E-MANUAL

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at

www.samsung.com

M o d e l __________________ S e r i a l N o . __________________

To directly go to the page that provides instructions

on how to use the manual for visually impaired

users, select the Menu Learning Screen link below.

“Menu Learning Screen” Link

English

Connecting Video Devices

19 Connecting with an HDMI cable

19 Connecting with a component cable

20 Connecting with a composite (A/V) cable

21 Connecting with a component cable (Only for models with

COMPONENT IN / AV IN)

22 Connecting with a composite cable (Only for models with

COMPONENT IN / AV IN)

Audio Input and Output Connections

23 Connecting with an HDMI (ARC) cable

23 Connecting with a digital audio (optical) cable

23 Connecting through a wireless network

Connecting a Computer

24 Connecting through the HDMI port ― Screen Sharing (HDMI)

Connecting Your Mobile Device

25 Connecting to the TV via the SmartThings app

26 Bidirectionally mirroring your TV and mobile device using the

SmartThings app

26 Managing a Mobile Device

Switching between external devices connected to the TV

27 Changing the input signal

27 Editing the name and icon of an external device

28 Using additional functions

Connection Notes

28 Connection notes for HDMI

29 Connection notes for audio devices

30 Connection notes for computers

30 Connection notes for mobile devices

Quick Guides

Using Smart Hub

Updating the TV’s Software

9 Updating the TV’s software to the latest version

9 Updating the TV automatically

Getting Support

10 Getting support through Remote Management

11 Finding the contact information for service

11 Requesting service

Connections

Connection Guide

Connecting an Antenna (Aerial)

Connecting to the Internet

14 Connecting to your Internet network

16 Checking the Internet connection status

16 Resetting Your Network

16 Turning on the TV with a Mobile Device

16 Connecting an IP control device to the TV

17 Setting up an Internet connection over IPv6

17 Changing the name of the TV on a network

Troubleshooting Internet Connectivity Issues

17 Troubleshooting Internet connectivity issues

Contents

Using the Gallery App

Using the Universal Guide App

Using the SmartThings App

Using the e-Manual

51 Launching the e-Manual

52 Using the buttons in the e-Manual

Using the Internet

Playing pictures/video/music

54 Playing media content

TV Viewing

Viewing Digital Broadcast Information at a Glance

55 Using the guide

Setting Up a Schedule Viewing

56 Setting up a schedule viewing for a channel

57 Editing a schedule viewing

Using the Channel List

Editing channels

59 Removing registered channels

59 Editing registered channels

Creating a Personal Favourites List

60 Registering channels as favourites

61 Viewing and selecting channels on Favourites lists only

Editing a Favourites List

61 Adding channels to favourites list

61 Removing channels from a favourites list

61 Rearranging a favourites list

61 Renaming a favourites list

Peripherals

Using Anynet+ (HDMI-CEC)

31 Connecting an external device through Anynet+ and using

their menus

Controlling the TV with a Keyboard or Mouse

32 Connecting a USB keyboard or mouse

32 Using the keyboard and mouse

33 Setting up the input devices

Entering Text using the On-Screen Virtual Keyboard

Smart Features

Smart Hub

36 Displaying the Home Screen

40 Launching Smart Hub automatically

40 Launching the last used app automatically

40 Testing Smart Hub connections

40 Resetting Smart Hub

Using a Samsung account

41 Creating and managing your Samsung account

42 Signing in to a Samsung account

Using the Apps Service

45 Installing and running an app

46 Managing purchased or installed apps

47 Rating apps

Picture and Sound

Adjusting the Picture Quality

69 Choosing a picture mode

70 Configuring advanced picture settings

Setting the Viewing Environment for External Devices

71 Playing games on an optimised screen

71 Using HDMI black level

Picture Support Functions

72 Changing the picture size

72 Changing the picture size automatically

72 Changing the picture size in 4:3 or Screen Fit mode

73 Fitting the picture to the screen

73 Adjusting the picture size and/or position

Configuring a Sound Mode and Expert Settings

73 Choosing a sound mode

74 Configuring advanced sound settings

Using the Sound Support Functions

75 Selecting speakers

75 Listening to the TV through a Samsung audio device that

supports the Wi-Fi function

TV-Viewing Support Functions

62 Changing the broadcast signal

62 Scanning for available channels

63 Checking digital channel signal info and strength

63 Restricting Viewing to Specific Channels

63 Using Mark Adult Channels

63 Selecting the broadcasting audio option

64 Using Programme Rating Lock

64 Configuring advanced broadcasting settings

64 Reading digital text

65 Selecting the broadcast audio language

65 Tuning broadcast signals manually

66 Fine-tuning analogue broadcasts

66 Transferring channel list

66 Enabling/Disabling Edit Channel Numbers

67 Deleting CAM operator profile

67 Setting satellite system

67 Changing teletext language

67 Showing TVkey Interface menu

68 Showing common interface menu

Using a TV Viewing Card (“CI or CI+ Card”)

