SyncMaster 2253BW/2253LW

LCD Monitor

User Manual

imagine the possibilities

Safety Instructions

Notational

Note

Please read the following safety instructions as they are designed to prevent damage to property and

harm to the user.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily harm

or damage to the equipment.

Notational Conventions

Prohibited Important to read and under-

stand at all times

Do not disassemble Disconnect the plug from the

outlet

Do not touch Ground to prevent an electric

shock

Power

When not used for extended period of time, set your computer to DPM.

If using screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases (or

countries).

Shortcut to Anti-Afterimage Instructions

Do not use damaged or loose plug.

• This may cause electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

• This may cause electric shock or fire.

Use only a properly grounded plug and receptacle.

• An improper ground may cause electric shock or equipment damage.

(Class 1 Equipment only.)

Insert the power plug firmly so that it does not come loose.

• A bad connection may cause fire.

Do not excessively bend the plug and wire nor place heavy objects

upon them, which could cause damage.

• This may cause electric shock or fire.

Do not connect too many extension cords or plugs to one outlet.

• This may cause fire.

Do not disconnect the power cord while using the monitor.

• A surge may be caused by the separation and may damage the mon-

itor.

Do not use the power cord when the connector or plug is dusty.

• If the connector or plug of the power cord is dusty, clean it with a dry

cloth.

• Using the power cord with a dusty plug or connector may cause an

electric shock or fire.

To disconnect the apparatus from the mains, the plug must be pulled

out from the mains socket, therefore the mains plug shall be readily op-

erable.

• This may cause electric shock or fire.

Installation

Be sure to contact an authorized Service Center when installing your monitor in

a location with heavy dust, high or low temperatures, high humidity, and exposed

to chemical substances and where it operates for 24 hours such as at airports,

train stations etc.

Failure to do so may cause serious damage to your monitor.

Place your monitor in a location with low humidity and a minimum

of dust.

• Failure to do so may cause electric shock or fire inside the monitor.

Do not drop the monitor when moving it.

• This may cause damage to the product or the person carrying it.

Install the monitor base in a showcase or shelf so that the end of the

base does not protrude from the showcase or shelf.

• Dropping the product may cause damage to the product or the person

carrying it.

Do not place the product on an unstable or small surface area.

• Place the product on an even and stable surface, as the product may

fall and cause harm to someone walking by, specifically children.

Safety Instructions

Do not place the product on the floor.

• Take care, as someone, specifically children may trip over it.

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR

OTHER OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL

TIMES.

• Otherwise, this may cause fire.

Keep any heating devices away from the power cable.

• A melted coating may cause electric shock or fire.

Do not install the product in places with poor ventilation, for instance,

a bookshelf, closet, etc.

• Any increase in the internal temperature may cause fire.

Put down the monitor carefully.

• Failing to do so may damage the monitor.

Do not place the monitor face down.

• This may damage the TFT-LCD surface.

The installation of the bracket must be done by a qualified professional.

• Installing the bracket by unqualified personnel may result in injury.

• Always use the mounting device specified in the owner's manual.

When installing the product, make sure to keep it away from the wall

(more than 10 cm / 4 inches) for ventilation purposes.

• Poor ventilation may cause an increase in the internal temperature of

the product, resulting in a shortened component life and degraded

performance.

Keep the plastic packaging (bag) out of children's reach.

• The plastic packaging (bag) may cause suffocation if children play

with it.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe

with a slightly moistened, soft fabric.

Do not spray water or detergent directly onto the monitor.

• This may cause damage, electric shock or fire.

Safety Instructions

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean

it properly using a dry cloth.

• A dirty connector may cause electric shock or fire.

Make sure to unplug the power cord before cleaning the product.

• Otherwise, this may cause electric shock or fire.

Unplug the power cord from the power outlet and wipe the product

using a soft, dry cloth.

• Do not use any chemicals such as wax, benzene, alcohol, thinners,

insecticide, air freshener, lubricant or detergent.

