Samsung SMT-1722 Manuale utente

17"/19" TFT-LCD Monitor

SMT-1722/1922

* Design and specifications are subject to change without notice

Distributed by

SAMSUNG ELECTRONICS CO., LTD.

416, Maetan 3 Dong, YeongTong-Gu, Suwon City, Kyeonggi-Do, Korea, 443-742

Tel: +82-31-277-3342~3347 Fax: +82-31-277-6597 http://www.samsungsecurity.com

SMT-1922

Features

620(PAL)/600(NTSC) Horizontal TV Lines

DNIe(Digital Natural Image engine)

1000:1 High Contrast Ratio

300cd/m

High Brightness

5ms Response Time

1280x1024 Resolution

BNC, S-Video, VGA Input

Built-in Speakers

Tempered Glass

VESA Mount Compatible

Sync. Format NTSC/PAL

Inch 17" 19"

Resolution 1280 X 1024

Brightness(cd/m2) 300

Panel Contrast 1,000:1

Response Time 5msec

Viewing Angle Degree 80/80/80/80

Active Display Area(mm) 338 x 270(H x V) 376 x 301(H x V)

CCFL Lifetime 50,000 hour

Scan System Progressive

Horizontal Resolution 620TVL (PAL), 600TVL (NTSC)

Screen Mode 4:3

Picture 3D Comb Filter Yes

Noise Reduction Yes

PIP/PBP Yes

Freeze Yes

Under Scan Yes

Composite 2Ch input, Loop Through out, BNC Type

Video S-Video 1Ch input(Y/C), Loop Through out

VGA 1Ch input

Audio 2Ch input, 2W Stereo, RCA Type

OSD Language 11 Language (Eng/Fre/Ger/Spa/Ita/Rus/Swe/Por/Kor/Chn/Jpn)

Lift 0 ~ 100mm

HAS Stand Tilt -5°~ 23°

Swivel -165° ~ +165°

Weight 5.95Kg 6.9Kg

371 x 368 x 220 (W x H x D / Lowest) 412 x 398 x 220 (W x H x D / Lowest)

Dimensions(mm) 371 x 468 x 220 (W x H x D / Highest) 412 x 498 x 220 (W x H x D / Highest)

Power Supply 100 ~ 240V 100 ~ 240V

Power Consumption 42W 42W

*Design and Specifications are subject to change without notice

Specifications

Model SMT-1722 SMT-1922

Dimensions(mm)

SMT-1722

imagine the outstanding image quality

with super high resolution!

Give the people that protect you and your property the best tools to do their job.

The SMT-1722/1922 provides your security personnel with the best images available to

ensure that even the smallest detail is not missed.

SMT-1722/1922

Super High Resolution of 620 TV Lines

Capable of resolving 620 TV Lines(PAL) / 600 TV Lines

(NTSC), the SMT-1722/1922 offer perfect reproduction

of high resolution CCTV images without degradation.

Enhanced Color with DNIe*

Utilizing Samsung’s DNIe technology, the SMT-1722/1922 monitors provide enhanced image reproduction

quality with optimized color, enhanced contrast and higher resolution. It delivers rich color and crystal clear

image for more comfortable reading and for reducing eye fatigue.

Motion Optimizer : Clear Moving Images Detail Enhancer : Fine Details

Contrast Enhancer : Sharp Contrast Color Optimizer : Natural Color

conventional DNle conventional DNle

*DNIe(Digital Natural Image Engine) : Samsung’s proprietary technology embedded in premium LCD TV to enhance picture quality for the best performance.

conventional

5msconventional

PIP (Picture in Picture) PBP (Picture by Picture)

Fast Response Time

With a response time of 5ms ghosting and jagged pixel effects

are greatly reduced, resulting in superb image clarity even when

monitoring scenes with high speed activity.

Beyond imagination! The ultra sharp screen with super high resolution

clearly displays even a bead of perspiration!

17”/19” TFT LCD Monitor

SMT-1722/1922

Tempered Glass Screen

SMT-1722/1922's tempered glass screen design

protects the screen from dirt, repetitive touching or scratching.

Multiple Connections

Based on different surveillance needs, a combination of different video/audio

ports can be used for a more integrated solution.

PIP (Picture in Picture), PBP (Picture by Picture)

The picture-in-picture or picture-by-picture capability allows a

security manager to use a PC and view a CCTV camera at the

same time. It could also allow the manager to always have a

video of important camera in the corner at all times.

Height Adjustable Stand (HAS)

SMT-1722/1922 monitor can be adjusted to your comfort level. Maximize your

efficiency with the convenient height adjustable stand.

Audio output in VGA Mode

Users can select an audio output in VGA mode from any of the audio inputs.
