch 19.05mm

Touchpad Synaptics Touchpad (Plat type with Scroll area)

Easy Button User setting button (default AVS premium)

Multi Memory Card Slot 1slot

Controller Ricoh R5C843

Type Memory stick / Memory stick pro / SD / xD / MMC (High speed MMC)

Special Feature

AV Station Premium

OS Windows XP / Windows VISTA

Function DVDplayer/MP3player/Pictureslideshow

Control Button Keyboard & Touchpad, Easy Button for direct access

Power and Power Management

Battery

Dimension 204 x 48 x 20mm

Weight 350g (max)

Recharge Time 2 hours to 100% with Windows on & off

Battery Life -

Details of Cell 6cells (2Parallel 3Serial)

Voltage 11.1Vdc

Battery Capacity 4000mAh/cell

Battery Rating 11.1V / 4000mAh (44.4Wh)

AC Adapter AD-6019S AD-9019S

Output Power 60 Watts 90 Watts

Dimension 108 x 46.5 x 28mm L126*W50*H30

Weight (AC Adapter) 320g (max)

Worldwide Compatibility Auto-sensing 100 - 240VAC Auto-sensing 100 - 240VAC

2. Introduction and Specification

- This Document can not be used without Samsung's authorization -

2- 6

Line Frequency 50 / 60Hz 50 / 60Hz

Adapter Rating - Input 100V - 240V, 1.4A 100V - 240V, 1.4A

Adapter Rating - Output 19.0VDC / 3.16A 19.0VDC / 4.74A

Power Management Features ACPI 1.0b support, Standby(S3),

Hibernate(S4) ACPI 1.0b support, Standby(S3),

Hibernate(S4)

System Dimensions

Dimensions (W X D X H) 360 x 264.5 x 26.1~37.1mm

Weight 2.7kg

　Status : No options, 6cell battery, 15.4" LCD

Materials PC/ABS

- This Document can not be used without Samsung's authorization -

2- 7

2. Introduction and Specification

3) Specification comparison between R50 and R40

Model name R50 R40


CPU 533MHz Pentium M 533/667MHz Pentium M (Merom,Yonah)

Chipset Intel 915 ATI RS600ME

Memory DDR2 400 / 533MHz DDR2 533 / 667MHz

(MAX 4GB)

Graphics Intel 915GM ATI Radeon Xpress 1250M

(2nd Vendor Chipset)

LCD 15.4” 15.4”

HDD PATA / SATA 2.5" SATA

ODD 12.7mm 12.7mm

Port 4 USB, IEEE1394, S-video, RJ45, RJ11,

CRT, PC-card

4USB, SVHS, RJ45, RJ11, CRT, PC-card,

BT(option)

Battery 6cell 신규 6cell

- This Document can not be used without Samsung's authorization -

2- 8

2. Introduction and Specification

4) Wireless LAN Specification

(1) Wireless LAN Standard (802.11BG card)

Atheros Wireless Network Adapter

2. Introduction and Specification

- This Document can not be used without Samsung's authorization -
