Samsung PN58B650S1F Guida rapida

2009 Samsung TV

F/W Upgrade Guide

Samsung Electronics

¾Model List

LCD TV

. LB650 series : LN40B650T1F, LN46B650T1F, LN55B650T1F, LN65B650X1F

. LB750 series : LN40B750U1F, LN46B750U1F, LN52B750U1F

PDP TV

. PB650 series : PN50B650S1F, PN58B650S1F

. PB850 series : PN50B850Y1F, PN58B850Y1F

Step1. How to prepare the USB Memory Drive

2. Connect the USB Memory Drive

to the USB port of your PC.

Copy the file into the USB Memory Drive.

3. Go to the USB Memory Drive and then double click the file.

1. Save the firmware file into your computer.

File Name : 2009 DTV 1G firmware.exe

4. Click on the “Unzip” button. 5. Unzipping is in progress.

6. After completing, click on the

“OK” and “Close” buttons.

7. A folder containing the firmware files

has been added to the USB memory drive.

Folder Name : T-CHEAUSC

8. Safely disconnect the USB memory drive

by right clicking the green check mark

on the taskbar and then left click

“Safely Remove”.

OK

9. Turn your TV on, and then insert

the USB Memory Drive containing

the firmware into the USB port

on the rear of the TV

※Important

If the firmware version you downloaded from the Samsung website

or received from Samsung is older than or has a lower version

number than the version on your TV, do not install it.

10. Press the MENU button to display

the menu. Press the ▲or ▼button

to select “Support”, then press the

ENTER button

11. Press the ▲or ▼button to select

“Software Upgrade”, then press the

ENTER button.

12. The message “Scanning for USB.

It may take up to 30 seconds”

is displayed.

13. Then, the message “Upgrade

Version XXXX to version XXXX?

The system will be reset after

upgrade.” is displayed.

Select “Yes”, then press the ENTER

button.

14. When the software upgrade is

complete; the TV will turn off and

then back on by itself.

Proceed with the ‘Plug & Play’

setup.

15. Once ‘Plug & Play’ is complete;

“Enjoy your watching.” is displayed.

Press the ‘Enter’ key and you are

done.

※Do not pull the USB drive out or

unplug the power cable until

complete

※Important

If the firmware version you downloaded from the Samsung website

or received from Samsung is older than or has a lower version

number than the version on your TV, do not install it.
