Samsung Yepp YP-T6H Manuale utente

Location of Controls

YP-T6 Quick Guide

Recording Button Play/Pause Button

Hold Switch

Loop Repeating Button

USB Cable

Connection Port

ENC Jack

Neck strap Hook

MENU, Navigation button/

Move to Track/Speed Search/

Volume Button

Display

Battery Cover

Earphone Jack

Microphone

Turning Power On and Off Playing Music

Pausing Music

●Power On : Press the button to turn on the power.

●Power Off : Press and hold the button to turn off the power. Press the button.

●Playback starts.

Press the button to pause playback.

●If no buttons are pressed within 10 seconds(changes depending on settings),

the yepp automatically powers off.

●While in Pause mode, briefly press again to resume playback.

Disconnecting the USB cable

After completing the file transfer, you must disconnect the cable in the following way:

4AH68-00000A (Rev 0.0)

1 Double-click on the green arrow in the

taskbar on the bottom right of the window.

2 When the [Stop a Hardware device] message appears,

press the [OK] button and disconnect the USB cable.

Downloading/Uploading files

●

The “WRITING/READING” message will appear during file download or upload.

Disconnecting the USB cable while “WRITING/READING” is displayed may cause

malfunction of the unit.

●

Files willl not necessarily play back in the order displayed in the Removable Disc in

Windows Explorer.

1 Connect the player to your PC with the supplied USB cable.

2 Open Windows Explorer on PC.

●Removable Disc is displayed in Windows Explorer.

3 Select the file to save and drag-and-drop it into the removable disk icon.

(Files will appear In numerical, alphabetical order)

●If you change the name of music files in Windows Explorer like 001* * * , 002* * *...,

music files will be played in the order of number indicated.

Connecting the USB cable

1Connect the USB cable to the USB port on the computer.

2Connect the other end of the USB cable to the USB cable connection port on

the bottom of the player.

● If you disconnect the USB cable from your PC while implementing a

command or initializing during USB driver installation, your PC may not

function correctly.

3The USB driver is installed with a message saying that it is searching for a

new device. You may not see the display screen during installation.

Go to the device manager to check that installation has been successfully

completed.

4Upon installation of the USB driver "Samsung yepp YP-T6 USB Device" will

appear in the [System Properties] ➝[Device Manager].

USB connect cable

➤Before connecting the player to PC, make sure to install USB driver.

Insert the Installation CD into the CD-ROM drive and then click [Install USB Driver].

Complete the installation by the instructions in the order as they appear in the windows.

Direct Connect USB Adaptor
