Samsung SC9210 Manuale utente

Operating Instructions

VACUUM CLEANER

❈Before operating this unit, please read the instructions carefully.

❈Indoor use only.

DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 2

DJ68-00208B REV(0.0)

IMPORTANT SAFEGUARDS

1. Read all instructions carefully. Before switching on, make sure that the voltage of your

electricity supply is the same as that indicated on the rating plate on the bottom of the

cleaner.

2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.

Do not use to suck up water.

3. Close supervision is necessary when any appliance is used by or near children. Do not

allow the vacuum cleaner to be used as a toy. Do not allow the vacuum cleaner to run

unattended at any time. Use the vacuum cleaner only for its intended use as described in

these instructions.

4. Do not use the vacuum cleaner without a dust bag(dust bin). Empty the dust bin before it

is full in order to maintain the best efficiency.

5. Do not use the vacuum cleaner to pick up matches,live ashes or cigarette butts. Keep the

vacuum cleaner away from stoves and other heat sources. Heat can deform and dis-

colour the plastic parts of the unit.

6. Avoid picking up hard,sharp objects with the vacuum cleaner as they may damage the

cleaner parts. Do not stand on the hose assembly. Do not put a weight on the hose. Do

not block the suction or the exhaust port.

7. Switch the vacuum cleaner off at the machine before unplugging from the electrical outlet.

Grasp the plug to disconnect cord from the electrical outlet before changing the dust bag.

8. The plug must be removed from the socket outlet before cleaning or maintaining the appli-

ance.

9. The use of an extension cord is not recommended.

10. If your vacuum cleaner is not operating correctly,switch off the power supply and consult

an authorized service agent.

11. If the supply cord is damaged, it must be replaced by the manufacturer or its service

agent or a similarly qualified person in order to avoid a hazard.

12. Don’t carry the vacuum cleaner by holding the hose.

Use the handle on the vacuum cleaner set.

DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 4

1ASSEMBLING THE CLEANER

Features may vary according to model.

▼

For storage, park the floor nozzle.

OPTION

DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 5

2OPERATING THE CLEANER

2-1 POWER CORD 2-2 ON/OFF SWITCH

(BODY-CONTROL TYPE ONLY)

2-3 POWER CONTROL

NOTE

When removing the

plug from the

electrical outlet,grasp the

plug,not the cord.

1)BODY-CONTROL TYPE

MIN = For delicate surface e.g. net curtains.

MAX = For hard floors and heavily soiled carpets.

INFRARED-CONTROL

Press control button repeatedly to select correct mode.

(STOP MIN MID MAX)

NOTE

If the cleaner is not working by handle-control you can operate the vacuum

cleaner with the CONTROL-BUTTON on the body.

2)REMOTE-CONTROL TYPE

DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 6

- TRANSPARENT TUBE

HARD FLOOR (OPTION)

CREVICE

DUSTING

UPHOLSTERY

PARQUET SPECIALIST (OPTION)

POWER PET (OPTION)

2-4 USING FLOOR TOOLS

DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 7

CHANGING THE DUST BAG

3LAMP SIGNALS

1)BODY-CONTROL TYPE

Check the Dust bag and change it.

(Check the Dust bin and empty it.)

2)REMOTE-CONTROL TYPE

Check the Dust bag and change it.

(Check the Dust bin and empty it.)

*LAMP SIGNALS

1. INDICATOR LAMP ON:

The dust bag is full, or the pipe is blocked.

2. POWER LAMP ON:

The power is applied to the vacuum cleaner

134

INDICATOR

LAMP

INDICATOR

LAMP

POWER

LAMP

OPTIONAL

●FOR CLOTH BAG

After using, if the cloth bag is full of dust, clean the cloth bag and use it again.

NOTE

Please make sure to retain the support-filter when you dispose of the dust bag.

NOTE

A used dust bag can be sealed by removing the paper from the adhesive strip and

sealing the strip over the hole.

DJ68-00208A(EN)REV(0.0) 5/16/03 11:46 AM Page 8

CLEANING THE CYCLONE FILTER (Optional)

1 2 3

4 5 6

NOTE

Use Cyclone Filter for the

best efficiency.

1 2 3

6-1 EMPTY THE DUST BIN

6CARING THE DUST BIN(OPTIONAL)

DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 9

4 5 6

OPTIONAL

You can rinse the bin with water.

Do not immerse the whole cleaner in water.

Ensure completely dry before replacing.

1 2 3

6-2 CLEANING THE GRILL

DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 10

7CHANGE THE BATTERY(OPTIONAL)

1)BATTERY TYPE : AA Size

WARNING

1. Never disassemble or recharge the batteries.

2. Never heat up the batteries or throw them into fire. 3. Do not reverse (+),(-) terminals.

4. Dispose the batteries properly.

NOTE

1. When the vacuum cleaner does not operate, replace the batter

ies. If the problem persists, please contact our authorized dealer.

2. 2 of Battery type

4 5

8CLEANING THE INLET FILTER

1234

NOTE :

Don’t throw away the filter

DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 11

9OUTLET FILTER

PROBLEM CAUSE REMEDY 0

- IF YOU HAVE A PROBLEM

Motor does not start.

No power supply.

Thermal cut-out.

Check cable, plug and socket.

Leave to cool.

Suction force is gradually

decreasing. Nozzle, suction hose or tube

is blocked. Check for blockage and

remove.

Cord does not rewind fully. Check that the cord is not

twisted or wound unevenly. Pull the cord out 2-3m and

push down the cord rewind

button.

Vacuum cleaner does not

pick up dirt.

Crack or hole in hose.

Check hose and replace if

required.

HEPA

FILTER(OPTION)

MICRO FILTER

NOTE :

Replacement filters or bags can be bought from your local Samsung distributor.

123

DJ68-00208A(EN)REV(0.0) 5/16/03 11:47 AM Page 12
