Samsung NP930MBE-K01US Manuale utente

www.samsung.com

User Manual

Getting started

3 About this manual

7 Layout

13 Turning the computer on

and off

15 Unlocking the screen

15 Windows

Basics

17 Using the computer as a

tablet

19 Using the Active Pen

(optional)

26 Touch screen (optional)

31 Keyboard

33 Touchpad

36 Fingerprint recognition

39 Memory card slot

41 External display

43 Wireless LAN

45 Bluetooth

47 Thunderbolt™3

Applications

49 Using applications

50 Samsung Settings

51 Samsung Security

53 Samsung Update

54 Online Support (S Service)

55 Samsung PC Help

(Self-help application)

56 Samsung PC Cleaner

Settings & Upgrade

57 LCD brightness

59 Volume

60 BIOS (Setup utility)

66 Battery

Troubleshooting

69 Samsung Recovery

74 Windows recovery

function

74 Q&A

Appendix

77 Product specifications

78 Ergonomic tips

82 Safety precautions

92 Important safety

information

95 Replacement parts and

accessories

98 Regulatory compliance

statements

106 WEEE symbol information

108 Samsung package Take-

Back program

Table of contents

Getting started

About this manual

•

This user manual is specially designed to detail the computer’s

functions and features.

•

The user manual supplied with the computer may vary

depending on the model.

•

Please read this manual before using the computer to ensure

safe and proper use.

•

Optional accessories, some devices, and software referred to

in this manual may not be provided or may not be subject to

upgrades. Note that the computer environment referred in

the user manual may not be the same as your environment.

•

Descriptions are based on the computer’s default settings

and the Windows 10 operating system. Available features and

additional services may vary depending on the computer or

operating system.

•

This user manual describes procedures for using the

touchpad, mouse and touch screen. Instructions for using the

touch screen are for models with the touch screen feature.

•

Images and screenshots are those of the representative model

of the series and may differ in appearance from the actual

product.

•

Content may differ from the final product and is subject to

change without prior notice. For the latest version of the

manual, refer to the Samsung website, www.samsung.com.

Getting started

This manual is protected under international copyright laws.

No part of this manual may be reproduced, distributed, translated,

or transmitted in any form or by any means, electronic or

mechanical, including photocopying, recording, or storing in any

information storage and retrieval system, without the prior written

permission of Samsung Electronics.

Computer specifications or the contents of this manual may

be changed without prior notice due to an upgrade of the

computer’s functions.

Instructional icons and expressions

Warning

: situations that could cause injury to yourself or

others

Caution

: situations that could cause damage to the

computer or other equipment

Note

: notes, usage tips, or additional information

The path you should follow to carry out an instruction. For

example, “select

Settings

→

Devices

”indicates that you

should select

Settings

and then

Devices

Select Click the mouse or tap the touchpad or touch screen.

Getting started

•

HDMI, the HDMI logo, and

the term High Definition

Multimedia Interface are

trademarks or registered

trademarks of HDMI Licensing

LLC.

•

Thunderbolt and the Thunderbolt logo are trademarks of Intel

Corporation in the U.S. and/or other countries.

•

All other trademarks and copyrights are the property of their

respective owners.

As an ENERGY STAR®Partner,

Samsung has determined that this

product meets the ENERGY STAR®

guidelines for energy efficiency.

•

The ENERGY STAR Program has reduced greenhouse gas

emissions and saved energy through voluntary labeling.

•

Power management setting of this product has been enabled

by default, and has various timing settings from 1 minute to

5 hours.

•

The product can wake with a button press on the chassis from

sleep mode.

Trademarks

•

Samsung and the Samsung logo are trademarks or registered

trademarks of Samsung Electronics.

•

Intel and Core are trademarks or registered trademarks of the

Intel Corporation.

•

Microsoft, MS-DOS, and Windows are trademarks or registered

trademarks of the Microsoft Corporation.

•

Bluetooth®is a registered trademark of Bluetooth SIG, Inc.

worldwide.

