Samsung YP-NEP32B Manuale utente

CD-quality sound.

MP3 refers to MPEG1 LAYER3. MP3 is a music file made of

audio data compression technology with no degradation of

the original sound.

yepp’ is an advanced digital audio player which doesn't need a

cassette tape or CD. You can download MP3 files from the Internet

or PC Communications and enjoy great sound any time, any place.

What is yepp’?

What is MP3?

English

Parts Description

Place to insert

SmartMedia Card

Remote controller jack

Connection cable terminal

Reverse

Forward Volume control

Stop/Power Off

Power On/

Play/Pause

HOLDHOLD

Hold switch

SMC Eject

Battery case

Headphone/Earphone port

Reverse

Forward

Power On/Play/Pause

Equalizer/Repeat

Hold switch

Select repeat

Stop/Power Off

Volume control

LCD panel

Listening to music through yepp’

Insert batteries into the battery compartment, and then

connect the remote controller (earphone) correctly.

Turn on the Power

Press the button on the yepp player or remote

controller.

Playback

Press the button on the yepp player or the remote

controller.

NNootteeTo pause playback, press the button the mark

blinks on the remote controller display panel. Press the

button again to resume playback. Every buttons

enable the lamp on the panel to blink for 3 seconds.

Control Volume

Control volume with the volume control button (-/+) on

your yepp player or remote controller.

NNootteeVolume can be controlled from 00 to 20. Press shortly to

move up or down by 1 step. Press and hold to move

continuously.

Stop Music

Press the STOP button ( ) of your yepp player or remote

controller to stop playing back sound.

NNootteeIf the unit is in the Stop mode for more than 3 minutes it

will power off automatically.

Searching the MP3 files at a faster speed

Press the and buttons too move to the next track.

To search within a song being played back

Press and hold the FF button ( ) while a song is being

played back to fast forward. Release the button to

resume playback.

NNootteePress and hold the REW ( ) button while a song is

being played back to move quickly backward.

To skip to the next song while another song is being

played back

Press the FF button to move one track forward.

To search a song in stop mode

1Press the FF button to move one track forward. To

play back the song that you chose, press the PLAY

button ( ).

2Press the REW button to move one track backward.

NNootteeIf the REW button is pressed before the first 5 seconds of

the track has played, the previous song will be repeated.

If the REW button is pressed after 5 seconds has played,

the current song will be repeated.

English

Hold Function

While the Hold switch on your yepp player is on

Buttons on the yepp won't work. Each time a button is

pressed, “Hold” will appear for a short time on the display

only the buttons on your remote controller will work.

While the Hold switch on your remote controller is on

The mark will appear on the display panel. None of

the buttons on your remote control will work. The buttons

on your yepp will work.

Repeating Tracks/Section

Press the “A

↔

B”button of your remote controller to

repeat the track or section that you selected. Setting 'Repeat

Track' needs a minimum of two seconds of play time.

1Press the A↔Bbutton of your remote control at the

start point of the track or section that you want to

repeat. Then, 'B' blinks on the display panel.

2Press this button again at the end point of the track or

section that you want to repeat.

NNootteeThe section from point A to point B that you selected will

automatically be repeated. To cancel this function, press

the A↔B button again. While tracks/sections are

repeated, the FF and REW buttons do not work.

Setting the Modes

Each time the EQ/REP button of your remote controller is

pressed and held, the modes will change in the order of

REP, ALL, SHU and INT.

◆REP mode : Repeats current track.

◆ALL mode : Repeats all the tracks.

◆SHU mode : Enables random playback.

◆INT mode : Enables you to repeat the first 10

seconds of the tracks saved (for 10

seconds each).

Using the Equalizer

Each time the EQ/REP button of your remote controller is

pressed, the equalizer modes will be changed in the

order of Classic, Jazz, Rock and Normal.

Normal mode is not indicated on the display.

Connecting yepp’to PC or Mac

1Connect the USB cable to the USB port of the computer.

2Turn the player on and connect the other end of the cable

to the download connector.

