USER MANUAL
Gaming Monitor
S24AG32*
S27AG32*
S32AG32*
The colour and the appearance may differ depending on the product, and the specifications are subject to
change without prior notice to improve the performance.
The contents of this manual are subject to change without notice to improve quality.
© Samsung
Samsung owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung is prohibited.
Trademarks other than that of Samsung are owned by their respective owners.
An administration fee may be charged in the following situations:
(a) An engineer is called out at your request, but it is found that the product has no defect (i.e.,
where the user manual has not been read).
(b) You bring the unit to a repair centre, but it is found that the product has no defect (i.e., where the
user manual has not been read).
You will be informed of the administration fee amount before a technician visits.
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Samsung Odyssey
S27AG320NU o cerca il tuo prodotto tra le migliori offerte di Monitor
Table of contents
Before Using the Product
4
4
5
Safety Precautions
Electricity and Safety
Installation
Operation 6
Cleaning
8
Correct posture to use the product
8
Preparations
9
9
11
11
12
13
13
14
Control Panel
2
Menu
Game 19
Picture 21
OnScreen Display 23
System 23
Installing the Software
Easy Setting Box 26
Restrictions and Problems with the Installation 26
System Requirements 26
Driver Installation 26
Connecting and Using a Source Device
Read below before connecting the product. 15
Ports 15
16
16
16
16
16
Connecting and Using a PC
Connection Using the HDMI Cable
Connection Using an HDMI-DVI Cable
Connection Using an DP Cable
Connecting to headphones or earphones
Connecting the Power 17
Tidying Up the Connected Cables 17
Setting Optimum Resolution 18
Information 25
Installation
Attaching the Stand
Precaution for moving the product
Checking the space around the product
Adjusting the Product Tilt and Height
Rotating the Product
Anti-theft Lock
Wall Mount Kit Specifications(VESA)
10
Table of contents
3
Appendix
Responsibility for the Pay Service
35(Cost to Customers)
Not a product defect 35
A Product damage caused by customer's fault 35
Others 35
FreeSync (for AMD graphics card) 36
Troubleshooting Guide
27
27
27
Requirements Before Contacting Samsung
Customer Service Centre
Product diagnosis (Screen issue)
Checking the Resolution and Frequency
Check the following. 27
Q & A 30
Specifications
General 31
Standard Signal Mode Table 33
37WEEE
Correct Disposal of This Product (Waste
Electrical & Electronic Equipment) 37
4
Safety Precautions
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are
not followed.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE
NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage
is present inside. It is dangerous to
make any kind of contact with any
internal part of this product.
AC voltage: Rated voltage marked with
this symbol is AC voltage.
This symbol indicates that this
product has included important
literature concerning operation and
maintenance.
DC voltage: Rated voltage marked with
this symbol is DC voltage.
Class II product: This symbol indicates
that a safety connection to electrical
earth (ground) is not required. If this
symbol is not present on a product
with a mains lead, the product
MUST have a reliable connection to
protective earth (ground).
Caution. Consult instructions for use:
This symbol instructs the user to
consult the user manual for further
safety related information.
Electricity and Safety
Warning
• Do not use a damaged power cord or plug, or a loose power socket.
• Do not use multiple products with a single power socket.
• Do not touch the power plug with wet hands.
• Insert the power plug all the way in so it is not loose.
• Connect the power plug to a grounded power socket (type 1 insulated devices only).
• Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy
object.
• Do not place the power cord or product near heat sources.
• Clean any dust around the pins of the power plug or the power socket with a dry cloth.
Caution
• Do not disconnect the power cord while the product is being used.
• Only use the power cord provided with your product by Samsung. Do not use the power cord with
other products.
• Keep the power socket where the power cord is connected unobstructed.
‒ The power cord must be disconnected to cut off power to the product when an issue occurs.
• Hold the plug when disconnecting the power cord from the power socket.
Before Using the Product
Chapter 01
5
Warning
• DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT
INSTALL THE PRODUCT NEAR HEAT SOURCES.
• Do not install the product in poorly ventilated spaces such as a bookcase or closet.
• Install the product at least 10cm away from the wall to allow ventilation.
