Samsung UN49M5300A Manuale utente

English - 7

01 TV Installation

Mounting the TV on a wall

If you mount this TV on a wall, follow the instructions exactly as set out by the manufacturer. Unless it is

correctly mounted, the TV may slide or fall and cause serious injury to a child or adult and serious damage

to the TV.

You can mount the TV on the wall using a wall mount kit (sold separately).

ǮɇͱЇϩ

bracket

׃Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you

choose to install the wall mount on your own.

׃To order the wall mount kit, contact Samsung Customer Care at 1-800-SAMSUNG (1-800-726-7864).

׃ǽͱЇʀɇϑϩɇцͱЇθиɇͱЇϩͱɇϑͱʒиɇΧʪθΧʪʒʀЇɇθϩͱϩ˵ʪѤͱͱθࢋ9ʪ˙ͱθʪɇϩϩɇʀ˵˝ϩ˵ʪиɇͱЇϩϩͱ

surfaces other than plaster board, contact your nearest dealer for additional information. If you install the TV on

a ceiling or slanted wall, it may fall and result in severe personal injury.

׃Ǯ˵ʪϑϩɇ˝ɇиɇͱЇϩϩࡡиʪθʪʀͱʪʒцͱЇ˙ɇϑϩʪɇ˙ͱЇθǤkƊϑʀθʪиϑࢋ

׃If you want to install a wall mount kit that attaches to the wall using two top screws only, be sure to use a

Samsung wall mount kit that supports this type of installation. (You may not be able to purchase this type of

wall mount kit, depending on the geographical region.)

׃Standard dimensions for wall mount kits are shown in the table below.

׃If you are installing a third-party wall mount, note that the length of the screws you can use to attach the TV to

the wall mount is shown in column C in the table below.

TV size in

inches

VESA screw hole specs

(A * B) in millimeters C (mm) Standard

Screw

Pitch

(mm) Quantity

49 200 x 200 20 - 21 M8 1.25 4

English - 12

Ǯ˵ʪцͱЇϩЇθͱцͱЇθƟǤ˙ͱθϩ˵ʪѣθϑϩϩʪࡡϩʪʒɇϩʪцϑϩɇθϩϑϩ˵ʪÃϩɇƊʪϩЇΧࢋFollow the instructions displayed

ͱϩ˵ʪϑʀθʪʪɇʒʀͱѣ˝Їθʪϩ˵ʪƟǤ࢒ϑɵɇϑʀϑʪϩϩ˝ϑϩͱϑЇϩцͱЇθЭʪи˝ʪЭθͱʪϩࢋ

Using the TV Controller

You can turn on the TV with the TV Controller button at the bottom of the TV, and then use the Control Menu. The

Control menu appears when the TV Controller is pressed while the TV is On. For more information about its usage,

θʪ˙ʪθϩͱϩ˵ʪѣ˝Їθʪɵʪͱиࢋ

TV Controller / Remote control sensor

Press: Move

Press & Hold: Select

The TV Controller is located on the bottom of

the TV.

: Power Off : Volume Up

: Channel Up : Volume Down

: Channel Down : Source

Control menu

03 Initial Setup

English - 16

05 ƊΧʪʀѣʀɇϩͱϑɇʒĮϩ˵ʪθÃ˙ͱθɇϩͱ

ƊΧʪʀѣʀɇϩͱϑ

Model Name UN49M5300A / UN49M530DA

Display Resolution 1920 x 1080

Screen Size

(Diagonal)

ߥߪ઎Aɇϑϑ

(48.5 measured diagonally)

Sound (Output) 20 Ǯ

Dimensions (W x H x D)

Body

With stand

44.0 x 25.6 x 2.9 inches

(1118.8 x 650.0 x 74.2 mm)

44.0 x 28.1 x 13.3 inches

(1118.8 x 714.1 x 337.5 mm)

Weight

Without Stand

With Stand

22.7 lbs (10.3 kg)

26.2 lbs (11.9 kg)

Environmental Considerations

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

50°F to 104°F (10°C to 40°C)

10% to 80%, non-condensing

-4°F to 113°F (-20°C to 45°C)

5% to 95%, non-condensing