(YP-NEU)

(YP-NEP)

NNoottee

Be sure to install the yepp’Explorer before

connecting your yepp’to PC or Mac.

When the message “Add new hardware

wizard”appears on the screen, click

[Cancel] and then install the yepp’explorer.

English

Installing Software on PC

Insert the Installation CD into the CD-ROM drive.

The picture below appears when inserting the CD.

1Click

Click

2Click the next button on each successive window.

yepp’explorer

1Click

Click

2Click the next button on each successive window.

NNootteeInstall the other program or download the files

depending on your requirement.

RealJukebox

This software lets you listen to MP3 music on your

computer and enables you to encode your CDs into

MP3 Files.

Installing Software on PC (Windows 2000)

If USB port error occurs after installing the yepp’explorer

in Windows 2000, do the following steps 1~3.

1Copy the secypusb. sys file from the installation CD.

2Paste the secypusb. sys into 'Drivers' from the

system32 folder in Windows 2000 (System Root

Directory). (ex:/WinNT/system32/Drivers)

NNootteeEven though the secypub. sys file is present in the

existing folder, be sure to run Change File.

3Re-boot the computer.

Installing Software on Mac

Insert the Installation CD into the CD-ROM drive.

1Execute the yepp’explorer.

- Double-click the yepp’explorer icon.

2Click the button on each successive window.

- After all installations are complete, the yepp’

explorer folder is created.

Formatting flash memory (continued...)

yepp’explorer

1Execute the yepp’explorer.

- Double-click the icon of the yepp’explorer on the

desktop.

2Click [File], [Format] and select [Flash Memory].

NNoottee

- Before formatting the flash memory or the SmartMedia Card,

connect your yepp’to PC and click Refresh icon on the yepp’

explorer.

- If the optional SmartMedia Card is installed in the yepp’, file(s)

can also be saved to the card by clicking Copy to and selecting

Smart Media Card.

- You can also format the flash memory or the SmartMedia Card

by pressing the right button on the mouse and selecting

Format.

- Formatting Flash memory (or Smart Media Card) will delete all

existing files.

RealJukebox

1Connect your yepp’to PC and execute the RealJukebox.

2Click/Double-Click through the following items.

Devices -->Samsung Ne....

3Click Configure icon and Select Format_Flash_

Card/Format_Internal_Memory.

English

Formatting flash memory

NNoottee

- Before formatting the flash(SmartMedia) Card or the Internal

(flash) memory, press F5 Key to refresh. (Or click

View↔Refresh in the Main menu)

- Formatting Flash memory(or Smart Media Card) will delete all

existing files.

Mac

Execute the yepp’explorer.

- Double-click the yepp´explorer icon in the HDD.

2Click [File], [Format] and select [Flash Memory].

NNoottee

- Before formatting the flash memory or the SmartMedia Card,

connect your yepp´to PC and click Refresh icon on the yepp´

explorer.

- If the optional SmartMedia Card is installed in the yepp´, file(s)

can also be saved to the card by clicking [Copy to] and

selecting SmartMedia Card.

- Formatting Flash memory (or Smart Media Card) will delete all

existing files.

Options (continued...)

yepp’explorer

- Auto

The device has been initially set "Auto".

- ECP & USB

When the communication is not smooth in Auto, Select ECP

when using a parallel cable (YP-NEP) and USB when using an

USB cable (YP-NEU).

- Bidirection

For YP-NEP, if the communication Between your yepp' and PC

doesn't go smoothly, select the Bidirection mode.

- Select only for using YP-D40.

Options

RealJukebox (Installation of the USB driver)

1After installing RealJukebox, connect the yepp to the

PC.

2Execute RealJukebox.

3Click on Devices icon on RealJukebox screen.

4Select Install Device.

5Follow the on-screen instructions for RealJukebox.

Sending files to yepp’(continued...)

Before sending files to your yepp’, connect the yepp’to

PC and execute the RealJukebox.

yepp’explorer (YP-NEP/NEU)

1Turn on the yepp’by pressing .

2Execute the yepp’explorer.

- Double-click the icon of the yepp’explorer on the

desktop.

3Click the Refresh icon on the yepp’explorer.

