Samsung SMT-1914 Manuale utente

User manual

Security LED Monitor

AB68-01117B

SMT-1914

Table Of Contents 2

Table Of Contents

BEFORE USING

THE PRODUCT

6 Copyright

6 Icons used in this manual

6 Symbols for safety precautions

7 Cleaning

8 Securing the Installation Space

9 Safety Precautions

9 Electricity and Safety

10 Installation and Safety

12 Operation and Safety

15 Correct posture to use the product

PREPARATIONS 16 Checking the Contents

16 Removing the Packaging

17 Checking the Components

18 Parts

18 Frontal Buttons

20 Reverse Side

21 Installation

21 Attaching the Stand

22 Installing a Wall-mount Kit or Desktop Stand

23 Anti-theft Lock

CONNECTING AND

USING A SOURCE

DEVICE

24 Before Connecting

24 Pre-connection Checkpoints

24 Connecting the Power

Table Of Contents

Table Of Contents 3

25 Connecting to a PC

25 Connecting to a DVR

27 Changing the Resolution Using a PC

SCREEN SETUP 30 Brightness

30 Configuring Brightness

31 Contrast

31 Configuring Contrast

32 Sharpness

32 Configuring Sharpness

33 SAMSUNG MAGIC Bright

33 Configuring SAMSUNG MAGIC Bright

34 SAMSUNG MAGIC Angle

34 Configuring SAMSUNG MAGIC Angle

35 Coarse

35 Adjusting Coarse

36 Fine

36 Adjusting Fine

CONFIGURING

TINT

37 SAMSUNG MAGIC Color

37 Configuring SAMSUNG MAGIC Color

38 Red

38 Configuring Red

39 Green

39 Configuring Green

40 Blue

40 Configuring Blue

25 Connections

26 Setting Optimum Resolution

Table Of Contents

Table Of Contents 4

41 Color Tone

41 Configuring the Color Tone Settings

42 Gamma

42 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

43 H-Position & V-Position

43 Configuring H-Position & V-Position

44 Menu H-Position & Menu V-Position

44 Configuring Menu H-Position & Menu V-

Position

SETUP AND

RESET

45 Reset

45 Initializing Settings (Reset)

46 Language

46 Changing the Language

47 Eco Saving

47 Configuring Eco Saving

48 Off Timer On/Off

48 Configuring Off Timer On/Off

49 Off Timer Setting

49 Configuring Off Timer Setting

50 Key Repeat Time

50 Configuring Key Repeat Time

51 Customized Key

51 Configuring Customized Key

Table Of Contents

Table Of Contents 5

52 Display Time

52 Configuring Display Time

53 Menu Transparency

53 Changing Menu Transparency

INFORMATION

54 INFORMATION

54 Displaying INFORMATION

TROUBLESHOOTI

NG GUIDE

55 Requirements Before Contacting

Samsung Customer Service Center

55 Testing the Product

55 Checking the Resolution and Frequency

55 Check the following.

57 Q & A

SPECIFICATIONS 59 General

60 PowerSaver

62 Standard Signal Mode Table

APPENDIX 64 Correct Disposal

64 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

65 Terminology

61 Dimensions

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Techwin owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Techwin

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

Symbols for safety precautions

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LEDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

zDo not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

zDo not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

zEnsure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

10 cm(3.93 inches) 10 cm(3.93 inches)

10 cm

(3.93

inches)

10 cm

(3.93

inches)

10 cm(3.93 inches)

Before Using the Product

Safety Precautions

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

zAn electric shock or fire may result.

Do not plug many products into the same power socket.

zOtherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

zOtherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

zAn unstable connection may cause a fire.

Ensure you connect the power plug to a grounded power socket. (type 1

insulated devices only).

zAn electric shock or injury may result.

Do not bend or pull the power cord with force. Do not weigh the power cord

down with a heavy object.

zA damaged power cord may cause an electric shock or fire.

Do not place the power cord or product near heat sources.

zAn electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

zOtherwise, a fire may result.

Before Using the Product

Caution

Installation and Safety

Warning

Do not unplug the power cord when the product is in use.

zThe product may become damaged by an electric shock.

Do not use the power cord for products other than authorized products supplied

by Samsung.

zAn electric shock or fire may result.

Keep the power socket where the power cord is connected unobstructed.

zIf any problem occurs in the product, unplug the power cable to completely

cut the power to the product.

Power to the product cannot be completely cut off with the power button.

Hold the plug when disconnecting the power cord from the power socket.

zAn electric shock or fire may result.

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP

OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

zOtherwise, a fire may result.

Avoid installing the product in a narrow space with bad ventilation, such as a

bookshelf or wall closet.

zOtherwise, a fire may result due to an increased internal temperature.

Keep the plastic packaging bag for the product in a place that cannot be reached

by children.

zChildren may suffocate.
