Samsung SAMTRON 58V Manuale utente

Install drivers

SAMTRON 591S/58V/59E/78E/78DF/78BDF/98PDF

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at

all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric

shock

Power

When not used for extended period of time, set your computer to DPMS. If using a

screen saver, set it to the active screen mode.

zIf the size of your monitor is small, or if the same image is present for long periods of

time, you may see afterimages due to damage to the fluorescent substance on the

inside of the CDT.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Do not excessively bend the plug and wire nor place heavy objects upon them,

which could cause damage.

zThis may cause an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or if it is not

used for a long period of time.

zThis may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause fire.

Installation

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Put your monitor in a location with low humidity and a minimum of dust.

zAn electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor may cause injury by falling.

Set down the monitor carefully.

zThe monitor could be damaged or broken.

Do not place the monitor face down.

zThe CDT surface may be damaged.

Do not use the monitor without the monitor stand.

zIt could break down or cause fire due to bad ventilation.

zIf the monitor must be used without the supplied stand, take steps to insure

proper ventilation.

Clean

When cleaning the monitor case or the surface of the CDT, wipe with a slightly

moistened, soft fabric.

Do not clean Flat monitor with water. Use a water-diluted mild detergent.

(Some detergents contain significant amounts of alcohol-based solvents, which can

damage (color change) or crack the monitor case. The antiglare/anti-static surface

coating on the CDT may also be affected.)

Dilute the detergent (1:10 ratio) with water before using.

Do not spray water or detergent directly on the monitor.

Use the recommended detergent with a smooth cloth.

zYou may prevent the coated CDT from being damaged or the monitor cabinet

from being dissolved, cracked or discolored.

zYou may buy a recommended detergent at any Service Center.

If the connector between the plug and the pin is dusty or dirty, clean it

properly with a dry cloth.

zA dirty connector may cause an electric shock or fire.

Do not set a glass of water, chemicals or any small metal objects on the

monitor.

zThis may cause damage, electric shock or fire.

zIf a foreign substance gets into the monitor, disconnect the plug and then

contact a service center.

Others

Do not remove cover(or back).

zThis may cause an electric shock or fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any

unusual sounds or smells coming from it - unplug it immediately and

contact an authorized dealer or service.

zThis may cause an electric shock or fire.

Do not place any heavy objects on the monitor.

zThis may cause an electric shock or fire.

For each hour of looking at the monitor, you should let your eyes rest for 5

minutes.

zThis will reduce eye fatigue.

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Do not try to move the monitor by pulling only the wire or the signal cable.

zThis may cause a breakdown, electric shock or fire due to damage to the

cable.

Do not move the monitor right or left by pulling only the wire or the signal

cable.

zThis may cause a breakdown, electric shock or fire due to damage to the

cable.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Keep the monitor away from any magnetic substances.

zThis may cause discoloring or distortion of the image.

Please make sure the following items are included with your monitor.

If an

items are missin

, contact

our deale

Unpacking

Monitor

Manual

Quick Setup Guide Warranty Card

(Not available in all

locations) User's Guide, Monitor

Driver

Cable

Power Cord

SAMTRON 591S/58V/59E

Stand

For Multimedia model (Option)

Manual

User Guide

Cable

Sound Cables

(

2each

)

DC Power Cord

Stand

Multimedia S

eaker Stand

Front

Menu button [ ]

Opens the OSD menu. Also used to exit the OSD menu or

return to the previous menu.

Adjust buttons [ ] These buttons allow you to highlight and adjust items in the

menu.

Enter button [ ] Used to select the OSD menu.

Power button Use this button for turn the monitor on and off.

Power indicator This light glows green during normal operation, and blinks green

once as the monitor saves your adjustments.

See PowerSaver described in the manual for further information regarding power saving

functions. For energy conservation, turn your monitor OFF when it is not needed, or when

leaving it unattended for long periods.

Rear

(The configuration at the back of the monitor may vary from product to product.)

Power port Connect the power cord for your monitor to the power port on

the back of the monitor.

Signal Cable Connect the signal cable to the video port on your computer,

video board, video card, or graphics card.

See Connecting the Monitor for further information regarding cable connections.

Bottom

Signal Cable Connect the signal cable to the video port on your computer,

video board, video card, or graphics card.

Power port Connect the power cord for your monitor to the power port on

the back of the monitor.

Tilt/Swivel Base You can separate the base from the monitor.