4Click [Copy to] and [Flash Memory] or [SmartMedia

Card].

5Select the file you would like to send to your yepp’.

6Click [Open].

- The selected file has been saved. Now you can

listen to music with yepp’after removing the

parallel cable.

NNootteeThe yepp’uses around 1MB of memory for each minute of

music.

Sending files to yepp’(continued...)

RealJukebox (YP-NEU)

1Connect the yepp’to your PC.

2Turn on the yepp’by pressing .

3Execute RealJukebox.

- Double-click the RealJukebox icon on the desktop.

4Click/Double-Click through the following items.

Devices---> Samsung Ne....

5Press F5 Key to refresh.

6Click Internal Yepp.../Smart Media...

7Drag your selected file from your folder and drop into

Yepp.../Smart Media... window.

8Click the Begin Transfer icon, at the left side of the

RealJukebox window.

Sending files to yepp’(continued...)

Mac (YP-NEU)

1Connect the yepp’to your Mac.

2Turn on the yepp’by pressing .

3Execute the yepp’explorer.

- Double-click the yepp’explorer icon in the HDD.

4Click the [File] [Refresh] on the yepp’explorer.

5Click [Copy to] and [Flash Memory] or [SmartMedia

Card].

6Select the file you would like to send to your yepp’.

7Click [Open].

- The selected file has been saved. Now you can

listen to music with yepp’after removing the USB

cable.

English

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Lettore MP3

Samsung

Samsung YP-Z5 Manuale utente

Samsung

Samsung Napster YH-920GS Manuale utente

Samsung

Samsung YP-GI1CW Manuale utente

Samsung

Samsung YP-T5H - YEPP 128 MB Digital Player Manuale utente

Samsung

Samsung YEPP YP-Q1 Manuale utente

Samsung

Samsung YP-T5H YP-T5V YP-T5X YP-520H Manuale utente

Samsung

Samsung YP-T10 Manuale utente

Samsung

Samsung Wingo MY-MP200 Manuale utente

Samsung

Samsung YH-925GS Manuale utente

Samsung

Samsung YP-T10JABY Manuale utente

Samsung

Samsung YP-T7Z - 1 GB, Digital Player Manuale utente

Samsung

Samsung YP-U5JQ Manuale utente

Samsung

Samsung YP-P3CB Manuale utente

Samsung

Samsung YEPP YP-S3 Manuale utente

Samsung

Samsung YP-U5 Manuale utente

Samsung

Samsung YEPP YP-MT6 Manuale utente

Samsung

Samsung YP-60V - YEPP Sports 256 MB Digital Player Manuale utente

Samsung

Samsung YP-R0 Manuale utente

Samsung

Samsung YP-S5 Manuale utente

Samsung

Samsung YP-U6AB Istruzioni per l’uso

Samsung

Samsung YH-J70L Manuale utente

Samsung

Samsung YP-K3 Manuale utente

Samsung

Samsung YP-U7 Manuale utente

Samsung

Samsung YP-60H Manuale utente

Manuali Lettore MP3 popolari di altre marche

Blaupunkt

Blaupunkt Compact Drive MP3 Manuale utente

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuale utente

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuale utente

Naxa

Naxa NMV-173NX Manuale utente

Philips

Philips PSA250 Manuale utente

Zipy

Zipy go! Waving Manuale utente

Sylvania

Sylvania SMPK4068 Manuale utente

Sony

Sony NW-MS7 - Memory Stick Walkman Manuale utente

Irradio

Irradio RF-42UC Manuale utente

NABAIJI

NABAIJI SWIM MUSIC 100 Manuale utente

Laser

Laser MP3-A9-4GB Manuale utente

Savant

Savant SMS-1001-00 Guida di riferimento rapido

Trevi

Trevi XP 71 BT Manuale utente

AGPtek

AGPtek C2 Manuale utente

MobiBlu

MobiBlu DAH-1500i Manuale utente

Denver

Denver MPS-201 Manuale utente

Steren

Steren MP3-002 Manuale utente

Kenwood

Kenwood M1GD50 Manuale utente