•

Wi-Fi®, Wi-Fi Protected Setup™, Wi-Fi Direct™, Wi-Fi

CERTIFIED™, and the Wi-Fi logo are registered trademarks of

the Wi-Fi Alliance.

Getting started

Product capacity representation

Storage capacity representation

The capacity of the storage device (HDD, SSD) of the manufacturer

is calculated assuming that 1 KB = 1,000 Bytes.

However, the operating system (Windows) calculates the storage

device capacity assuming that 1 KB = 1,024 Bytes. Therefore, the

available capacity of the HDD in Windows is smaller than the

actual capacity due to the difference in capacity calculation. For

example, for an 80 GB HDD, Windows calculates the capacity as

74.5 GB, (80x1,000x1,000x1,000) Bytes/(1,024x1,024x1,024) Bytes

= 74.505 GB.

In addition, the capacity representation in Windows may be even

smaller because some programs, such as Samsung Recovery, may

reside in a hidden area of the HDD.

Memory capacity representation

The available memory capacity in Windows is less than the actual

capacity of memory. This is because some memory is required for

regular system operations.

For example, for 1 GB (= 1,024 MB) memory installed, Windows

may report the capacity as 1,022 MB or less.

Data precautions

Samsung Electronics shall not be liable for any data loss. Please

take care to avoid losing any important data and back up your

data to prevent any such data loss.

Operating system and software support

If you change the product’s factory OS (Operating System) to

another OS or if you install software which is not supported by the

product’s original factory OS, you will not receive any technical

support, product exchange or refund, and a fee will be charged

when requesting a service.

Please use your computer with the original factory OS. If you

install an OS other than the factory OS, data may be deleted or the

computer may not start.

* Please use Windows 10 64-bit only for this model.

Getting started

Layout

•

Features or options may differ depending on the model.

•

The items marked as optional may not be provided or

may be provided in different locations.

•

Since some space on the SSD is reserved for system

recovery and operations, the available space on the SSD

may be less than the actual capacity.

•

Images and screenshots may differ from the actual

appearance of the product.

Getting started

Number/Name Description

Microphone

•

You can use the built-in

microphone.

Camera indicator

light

•

This indicates the camera

operating status.

Camera

•

Using this camera, you can take

still pictures and record video.

LCD/Touch screen

(optional)

•

The screen’s images are displayed

here.

•

Recognizes touch interactions

(Only for touch screen models).

Operating

status LED and

Illumination

sensor (optional)

•

Shows the operating status of the

computer.

Keyboard

•

Enter text or control computer

functions.

Touchpad

•

Moves the cursor and selects

options.

•

Functions as a mouse.

Front view

Getting started

Number/Name Description

Operating status

LED

•

Shows the operating status of the

computer.

–

Red

: Charging

–

Green

: Fully charged

–

Blue

: Turned on

Illumination

sensor (optional)

•

The sensor detects the ambient

light.

•

If the ambient light level becomes

too low, the computer’s backlight

will automatically turn on.

•

If there is sufficient ambient

lighting, the computer’s backlight

will automatically turn off.

•

Do not block the sensor.

Operating status LED and Illumination

sensor

Getting started

Number/Name Description

Memory card slot

•

Insert a memory card into the slot.

Power button/

Fingerprint

recognition

sensor

•

Turns the computer on and off.

•

The fingerprint recognition sensor

recognizes fingerprints. You can

unlock the screen with your

fingerprint.

USB-C™port

•

This port allows the USB PD AC

adapter to be used to supply

power to the computer. It can also

be used to charge USB-C devices

or to connect external display

devices.

•

When you register your fingerprint, make sure to cover

the entire fingerprint recognition sensor with your

finger.

•

To scan as much of the fingerprint as possible, cover the

fingerprint recognition sensor with your finger.

•

Make sure not to press the Power button when you

connect an external device, such as a USB, to the

USB-C™port.

Right view

21 3
