Samsung YP-20T - YEPP Digital Player Manuale utente

MP3 music file playback

Real time clock

4-mode equalizer

32MB Built-In Flash memory

Data transfer with USB

YP-20T

˙¥` ‚‚ (¿)-„`˙ 01.3.2010:58PM˘`2

What is MP3?

CD-quality sound.

MP3 refers to MPEG1 LAYER3. MP3 is a music file made of audio data from

compression technology with no degradation of the original sound.

“yepp’” is an advanced digital audio player which doesn’t need

a cassette tape or CD. You can download MP3 files

from the Internet or PC Communications and enjoy great sound

any time, any place.

FFeeaattuurreess

What is yepp’?

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`1

PREPARING FOR USE

LISENING TO THE SAMPLE MUSIC

SOFTWARE INSTALLATION AND OPERATION

CONTENTS Digital Sound-

Checking Parts..........................................................................................................4

Parts Description......................................................................................................5

Listening to music through yepp’

........................................................................7

Searching the MP3 files at a faster speed..............................................................9

Changing the Time/Date.........................................................................................11

Setting the Mode.....................................................................................................13

Using the Equalizer................................................................................................15

Hold Function..........................................................................................................16

Connecting yepp’

to PC.......................................................................................19

Installing software on PC.......................................................................................21

Installing USB Driver..............................................................................................23

Installing software on Mac.....................................................................................25

Formatting flash memory (PC)..............................................................................27

Listening to music on your PC..............................................................................28

Sending files to yepp’

PC.....................................................................................31

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`2

CREATING AND DELETING MP3 FILES

Making MP3 files from an audio CD......................................................................33

Deleting files...........................................................................................................35

Formatting flash memory (Mac)............................................................................36

Sending files to yepp’

(Mac)................................................................................37

Deleting files...........................................................................................................39

Safety Precautions.................................................................................................40

Troubleshooting.....................................................................................................41

Security....................................................................................................................42

Technical Specifications........................................................................................43

Safety Information..................................................................................................44

Warranty..................................................................................................................46

OTHERS

CONTENTS Digital Sound-

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`3

Player Software

Installation CD AAA alkaline

battery(1.5V)

User's Guide

User’s

Guide

Checking Parts Digital Sound-

yepp HolderEarphone PC connecting

USB port cable

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`4

Reverse button

(Volume Down)

LCD

Mode button

Play / Pause / Stop

button

Forward button

(Volume up)

Front Panel

Parts Description

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`5

2Insert the battery; paying

attention to the orientation of

the and ends of the

battery. Replace the battery

door.

1Remove the battery door

pushing on the thumb

recess in the direction of

the arrow.

Rear Panel Battery Installation

Earphone jack

Battery Cover

Lock

USB port

Battery Case

Digital Sound-

Main System

SAMSUNG

DIGITAL AUDIO PLAYER

YP-20T

SAMSUNG

DIGITAL AUDIO PLAYER

YP-20T

SAMSUNG

DIGITAL AUDIO PLAYER

YP-20T

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`6

SAMSUNG yepp

Insert the battery.

• Press the button once more while the

music that you selected is played back.

Then, appears on the display panel, and

the sound is paused for a moment.

Press the button again to resume playback.

Your yepp’ contains a few sample MP3 files. Insert the Battery in the Battery compartment,

and then connect the earphone correctly.

Turn on the Power

WHEN I DREAM.MP3

Press the button on

the front panel.

Playback

Listening to music through

Press the button

to start playback.

12/30 12:00P

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`7

Press the button.

Control volume with the volume

control button / .

Press the Stop button to stop

playback.

0:20

Volume can be controlled from 0 to 20.

Press to move up or down by 1 step.

Press and hold to move continuously.

Control Volume Stop Music

WHEN I DREAM.MP3

0:20

Digital Sound-

Stop mode will automatically revert to clock

mode ifno buttons are pressed for

1 minute.

Basic Function

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`8

Press the and buttons to move to the next track.

Searching the MP3 files at a faster speed

Reverse button Foward button

To search within a song being

played back:

0:20

0:59

Press and hold the button while a song is being played

back to fast forward. Release the button to resume playback.

Press and hold the button while a song is played back to

move quickly backward.

Yepp…‡‚ …› (¿)-„`˙ 01.3.2010:53PM˘`9