Others

Do not remove the cover (or back).

• This may cause electric shock or fire.

• Refer to a qualified servicing company.

If your monitor does not operate normally - in particular, if there is

any unusual sound or smell coming from the monitor - unplug it imme-

diately and contact an authorized dealer or the Service Center.

• This may cause electric shock or fire.

Keep the product away from places exposed to oil, smoke or moisture;

do not install inside a vehicle.

• This may cause a malfunction, electric shock or fire.

• In particular, avoid operating the monitor near water or outdoors

where the monitor could be exposed to snow or rain.

If the monitor is dropped or the casing is damaged, turn the monitor

and unplug the power cord. Then contact the Service Center.

• The monitor may malfunction, causing electric shock or fire.

Disconnect the plug from the outlet during storms or lightning or if it

is not used for a long period of time.

• Failure to do so may cause electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal

cable.

• This may cause a breakdown, electric shock or fire due to damage to

the cable.

Safety Instructions

Do not move the monitor right or left by pulling only the wire or the

signal cable.

• This may cause a breakdown, electric shock or fire due to damage to

the cable.

Do not cover the vents on the monitor cabinet.

• Bad ventilation may cause a breakdown or fire.

Do not place water containers, chemical products or small metal ob-

jects on the monitor.

• This may cause a malfunction, electric shock or fire.

• If a foreign substance enters the monitor, unplug the power cord and

contact the Service Center.

Keep the product away from combustible chemical sprays or inflam-

mable substances.

• This may cause an explosion or fire.

Never insert anything metallic into the monitor openings.

• This may cause electric shock, fire or injury.

Do not insert metal objects such as chopsticks, wire and tools or in-

flammable objects such as paper or matches into the vent, headphone port

or AV ports or etc.

• This may cause electric shock or fire. If an alien substances or water

enters the product, turn the product off, unplug the power connector

from the wall outlet and contact the Service Center.

When viewing a fixed screen for an extended period of time, residual

image or blurriness may appear.

• Change the mode to energy saving mode or set a screensaver to a

changing picture when away from the monitor for an extended period

of time.

Adjusts the resolution and frequency to the level appropriate for the

model.

• An inappropriate resolution may cause undesirable picture quality.

Viewing the monitor continuously at a too close angle may result in

damage to your eyesight.

To ease eye strain, take at least a five-minute break after every hour

of using the monitor.

Safety Instructions

Do not install the product on an unstable, uneven surface or a location

prone to vibrations.

• Dropping the product may cause damage to the product or the person

carrying it. Using the product in a location prone to vibrations may

shorten the lifetime of the product or may cause the product to catch

fire.

When moving the monitor, turn off and unplug the power cord. Make

sure that all cables, including the antenna cable and cables connected to

other devices, are disconnected before moving the monitor.

• Failure to disconnect cables may damage it and cause fire or electric

shock.

Place the product out of children’s reach, as they could damage by

hanging onto it.

• A falling product may cause injury to the person or even fatality.

When not using the product for an extended period of time, keep the

product unplugged.

• Otherwise, this may cause heat emission from the accumulated dirt

or degraded insulation, causing electric shock or fire.

Do not place your children's favorite toys or any other objects of in-

terest on the product.

• Children may try to climb on the product to retrieve an object. The

product could fall, causing injury or even fatality.

When lifting up or moving the monitor, do not lift the monitor upside

down while holding only the stand.

• This may cause your monitor to fall, and become damaged or cause

personal injury.

Good Postures When Using the Monitor

Try to maintain a good posture when using the monitor.

• Keep your back straight.

• Keep a distance of about 45 ~ 50 cm between your eyes

and the monitor screen. Look at the screen from slightly

above it, and have the monitor directly in front of you.

• Tilt the monitor upwards by 10 ~ 20 degrees. Adjust the

monitor height so that the top of the monitor is slightly

below eye level.

• Adjust the monitor angle so that there is no reflected

light on the screen. Try to maintain your arms perpen-

dicular to your armpits.

