Samsung SyncMaster UD46A Manuale utente

SyncMaster UD46A, UD55A

LCD Display

User Manual

The color and the appearance may differ depending on the

product, and the specifications are subject to change

without prior notice to improve the performance.

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property damage.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily harm

or damage to the equipment.

Note

Prohibited Important to read and under-

stand at all times

Do not disassemble Disconnect the plug from the

outlet

Do not touch Ground to prevent an electric

shock

• An administration fee may be charged if either

•(a) an engineer is called out at your request and there is no defect in the product(i.e.

where you have failed to read this user manual)

• (b) you bring the unit to a repair centre and there is no defect in the product(i.e.

where you have failed to read this user manual).

• The amount of such administration charge will be advised to you before any work or

home visit is carried out.

Power

When not used for extended period of time, set your computer to DPM.

If using a screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases (or

countries).

Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or loose power

outlet.

•Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or plug-

ging the plug into the outlet.

•Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power outlet.

•Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet firmly and

correctly.

•Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place any

heavy material on it.

•Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

•Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

• Otherwise, this may result in damage to the product due to electric

shock.

To disconnect the apparatus from the mains, the plug must be pulled

out from the mains socket, therefore the mains plug shall be readily op-

erable.

• Otherwise, this may cause electric shock or fire.

Use only the power cord provided by our company. Do not use the

provided power cord of another product.

•Otherwise, this may result in fire or electric shock.

Connect the power plug to a wall outlet that can be easily reached.

• When a problem occurs with the product, you must unplug the power

plug to cut the power off completely. You cannot cut the power off

completely using only the power button on the product.

Installation

Be sure to contact an authorized Service Center when installing your monitor in

a location with heavy dust, high or low temperatures, high humidity, and exposed

to chemical substances and where it operates for 24 hours such as at airports,

train stations etc.

Failure to do so may cause serious damage to your monitor.

Safety Instructions

Ensure that at least two persons lift and move the product.

• Otherwise, it may be dropped and cause personal injury, and/or dam-

age the product.

When installing the product in a cabinet or rack, make sure that the

front end of the bottom of the product does not project out.

•Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGA-

RETTES AND ANY HEATING APPLIANCES NEAR THE PROD-

UCT.

• Otherwise, this may result in fire.

Keep heating appliances as far away from the power cord or the prod-

uct as possible.

•Otherwise, this may result in electric shock or fire.

Do not install it in a badly ventilated location such as a bookcase or

closet.

• Otherwise, this may result in fire due to an increase in the internal

temperature.

When putting the product down, make sure to put it down softly.

•Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

•Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that there is

a clearance of more than 4 inches (10 cm) from the wall.

• Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Ensure that the packaging vinyl is kept away from children.

• Otherwise, it may result in serious harm (suffocation) if children play

with it.

If the height of your monitor is adjustable, do not place any object or

part of your body on the stand when lowering it.

•This may cause damage to the product or the person carrying it.

Safety Instructions

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe

with a slightly moistened, soft cloth.

Do not spray cleaner directly onto the surface of the product.

• Otherwise, this may result in the discoloration and distortion of the

structure and the screen surface may peel off.

When cleaning the power plug pins or dusting the power outlet, clean

it with a dry cloth.

•Otherwise, it may result in fire.

When cleaning the product, make sure to disconnect the power cord.

•Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and clean it

with a soft, dry cloth.

•(Do not use chemicals such as wax, benzene, alcohol, thinner, mos-

quito repellant, lubricant, or cleaner.) These may change the appear-

ance of the product surface and peel off the indication labels on the

product.

Since the product housing is easily scratched, make sure to use the

specified cloth only.

When cleaning the product, do not spray water directly onto the main

body of the product.

•Ensure that water does not enter the product and that it is not wet.

• Otherwise, this may result in electric shock, fire or a malfunction.

Others

The product is a high voltage product. Do not disassemble, repair or

modify the product yourself.

• Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming from

the product, disconnect the power plug immediately and contact a Service

Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust,

smoke, water, or in a car.

•Otherwise, this may result in electric shock or fire.

Safety Instructions

When you drop the product or the case is broken, turn the power off

and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

If thunder or lightning is occurring, do not touch the power cord or

antenna cable.

•Otherwise, this may result in electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal

cable.

• Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and left

while only holding the power cord or signal cables.

• Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table or

curtain.

• Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Do not place any containers containing water, vases, flowerpots, med-

icines as well as any metal on the product.

• If water or a foreign material enters the product, disconnect the power

cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material near the

product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and steel, or

flammable objects, such as matches or paper, inside the product (through

the ventilating openings, input and output terminals, etc).

• If water or foreign material enters the product, disconnect the power

cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain may

occur.

• If you are not using your product for a long period of time, put it into

sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

•Otherwise, your eyesight may be damaged.

Safety Instructions

When using headphones or earphones, do not turn the volume too high.

•Having the sound too loud may damage your hearing.

To avoid eyestrain, do not sit too close to the product.

Take a rest for at least five (5) minutes after using the monitor for one

(1) hour.

This reduces eye fatigue.

Do not install it in an unstable location such as an unstable rack or

uneven surface or a location exposed to vibrations.

• Otherwise, it may fall and cause personal injury and/or damage the

product.

• If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect the power

plug, antenna cable, and all the cables connected to the product.

•Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up onto the

product.

•The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect the

power cord from the power outlet.