86 Connecting the “CI or CI+ Card” via COMMON INTERFACE slot

with the CI CARD Adapter

87 Connecting the “CI or CI+ Card” via COMMON INTERFACE slot

87 Using the “CI or CI+ Card”

Teletext Feature

90 Typical Teletext page

Troubleshooting

Getting Support

91 Getting support through Remote Management

92 Finding the contact information for service

92 Requesting service

Diagnosing TV operational issues

There Is a Problem with the Picture

93 Testing the picture

I Can't Hear the Sound Clearly

96 Testing the sound

There Is a Problem with the Broadcast

My Computer Won't Connect

The TV Won't Connect to the Internet

Anynet+ (HDMI-CEC) Isn't Working

I Have Trouble Launching/Using Apps

My File Won't Play

I Want to Reset the TV

Other Issues

System and Support

Using the Time Functions and the Timers

76 Setting the current time

77 Using the timers

Using the Auto Protection Time and Energy Saving Functions

78 Setting the Auto Protection Time

78 Reducing the energy consumption of the TV

Updating the TV’s Software

79 Updating the TV’s software to the latest version

79 Updating the TV automatically

Protecting the TV from Hacking and Malicious Code

80 Scanning the TV and connected storage for malicious code

Using Other Functions

80 Running the accessibility functions

80 Running Accessibility Shortcuts

81 Enabling voice guides for the visually impaired

81 Audio Description

82 White text on black background (high contrast)

82 Enlarging the font (for the visually impaired)

82 Learning about the remote control (for the visually impaired)

82 Learning about the TV menu

83 Watching TV broadcasts with subtitles

83 Configuring advanced system settings

84 Restoring the TV to the factory settings

HbbTV

Precautions and Notes

Supported broadcasting audio options

Read Before Using Apps

Read Before Using the Internet

107 Read before setting up a wireless Internet connection

Read Before Playing Photo, Video, or Music Files

108 Limitations on use of photo, video, and music files

109 Supported external subtitles

109 Supported internal subtitles

110 Supported image formats and resolutions

110 Supported music formats and codecs

111 Supported video codecs

Read After Installing the TV

113 Picture sizes and input signals

113 Installing an anti-theft lock

Read Before Connecting a Computer (Supported Resolutions)

114 Full HD TV

114 IBM

114 MAC

115 VESA DMT

116 HD TV

116 IBM

116 MAC

117 VESA DMT

Supported Resolutions for Video Signals

118 VESA CVT

118 CEA-861

Buttons and functions available while playing multimedia

content

Licences & Other Information

Accessibility Guidance

Menu Learning Screen

Using the accessibility menu

122 Accessibility Shortcuts menu

123 Step by Step instructions to run the options

Using the TV with Voice Guide on

125 Watching TV

Using the guide

Setting Up a Schedule Viewing

129 Cancelling a scheduled viewing

Using the Channel List

131 Creating a Personal Favourites List

Using Smart Hub

133 Smart Hub

134 Using the Home Screen in Smart Hub

Launching the e-Manual

- 7 -

Quick Guides

You can learn quickly how to run and use the frequently used functions.

Using Smart Hub

Connect to Smart Hub for apps, games, movies, and more.

Enjoy the multiple functions provided by Smart Hub simultaneously on a single screen.

Sources

TV HDMI 1 HDMI 2 USB 1 USB 2 Connection

Guide

Source

"The image on your TV may differ from the image above depending on the model and geographical area.

When you press the button on your remote control, you can use the following functions and features.

1 Notification

You can view a list of notifications for all events that occur on your TV. A notification appears on the screen when it is

time to broadcast a scheduled programme or when an event occurs on a registered device.

"For more information, refer to "Displaying the Home Screen".

- 8 -

2 Settings

When the focus is moved to the icon, a list of quick settings icons appears above the top of the menu. You can

quickly set frequently used functions by clicking the icons.

3 Source

You can select an external device connected to the TV.

"For more information, refer to "Switching between external devices connected to the TV".

4 Search

You can search for channels, programmes, movie titles, and apps from Smart Hub.

"To use this feature, the TV must be connected to the Internet.

5 APPS

You can enjoy a wide range of content including news, sports, weather, and games by installing the corresponding

apps on your TV.

"To use this feature, the TV must be connected to the Internet.

"For more information, refer to "Using the Apps Service".

6 Universal Guide

Universal Guide is an app that allows you to search for and enjoy various content such as TV shows, dramas, and

movies in one place. Universal Guide can recommend content tailored to your preferences and notify you of new

drama series.

"For more information about the Universal Guide, refer to "Using the Universal Guide App".

"Images may look blurry depending on the service provider's circumstances.