• Keep your arms level with the back of your hands.

• Keep the angle of the elbow perpendicular.

Safety Instructions

• Keep the angle of the knees at more than 90 degree. Do

not let your feet fall up from the floor. Adjust the arm

position so that it is below the heart.

Safety Instructions

Introduction

Package Contents

Note

Please make sure the following items are included with your monitor.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

Unpacking

Monitor

Manuals

Quick Setup Guide Warranty Card

(Not available in all loca-

tions)

User's Guide

Cables

D-Sub Cable Power Cord DVI Cable (option)

Others

Cleaning Cloth

Note

This is only provided for highly polished black products as a product feature.

Your Monitor

Initial Settings

Select the language using the up or down key.

The displayed content will disappear after 40 seconds.

Turn the Power button off and on. It will be displayed again.

It can be displayed up to three (3) times. Make sure to adjust the resolution of your PC before reaching

the maximum count.

Note

The resolution displayed on the screen is the optimal resolution for this product.

Adjust your PC resolution so that it is the same as the optimal resolution for this product.

Front

MENU button [MENU/ ]

Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu

or return to the previous menu.

Customized Key[ ]

You can customize key assignment for the Custom button according to your pref-

erences.

Introduction

Altri manuali per SyncMaster 2253BW, 2253LW

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Monitor

Samsung

Samsung 245T - SyncMaster - 24" LCD Monitor Manuale utente

Samsung

Samsung ME95C Manuale utente

Samsung

Samsung SyncMaster 400UX-3 Manuale utente

Samsung

Samsung S22E391H Manuale utente

Samsung

Samsung S49A95 U Series Manuale utente

Samsung

Samsung SyncMaster 450Nb Manuale utente

Samsung

Samsung HPT4264 - 42" Plasma TV Manuale utente

Samsung

Samsung S19C350NW Manuale utente

Samsung

Samsung 940MW - SyncMaster - 19" LCD Monitor Manuale utente

Samsung

Samsung SYNCMASTER 152X/172X Guida utente

Samsung

Samsung PS-42C62H Manuale utente

Samsung

Samsung ML467 series Manuale utente

Samsung

Samsung SyncMaster S20A300N Manuale utente

Samsung

Samsung SyncMaster 932BF Manuale utente

Samsung

Samsung SyncMaster 910N Manuale utente

Samsung

Samsung ED75D Manuale utente

Samsung

Samsung SyncMaster 171B, 171S, 181B, 171T, 171Q Guida utente

Samsung

Samsung HP-S4233 Manuale utente

Samsung

Samsung F24T40 Series Manuale utente

Samsung

Samsung 2233BW - SyncMaster - 22" LCD Monitor Manuale utente

Samsung

Samsung SyncMaster 170T Manuale utente

Samsung

Samsung HPT5054 - 50" Plasma TV Manuale utente

Samsung

Samsung C34H890W Series Manuale utente

Samsung

Samsung LS27A650DS/ZA Manuale utente

Manuali Monitor popolari di altre marche

Linear Acoustic

Linear Acoustic LQ-1000 Manuale utente

AOC

AOC I2579V Manuale utente

Gateway

Gateway FPD1520 Manuale utente

Furuno

Furuno Mu 120c Manuale utente

Asus

Asus VB171D - 17" LCD Monitor Manuale utente

Dell

Dell S2230MX Istruzioni utente

Philips

Philips 107C64 Manuale utente

Dell

Dell S2409WFP Manuale utente

EverFocus

EverFocus EN-7517E Manuale utente

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuale utente

Dell

Dell Precision 7680 Manuale di istruzioni

LG 50PM1M - - 50" Plasma Panel Manuale utente

Bosch

Bosch DDU 9 Manuale utente

Acer

Acer A231HL Manuale utente

Philips

Philips 86BDL4152T Manuale utente

NEC

NEC AccuSync LCD5V Manuale utente

Emay

Emay SleepO2 Manuale utente

IBM

IBM 6360 Istruzioni per l'installazione
