User Manual

NT550XDA/NT550XDZ/NT551XDA

/NP550XDA/550XDA/550XDZ

Getting started

3 About this manual

7 Layout

12 Turning the computer on

and off

14 Unlocking the screen

14 Windows

Basics

16 Keyboard

18 Touchpad

21 Memory card slot

23 External display

25 Wired LAN

28 Wireless LAN

30 Bluetooth

32 Using the security slot

Applications

33 Using applications

34 Samsung Settings

35 Samsung Security

37 Online Support (S Service)

38 Samsung PC Help (Self-

help application)

39 Samsung PC Cleaner

40 Quick Search

Settings & Upgrade

41 LCD brightness

43 Volume

44 BIOS (Setup utility)

50 Battery

Troubleshooting

53 Samsung Recovery

58 Windows recovery

function

58 Q&A

Appendix

61 Product specifications

62 Ergonomic tips

66 Safety precautions

76 Important safety

information

79 Replacement parts and

accessories

82 Regulatory compliance

statements

90 WEEE symbol information

92 Samsung package Take-

Back program (USA only)

Table of contents

Getting started

About this manual

•

This user manual is specially designed to detail the computer’s

functions and features.

•

The user manual supplied with the computer may vary

depending on the model.

•

Please read this manual before using the computer to ensure

safe and proper use.

•

Optional accessories, some devices, and software referred to

in this manual may not be provided or may not be subject to

upgrades. Note that the computer environment referred in

the user manual may not be the same as your environment.

•

Descriptions are based on the computer’s default settings

and the Windows 10 operating system. Available features and

additional services may vary depending on the computer or

operating system.

•

This user manual describes procedures for using the

touchpad, mouse and touch screen. Instructions for using the

touch screen are for models with the touch screen feature.

•

Images and screenshots are those of the representative model

of the series and may differ in appearance from the actual

product.

•

Content may differ from the final product and is subject to

change without prior notice. For the latest version of the

manual, refer to the Samsung website, www.samsung.com.

Getting started

This manual is protected under international copyright laws.

No part of this manual may be reproduced, distributed, translated,

or transmitted in any form or by any means, electronic or

mechanical, including photocopying, recording, or storing in any

information storage and retrieval system.

Computer specifications or the contents of this manual may

be changed without prior notice due to an upgrade of the

computer’s functions.

Instructional icons and expressions

Warning

: situations that could cause injury to yourself or

others

Caution

: situations that could cause damage to the

computer or other equipment

Note

: notes, usage tips, or additional information

The path you should follow to carry out an instruction. For

example, “select

Settings

→

Devices

”indicates that you

should select

Settings

and then

Devices

Select Click the mouse or tap the touchpad or touch screen.

Getting started

•

HDMI, the HDMI logo, and

the term High Definition

Multimedia Interface are

trademarks or registered

trademarks of HDMI Licensing

LLC.

•

All other trademarks and copyrights are the property of their

respective owners.

As an ENERGY STAR®Partner,

Samsung has determined that this

product meets the ENERGY STAR®

guidelines for energy efficiency.

•

The ENERGY STAR Program has reduced greenhouse gas

emissions and saved energy through voluntary labeling.

•

Power management setting of this product has been enabled

by default, and has various timing settings from 1 minute to

5 hours.

•

The product can wake with a button press on the chassis from

sleep mode.

Trademarks

•

Samsung and the Samsung logo are trademarks or registered

trademarks of Samsung Electronics Co., Ltd.

•

Intel and Core are trademarks or registered trademarks of the

Intel Corporation.

•

Microsoft, MS-DOS, and Windows are trademarks or registered

trademarks of the Microsoft Corporation.

•

Bluetooth®is a registered trademark of Bluetooth SIG, Inc.

worldwide.

•

Wi-Fi®, Wi-Fi Direct™, Wi-Fi CERTIFIED™, and the Wi-Fi logo

are registered trademarks of the Wi-Fi Alliance.

Getting started

Product capacity representation

Storage capacity representation

The capacity of the storage device (HDD, SSD) of the manufacturer

is calculated assuming that 1 KB = 1,000 Bytes.

However, the operating system (Windows) calculates the storage

device capacity assuming that 1 KB = 1,024 Bytes. Therefore, the

available capacity of the HDD in Windows is smaller than the

actual capacity due to the difference in capacity calculation. For

example, for an 80 GB HDD, Windows calculates the capacity as

74.5 GB, (80x1,000x1,000x1,000) Bytes/(1,024x1,024x1,024) Bytes

= 74.505 GB.

In addition, the capacity representation in Windows may be even

smaller because some programs, such as Samsung Recovery, may

reside in a hidden area of the HDD.

Memory capacity representation

The available memory capacity in Windows is less than the actual

capacity of memory. This is because some memory is required for

regular system operations.

For example, for 1 GB (= 1,024 MB) memory installed, Windows

may report the capacity as 1,022 MB or less.

Data precautions

Samsung Electronics shall not be liable for any data loss. Please

take care to avoid losing any important data and back up your

data to prevent any such data loss.

Operating system and software support

If you change the product’s factory OS (Operating System) to

another OS or if you install software which is not supported by the

product’s original factory OS, you will not receive any technical

support, product exchange or refund, and a fee will be charged

when requesting a service. Please use your computer with the

original factory OS.

If you install an OS other than the factory OS, data may be deleted

or the computer may not start.

* Please use Windows 10 64-bit only for this model.

Getting started

Layout

•

Features or options may differ depending on the model.

•

The items marked as optional may not be provided or

may be provided in different locations.

•

Since some space on the SSD is reserved for system

recovery and operations, the available space on the SSD

may be less than the actual capacity.

Getting started

Number/Name Description

Camera indicator

light

•

This indicates the camera

operating status.

Microphone

•

You can use the built-in

microphone.

Camera

•

Using this camera, you can take

still pictures and record video.

LCD

•

The screen’s images are displayed

here.

Operating status

LED

•

Shows the operating status of the

computer.

–

Blue

: Turned on

Power button

•

Turns the computer on and off.

Keyboard

•

Enter text or control computer

functions.

Touchpad

•

Moves the cursor and selects

options.

•

Functions as a mouse.

Front view

Getting started

Number/Name Description

Memory card slot

•

Insert a memory card into the slot.

USB 2.0 port

•

Connect various peripheral

devices, such as a mouse, camera,

or keyboard.

Security slot

•

Secure the computer by

connecting an optional lock and

cable to it.

Right view

Getting started

Number/Name Description

DC jack

•

This jack connects to the AC

adapter to supply power to the

computer.

Wired LAN port

•

Connect the Ethernet cable to this

port.

HDMI port

•

Used to connect an HDMI cable to

an external device.

USB 3.0 port

•

Connect various peripheral

devices, such as a mouse, camera,

or keyboard.

USB-C®port

•

This port can use USB-C®devices,

charge external devices, or to

connect external display devices.

Earpiece/

Headset jack

•

Connect an earpiece or a headset

to the computer to listen to audio.

Left view

1 2 3 64 5