• Otherwise, this may result in overheating or fire due to dust, and may

result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as cookies

etc. that may attract the attention of children and to the product.

• Your children may hang onto the product causing it to fall and this

may result in personal injury or death.

Be careful that children do not place the battery in their mouths when

removed from the remote control. Place the battery in a location that

children or infants cannot reach.

• If children have had the battery in their mouths, consult your doctor

immediately.

When replacing the battery, insert it with the right polarity (+, -).

• Otherwise, the battery may become damaged or it may cause fire,

personal injury or damage due to leakage of the internal liquid.

Safety Instructions

Use only the specified standardized batteries, and do not use a new

battery and a used battery at the same time.

• Otherwise, the batteries may be damaged or cause fire, personal in-

jury or damage due to a leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary refuse and

must be returned for recycling purposes. The customer is responsible for

returning the used or rechargeable batteries for recycling.

• The customer can return used or rechargeable batteries to a nearby

public recycling center or to a store selling the same type of the battery

or rechargeable battery.

Do not place the product in a location exposed to direct sunlight or

near any heat such as a fire or heater.

•This may reduce the lifetime of the product, and may result in fire.

Do not drop any objects onto the product or cause any impact to the

product.

•Otherwise, this may result in electric shock or fire.

Do not use a humidifier near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power plug;

ventilate immediately.

•If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display panel

becomes hot. Do not touch it.

Keep the small accessories in a location out of the reach of children.

Be careful when adjusting the angle of the product or the height of the

stand.

• This may result in personal injury as your hand or fingers may be-

come caught.

• Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children to

reach.

•Otherwise, it may fall and result in personal injury.

• Since the front part of the product is heavy, install the product on a

level and stable surface.

Safety Instructions

Do not put any heavy objects on the product.

•This may result in personal injury and/or damage to the product.

Precautions when handling the panel

Do not stand the product as shown in the image.

The panel is fragile and can get damaged.

Lay the product down to handle it as shown in the image.

(the packaging can be used).

Ensure you use the handles on the back when moving

the product.

Do not hold or grasp any area of the product within

15mm from the front.

Safety Instructions

Introduction

Package Contents

Checking the Contents of the Package

Remove the lock from the package box, as shown in the figure above.

Lift up the package box by

holding the grooves on both

sides of the package box.

Check the contents of the

package.

Remove the styrofoam and

vinyl cover.

Note

•After unpacking the package, make sure to check the contents of the package.

• Store the packaging box in case you need to move the product later.

• If any items are missing, contact your dealer.

• Contact a local dealer to purchase optional items.

Unpacking

LCD Display

Altri manuali per SyncMaster UD46A

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Monitor

Samsung

Samsung SyncMaster 710MP Manuale utente

Samsung

Samsung SyncMaster 940MG Manuale di installazione e funzionamento

Samsung

Samsung PL-50P5HD Manuale utente

Samsung

Samsung S24A40 Series Manuale utente

Samsung

Samsung C27HG70 Manuale utente

Samsung

Samsung T220HD - SyncMaster - 22" LCD Monitor Guida utente

Samsung

Samsung C27RG5 Series Manuale utente

Samsung

Samsung SyncMaster 2032GWPlus Manuale utente

Samsung

Samsung SyncMaster eX2020X Manuale utente

Samsung

Samsung SyncMaster 2443BW Manuale utente

Samsung

Samsung 820DXn - SyncMaster - 82" LCD Flat Panel... Manuale utente

Samsung

Samsung SyncMaster 151X Manuale utente

Samsung

Samsung SyncMaster Magic P2770H Manuale utente

Samsung

Samsung SyncMaster 220TN Manuale utente

Samsung

Samsung SyncMaster S20A350B Manuale utente

Samsung

Samsung S H85 Series Manuale utente

Samsung

Samsung SyncMaster 730XT Manuale utente

Samsung

Samsung S27CG55 Series Manuale utente

Samsung

Samsung 940MW - SyncMaster - 19" LCD Monitor Manuale utente

Samsung

Samsung LC24RG50FQRXXU Manuale utente

Samsung

Samsung SyncMaster 2043SNX Guida utente

Samsung

Samsung SyncMaster 570S TFT Manuale utente

Samsung

Samsung SyncMaster 323T Manuale utente

Samsung

Samsung SyncMaster 400BX Manuale utente

Manuali Monitor popolari di altre marche

Linear Acoustic

Linear Acoustic LQ-1000 Manuale utente

AOC

AOC I2579V Manuale utente

Gateway

Gateway FPD1520 Manuale utente

Furuno

Furuno Mu 120c Manuale utente

Asus

Asus VB171D - 17" LCD Monitor Manuale utente

Dell

Dell S2230MX Istruzioni utente

Philips

Philips 107C64 Manuale utente

Dell

Dell S2409WFP Manuale utente

EverFocus

EverFocus EN-7517E Manuale utente

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuale utente

Dell

Dell Precision 7680 Manuale di istruzioni

LG 50PM1M - - 50" Plasma Panel Manuale utente

Bosch

Bosch DDU 9 Manuale utente

Acer

Acer A231HL Manuale utente

Philips

Philips 86BDL4152T Manuale utente

NEC

NEC AccuSync LCD5V Manuale utente

Emay

Emay SleepO2 Manuale utente

IBM

IBM 6360 Istruzioni per l'installazione