"This function may not be supported depending on the model or geographical area.

- 9 -

Updating the TV’s Software

View your TV's software version and update it if necessary.

Settings Support Software Update Try Now

Updating the TV’s software to the latest version

[ DO NOT turn off the TV’s power until the update is complete. The TV will turn off and on automatically after

completing the software update. Video and audio settings will be reset to their defaults after a software

update.

Updating through the Internet

Settings Support Software Update Update Now Try Now

"Updating from the Internet requires an active Internet connection.

Updating through a USB device

Settings Support Software Update Update Now

After downloading the update file from the Samsung website and storing it on a USB device, connect the USB device

to the TV to update.

"To update using a USB flash drive, download the update package from Samsung.com to your computer. Then, save the

update package in the USB device's top-level folder. Otherwise, the TV will not be able to locate the update package.

Updating the TV automatically

Settings Support Software Update Auto update Try Now

If the TV is connected to the Internet, you can have the TV update its software automatically while you are watching

the TV. When the background update is completed, it is applied the next time the TV is turned on.

If you agree to the Smart Hub terms and conditions, Auto update is set to On automatically. If you want this function

disabled, use the Select button to turn it off.

"This function may take a longer time if another network function is running concurrently.

"This function requires an Internet connection.

- 10 -

Getting Support

Get help directly from Samsung if you have a problem with your TV.

Getting support through Remote Management

Settings Support Remote Management Try Now

After consenting to our service agreement, you can use Remote Management to access Remote Support and have a

Samsung service technician diagnose your TV, correct problems, and update your TV's software remotely via the web.

You can also turn Remote Management on and off.

"This function requires an Internet connection.

"You can also start this function by pressing and holding the button for 5 or more seconds.

What is Remote Support?

Samsung Remote Support service offers you one-on-one support with a Samsung Technician who can remotely:

●Diagnose your TV

●Adjust the TV settings for you

●Perform a factory reset on your TV

●Install recommended firmware updates

How does Remote Support Work?

You can easily get Samsung Remote Support service for your TV:

Call the Samsung Contact Centre and ask for remote support.

Open the menu on your TV and go to the Support section. ( Settings Support)

Select Remote Management, then read and agree to the service agreements. When the PIN screen appears,

provide the PIN number to the technician.

The technician will then access your TV.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung TV LCD

Samsung

Samsung LW22A13W Manuale utente

Samsung

Samsung LE22A451C1 Manuale utente

Samsung

Samsung LN19C350D1D Manuale di istruzioni

Samsung

Samsung LTM 225W Manuale utente

Samsung

Samsung Series 4+ Manuale utente

Samsung

Samsung LN-S2341W Manuale utente

Samsung

Samsung LW46G15W Manuale utente

Samsung

Samsung QN95B Series Manuale utente

Samsung

Samsung PN58C680G5F Manuale utente

Samsung

Samsung LE15S51BP Manuale utente

Samsung

Samsung LE19C430C4W Manuale utente

Samsung

Samsung LE32C650 Manuale utente

Samsung

Samsung LN40B540 Manuale utente

Samsung

Samsung SyncMaster P2370HD Manuale utente

Samsung

Samsung LE37C580J1K Manuale utente

Samsung

Samsung 3 SERIES Manuale utente

Samsung

Samsung LN32B550K1F Manuale utente

Samsung

Samsung LN37A330J1D Manuale utente

Samsung

Samsung LN-T4669F Guida all'installazione

Samsung

Samsung LNS3292D Istruzioni operative

Samsung

Samsung LA22B350F2 Manuale utente

Samsung

Samsung LTM1555X Manuale utente

Samsung

Samsung H6400 Series Manuale utente

Samsung

Samsung UN40C6300SF Manuale utente

Manuali TV LCD popolari di altre marche

LG 32LC4R* Manuale utente

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manuale utente

Salora

Salora 22LED1600 Manuale utente

Dell

Dell W1900 19 Istruzioni utente

Grundig

Grundig 40 VLE 8230 BP Manuale utente

Philips

Philips 43PFL4901/F7 Manuale utente

Sony

Sony Bravia XBR-43X830C Manuale utente

LG 32LS350 Manuale utente

VIORE

VIORE LED32VF60 Manuale utente

Toshiba

Toshiba Regza 42HL167 Manuale utente

JVC

JVC LT-32A220 Manuale utente

Philips

Philips 20TA1000/93 Manuale utente

Philips

Philips 32PFL3158T/12 Manuale utente

Sony

Sony Bravia KDL-V32XBR2 Manuale utente

Vizio

Vizio VP422HDTV10A - 42" Plasma TV Manuale utente

Philips

Philips 40PFL7705D Manuale utente

Dynex

Dynex DX-40L261A12 Manuale utente

JVC

JVC LT-23C50BU Manuale utente
