Vacuum Cleaner

user manual

Thank you for purchasing a Samsung product.

✻Please read the User Manual thoroughly before operating the vacuum.

✻For indoor use only.

SC07F70 Series

SC08F70 Series

SC20F70 Series

DJ68-00701A (EN)-07.indd 1 2014. 12. 19. �� 10:42

Contents

YOUR VACUUM CLEANER

BEFORE USING THE VACUUM

CLEANER

8 Assembly

9 Using the UV brush (Option)

9 Installing the Dust Sensor (Option)

10 Using accessory

OPERATING CLEANER

12 Power cord

12 Check ﬁlter

12 ON/OFF

13 Power control

14 Dust Sensor (Option)

MAINTENANCE

15 Cleaning the dust bin and grille

18 Cleaning the outlet ﬁlter

19 Maintain ﬂoor tools

TROUBLESHOOTING

PRODUCT FICHE

DJ68-00701A (EN)-07.indd 2 2014. 12. 19. �� 10:42

English - 3

Safety information

SAFETY INFORMATION

WARNING

• Before operating the appliance, please read this manual thoroughly and retain it

for your reference.

WARNING

• Because the following operating instructions cover various models, the

characteristics of your vacuum cleaner may differ slightly from those described in

this manual.

CAUTION/WARNING SYMBOLS USED

WARNING Indicates that a risk of death or serious injury exists.

CAUTION Indicates that a risk of personal injury or material damage exists.

OTHER SYMBOLS USED

Represents something you must NOT do.

Represents something you must follow.

Indicates that you must disconnect the power plug from the socket.

WARNING

This vacuum cleaner is designed for household use only.

Do not use this vacuum cleaner to clean building waste or debris.

Regularly keep the ﬁlters in clean conditions to prevent of collecting ﬁne dust in

them.

Do not use this vacuum cleaner with any of the ﬁlters removed.

Failure to meet these requirements could cause injury, damage the vacuum

cleaner and void your warranty.

DJ68-00701A (EN)-07.indd 3 2014. 12. 19. �� 10:42

English - 4

IMPORTANT SAFEGUARDS

GENERAL

• Read all instructions carefully. Before switching on, make sure

that the voltage of your electricity supply is the same as that

indicated on the rating plate on the bottom of the cleaner.

• WARNING : Do not use the vacuum cleaner when rug or ﬂoor is

wet. Do not use to suck up water.

• Close supervision is necessary when any appliance is used by

or near children. Do not allow the vacuum cleaner to be used

as a toy. Do not allow the vacuum cleaner to run unattended at

any time. Use the vacuum cleaner only for its intended use as

described in these instructions.

• Do not use the vacuum cleaner without a dust bin.

Empty the dust bin before it is full in order to maintain the best

efﬁciency.

• Do not use the vacuum cleaner to pick up matches, live ashes or

cigarette butts. Keep the vacuum cleaner away from stoves and

other heat sources. Heat can deform and discolour the plastic

parts of the unit.

• Avoid picking up hard, sharp objects with the vacuum cleaner as

they may damage the cleaner parts.

Do not stand on the hose assembly. Do not put weight on the

hose.

Do not block the suction or the exhaust port.

• Switch the vacuum cleaner off on the body of the machine

before unplugging from the electrical outlet. Disconnect the plug

from the electrical outlet before emptying the dust bin. To avoid

damage, please remove the plug by grasping the plug itself, not

by pulling on the cord.

• This appliance can be used by children aged from 8 years and

above and people with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

DJ68-00701A (EN)-07.indd 4 2014. 12. 19. �� 10:42

English - 5

Children shall not play with the appliance. Cleaning and user

maintenance shall not be done by children without supervision.

• Children should be supervised to ensure that they do not play

with the appliance.

• The plug must be removed from the socket outlet before

cleaning or maintaining the appliance.

• The use of an extension cord is not recommended.

• If your vacuum cleaner is not operating correctly, switch off the

power supply and consult an authorized service agent.

• If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualiﬁed person in

order to avoid a hazard.

• Don’t carry the vacuum cleaner by holding the hose.

Use the handle on the vacuum cleaner set.

• Unplug the cleaner when not in use.

Turn off the power switch before unplugging.

UV BRUSH

• Since the UV rays from the UV Brush damage skin and eyes,

never allow the rays to make contact with skin or eyes and

do not let children or the elderly use the UV Brush. If used

incorrectly it may cause damage to a persons eyesight.

• If the transparent window is broken and the UV rays are exposed

directly, turn the power off and contact the service center.

• Do not use the UV Brush for purposes other than the sterilization

of mattresses, bedclothes, beds, cushions and so on made from

material. The company will not be held liable for any loss due to

accidents from using the UV Brush for purposes other than its

original purpose as listed above.

• Do not sit on the UV Brush or drop it, and avoid imparting

impacts on the product. Failing to do so may result in injury or

product damage.

• Do not touch the power terminals on the back of the UV Brush

with a metal pin or rod. This may result in electric shock or ﬁre.

DJ68-00701A (EN)-07.indd 5 2014. 12. 19. �� 10:42

English - 6

• When the UV lamp is out of order, never disassemble or modify

the product yourself.

Please contact the manufacturer or service center for a

replacement.

• Since an internal discharge occurs within the UV Brush, never

use the product near an inﬂammable spray or substance.

• Take care not to touch the UV lamp window after using the

UV Brush for an extended period of time as the surface of the

window may be hot.

• The UV Brush may start slowly at a low temperature due to the

inherent characteristics of UV lamps. Please keep the UV Brush

indoors.

DJ68-00701A (EN)-07.indd 6 2014. 12. 19. �� 10:42

English - 7

YOUR VACUUM CLEANER

Your vacuum cleaner

Handle

Hose

Cyclone

Combination accessory

Pipe

2-Step brush

OPTION (Depending on model) *

SC20F70U / SC07F80U Series

Power turbo

plus *

Parquet

master *

Mini turbo *

2-Step brush * ECO Hard

ﬂoor*

Pipe * Handle *

ECO carpet* Cover battery *

Dust sensor * Furniture

brush *

UV brush *

2-in-1

accessory *

DJ68-00701A (EN)-07.indd 7 2014. 12. 19. �� 10:42

English - 8

ASSEMBLY

Connecting the Hose

Connecting the handle and pipe

Connecting the brush

Before using the vacuum cleaner

DJ68-00701A (EN)-07.indd 8 2014. 12. 19. �� 10:42

English - 9

BEFORE USING THE VACUUM CLEANER

USING THE UV BRUSH (OPTION)

Connecting the brush into the hose

handle

There will be a “clicking” sound when the UV

brush has been installed securely on the hose

handle.

For safety reasons, UV brushing only runs for 30 minutes and then stops operating.

To resume the operation, press the [BRUSH ON/OFF] button again.

CAUTION

The UV brush, which is assembled into the hose handle (not directly connected to

the pipe), is dedicated for bedclothes.

INSTALLING THE DUST SENSOR (OPTION)

Assemble the dust sensor

between the brush and the pipe

between the pipe and the hose

DJ68-00701A (EN)-07.indd 9 2014. 12. 19. �� 10:42

English - 10

USING ACCESSORY

Combination accessory (Option)

Dusting brush Crevice tool

Accessories (Option)

Install the accessory to the handle.

Dusting brush

Crevice tool

Dusting brush - For cleaning moldings, carved articles. etc.

Crevice tool - For cleaning in folds, crevices and corners.

DJ68-00701A (EN)-07.indd 10 2014. 12. 19. �� 10:42