• Keep the plastic packaging out of the reach of children.
‒ Children may suffocate.
• Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)
‒ The product may fall and become damaged and/or cause an injury.
‒ Using the product in an area with excess vibration may damage the product or cause a fire.
• Do not install the product in a vehicle or a place exposed to dust, moisture (water drips, etc.), oil, or
smoke.
• Do not expose the product to direct sunlight, heat, or a hot object such as a stove.
‒ The product lifespan may be reduced or a fire may result.
• Do not install the product within the reach of young children.
‒ The product may fall and injure children.
• Edible oil, such as soybean oil, can damage or deform the product. Do not install the product in a
kitchen or near a kitchen counter.
Caution
• Do not drop the product while moving.
• Do not set down the product on its front.
• When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the
product is not protruding.
‒ The product may fall and become damaged and/or cause an injury.
‒ Install the product only on cabinets or shelves of the right size.
• Set down the product gently.
‒ Product failure or personal injury may result.
• Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances,
extreme temperatures or a significant presence of moisture, or a place where the product will operate
continuously for an extended period of time) may seriously affect its performance.
‒ Be sure to consult Samsung Customer Service Centre if you want to install the product at such a
place.
• Before assembling the product, place the product down on a flat and stable surface so that
the screen is facing downwards.
• In the same series, the colour can vary depending on the size.
Installation
6
Warning
• There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.
‒ Contact Samsung Customer Service Centre for repairs.
• To move the product, first disconnect all the cables from it, including the power cable.
• If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord
immediately and contact Samsung Customer Service Centre.
• Do not let children hang from the product or climb on top of it.
‒ Children may become injured or seriously harmed.
• If the product is dropped or the outer case is damaged, turn off the power and disconnect the power
cord. Then contact Samsung Customer Service Centre.
‒ Continued use can result in a fire or electric shock.
• Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.
‒ The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a
serious injury.
• During a lightning or thunderstorm, power off the product and remove the power cable.
• Do not drop objects on the product or apply impact.
• Do not move the product by pulling the power cord or any cable.
• If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area
immediately.
• Do not lift or move the product by pulling the power cord or any cable.
• Do not use or keep combustible spray or an inflammable substance near the product.
• Ensure the vents are not blocked by tablecloths or curtains.
‒ An increased internal temperature may cause a fire.
• Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper,
matches, etc) into the product (via the vent or input/output ports, etc).
‒ Be sure to power off the product and disconnect the power cord when water or other foreign
substances have entered the product. Then contact Samsung Customer Service Centre.
• Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the
product.
‒ Be sure to power off the product and disconnect the power cord when water or other foreign
substances have entered the product. Then contact Samsung Customer Service Centre.
Operation
7
Caution
• Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage
burn-in or defective pixels.
‒ Set the screen to power-saving mode or moving-picture screen saver when not using the product
for an extended period of time.
• Disconnect the power cord from the power socket if you do not plan on using the product for an
extended period of time (vacation, etc).
‒ Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.
• Use the product at the recommended resolution and frequency.
‒ Your eyesight may deteriorate.
• Do not put AC/DC adapters together.
• Remove the plastic bag from the AC/DC adapter before you use it.
• Do not let water enter the AC/DC adapter device or get the device wet.
‒ An electric shock or fire may result.
‒ Avoid using the product outdoors where it can be exposed to rain or snow.
‒ Be careful not to get the AC/DC adapter wet when you wash the floor.
• Do not put the AC/DC adapter near to any heating apparatus.
‒ Otherwise, a fire may result.
• Keep the AC/DC adapter in a well-ventilated area.
• If you place the AC/DC power adapter hanging with the cord input facing upwards, water or other
foreign substances could enter the Adapter and cause the Adapter to malfunction.
Make sure to rest the AC/DC power adapter flat on a table or the floor.
• Do not hold the product upside-down or move it by holding the stand.
‒ The product may fall and become damaged or cause an injury.
• Looking at the screen too close for an extended period of time can deteriorate your eyesight.
• Do not use humidifiers or stoves around the product.
• Rest your eyes for more than 5 minutes or look at distance objects for every 1 hour of product use.
