Samsung LN26C450E1D Manuale utente

2010 Samsung TV

F/W Upgrade Guide

Samsung Electronics

Model List

LCD TV

4 series :

LN26C450E1D, LN32C450E1D, LN32C450E1V

5 series :

LN32C530F1F, LN32C540F2D, LN32C540F2F, LN32C550J1F,

LN37C530F1F, LN37C550J1F, LN40C530F1F, LN40C540F2F,

LN40C550J1F, LN46C530F1F, LN46C540F2F, LN46C550J1F,

LN52C530F1F

LED TV

4000 series :

UN19C4000PD, UN22C4000PD, UN22C4010PD, UN26C4000PD,

UN32C4000PD

5000 series :

UN32C5000QF, UN32C5100QF, UN37C5000QF,UN37C5100QF,

UN40C5000QF, UN40C5100QF, UN46C5000QF

Step1. How to prepare the USB Memory Drive

2. Connect the USB Memory Drive

to the USB port of your PC.

Copy the file onto the USB Memory Drive.

3. Go to the USB Memory Drive and then double click the file.

1. Save the firmware file onto your computer.

File Name : T-TDT5AUSC and T-MSX5AUSC.exe

4. Click on the “Unzip” button. 5. Unzipping is in progress.

6. After completing, click on the

“OK” and “Close” buttons.

7. A folder containing the firmware files

has been added to the USB memory drive.

Folder name : T-TDT5AUSC and

T-MSX5AUSC

8. Safely disconnect the USB memory drive

by right clicking the green check mark

on the taskbar and then left click

“Safely Remove”.

OK

[Step 1] Turn the TV on

[Step 2] Insert the USB Memory Drive

containing the Software into the USB port

on the side (or rear) of the TV

Step2. How to upgrade the firmware

[Step 3] Press the MENU button to display

the menu. Press the ▲or ▼button

to select “Support”, then press the

ENTER button

[Step 4] Press the ▲or ▼button to select

“Software Upgrade”, then press the

ENTER button

[Step 5] The message “Scanning for USB.

It may take up to 30 seconds”

is displayed.

[Step 6] Then, the message “Upgrade

Version XXXX to version XXXX?

The system will be reset after

upgrade.” is displayed.

Select “Yes”, then press the ENTER

button.

And then software is upgraded

automatically.

[Step 7] When the Software upgrade

is complete; the TV will turn off and

then back on by itself.