• Do not touch the screen when the product has been turned on for an extended period of time as it
will become hot.
• Store small accessories out of the reach of children.
• Exercise caution when adjusting the product angle.
‒ Your hand or finger may get stuck and injured.
‒ Tilting the product at an excessive angle may cause the product to fall and an injury may result.
• Do not place heavy objects on the product.
‒ Product failure or personal injury may result.
• When using headphones or earphones, do not turn the volume too high.
‒ Having the sound too loud may damage your hearing.
8
Cleaning
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
― Contact your nearest Samsung Customer Service Centre if you want to clean the inside of the product (Service
fee will be charged.)
Do not press the product screen with hands or other objects. There is a risk of damaging the screen.
― Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1 Power off the product and PC.
2 Disconnect the power cord from the product.
― Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock
may result.
3 Wipe the product with a clean, soft and dry cloth.
Wet a soft cloth in water, wing it out well, and then use the cloth to wipe the exterior of the product
clean.
‒ Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the product.
‒ Do not spray water or detergent directly on the product.
4 Connect the power cord to the product when cleaning is finished.
5 Power on the product and PC.
Correct posture to use the product
Use the product in the correct posture as follows:
• Straighten your back.
• Allow a distance of 45 to 50cm between your eye and the screen, and look slightly downward at the
screen.
• Keep your eyes directly in front of the screen.
• Adjust the angle so light does not reflect on the screen.
• Keep your forearms perpendicular to your upper arms and level with the back of your hands.
• Keep your elbows at about a right angle.
• Adjust the height of the product so you can keep your knees bent at 90 degrees or more, your heels
attached to the floor, and your arms lower than your heart.
• Do the Eye excercises or blink frequently, then eye fatigue will be relieved.
9
Chapter 02
Preparations
Installation
Attaching the Stand
― Disassembly is the reverse order of assembly.
7
4 5
1 2 3
6
Put the stand base onto the stand neck as
the direction shown in the figure. Check
that the stand neck is firmly connected.
Tightly fasten the connecting screw
at the bottom of the stand base.
Attach the decoration cover in the direction of the arrow and turn it in clockwise
according to the mark.
Push the assembled stand into the main body in the direction of the arrow
as shown in the figure.
Caution
Do not arbitrarily remove the panel film. If not
observed, the warranty service may be restricted.
Stand up the monitor as
shown in the figure.
After installing the stand,
place the product upright.
10
Precautions for moving the product
• Hold the lower corners or edges of the
product when moving it.
• Do not directly apply pressure on
the screen.
• Do not hold the screen when
moving the product.
• Do not hold the product upside down only
by the stand.
• Do not press down on the product.
There is a risk of damaging the product.
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali Samsung Monitor
Samsung
Samsung S55BG97 Series Manuale utente
Samsung
Samsung 2243WM - SyncMaster - 22" LCD Monitor Manuale utente
Samsung
Samsung LS27R650FDUXXU Manuale utente
Samsung
Samsung 400PX - SyncMaster - 40" LCD Flat Panel... Manuale utente
Samsung
Samsung S24A60S Series Manuale utente
Samsung
Samsung S34A65 Series Manuale utente
Samsung
Samsung 931C - SyncMaster - 19" LCD Monitor Manuale utente
Samsung
Samsung SyncMaster 720B Manuale utente
Samsung
Samsung S24C230JL Manuale utente
Samsung
Samsung XL2370 - SyncMaster - 23" LCD Monitor Guida utente
Samsung
Samsung SyncMaster UD46A Manuale utente
Samsung
Samsung S22F350FH Manuale utente
Samsung
Samsung SyncMaster 730BF Manuale utente
Samsung
Samsung SyncMaster 153V Manuale utente
Samsung
Samsung SyncMaster 400TSn-2 Manuale utente
Samsung
Samsung SyncMaster 220TN Manuale utente
Samsung
Samsung LTM 1525 Manuale utente
Samsung
Samsung ME75C Manuale utente
Samsung
Samsung 320MXn-2 - SyncMaster - 32" LCD Flat Panel... Guida utente
Samsung
Samsung P50HP - SyncMaster - 50" Plasma Panel Manuale utente
