BEFORE USING THE WASHER

CAUTIONS

PRECAUTIONS WHEN OPERATING

 In case of pump drained washer,

remove the cap-hose from

the drain hole.

 B e s ure that the was her is grounded.

To avoid electrical shock,use

a metal pipe for the ground

connection. B ut, don't ground

the washer with gas pipes or

telephone lines to avoid to

dangers of explosion or lightning strike.

 Do not put your hands into the s pin

dryer bas ket when it is s pinning.

Your fingers can be caught

by spinning laundry and

damaged.

 Ventilation opnning must not be obstructed

by carpeting when the washing machine is

installed on a carpeted floor.

 If the supply cord of this appliance is damaged,

it must only be replaced by a repair shop

appointed by the manufacturer,because

special purpose tools are required.

 To avoid overfilling and damages this appliance

must be filled with the operator present us ing a

moderate water supply pressure only.

 Never allow children to operate

or play with the was her.

C hildren playing with the was her

may accidentally fall into the

was hing tub.

 B e s ure to c over with the inner

cover on laundry before s pinning.

This prevents laundry from

being tos s ed out and damaged.

 B efore was hing,check all poc kets .

If nails or pins remain in pockets,they may

damage the was her or clothes.

 C los e the water tap a little if the

water pres s ure is too high.

 To avoid water s plas hes ,

clos e the was h tub lid.

 B e s ure lay the drain hos e down

(in cas e no drain pump)

 Never s plas h water on the control panel.

 Dis connect the power cord from the

power s upply when not in us e.

 Don't us e exces s ively hot water.

(50ûC or more)

P las tic parts may be deformed or damaged.

Also, clothing may be deformed or decolored.

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 1

DESCRIPTION OF PARTS

INNE R L ID

When you open this lid while

the spin basket is spinning,

the spinning will be stopped

by breake system.

P OWE R C OR D

WATE R DR AIN HOS E

(W IT HOUT P UMP )

DR A IN HOS E

(W IT H P UMP )

S P IN DR Y E R

B AS K E T

WA S H TUB L ID

Be sure to keep the lid

closed during washing

and spinning.

OV E R F L OW

FILTE R

S TR A INE R (F ILTE R )

WA S H T UB

P UL S ATOR

DR AIN FILTE R

(with pump)

The plugÕs shape may not

correspond with this drawing.

1.WAS H TIME R

This is used to set the wash time, 1-15 minutes.

2.C Y C L E S E L E C TOR

This is used to select the Washing /

R insing or draining

3. S P IN DR Y T IME R

This is used to set the spin time, 1-5 minutes.

4.WAT E R S E L E C TOR (FOR B TY P E )

During washing,WATE R S E LE C TOR K NOB should

be selected to wash.During spin rinsing,WAT E R

S E LE C TOR K NOB should be selected to spin.

CONTROL PANEL

S P IN DR Y E R L ID

F OR A T Y P E

F OR B T YP E

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 2

WASHING PROCEDURE

S P IN DR Y

1. B efore s tarting was hing, check the following;

C onnect the water supply hose and open the water tap.

- Lay the drain hose down toward a sinkhole.

(In case no drain pump)

- Place the drain hose in sink or bath.

(In case drain pump)

-C onnect the power cord to the power supply outlet .

2. S et the C Y C L E S E L E C TOR K NOB to

‘WAS H  R INS E . (in case drain pump “WAS H )

4. F ill water in the was h tub

and add the detergent.

5. L oad laundry in the

was h tub and fill

water to H high

water level.

6. S et the WAS H TIME R 1-15minutes .

7. After was hing,s et the

C Y C L E S E L E C TOR K NOB

to ÔDR AINÕfor drain.

1. Trans fer the clothes into the s pin bas ket

and arrange the clothes evenly. 3. C los e the s pin dryer lid.

4. S et the S P IN DR Y TIME R 1-5minutes .2. B e s ure to attach the s afety cover and

clos e the inner lid.

inner lid

safty cover

3. S et the WATE R S E L E C TOR

K NOB to WAS H .

TO WAS H

F OR B T YP E

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 3

“‘

‘

ADDITIONAL R INS E

S et the WATE R S E LE C TOR K NOB to

S P IN and C Y C LE

S E LE C TOR K NOB to

ÔDR AINÕ.

R INS ING

OV E R F L OW R INS E

1. S et the C Y C L E S E L E C TOR K NOB to

WAS H R INS E (In case drain pump “WAS H )

2. S upply the proper amount of water

as not to overflow the top of the

was hing tub.

3. S et the WAS H TIME R

2~3minutes .

3.As s oon as the WAS H TIME R

s huts off, turn off the water tap.

1.K eep s uppling water

4. Drain the water.

S et the C Y C L E

S E L E C TOR

K NOB to DR AIN

5.R epeat this cycle until drain water

is clean. (2~3 cycle)

2.S et the WAS H

TIME R 6~8minutes . 4. S et the C Y C L E

S E L E C TOR K NOB

to ÔDR AINÕ.

inner lid

safety cover

After rinsing you can select this

course for more effective rinse

(Don't select only this course

for rinse.) Load the laundry

evenly into the spin basket.

S upply water for about 1minute.

Adjust the water flow to prevent

overflow from the wash tub.

After stopping water

supply, cover the

laundry with safety cover

and close the inner lid.

C lose the spin dryer

lid.

S et the S P IN DR Y

TIME R 2~3 minutes.

(Without pump) (with pump)

Adjust water pressure to ensure

that the amount of water supplied

does not exceed that water drained.

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 4

‘

“

‘

C ONNE C T ING THE DR AIN HOS E

INSTALLATION

L eave s ome s pac e

S pace at last 15cm between the washer

and the wall.

P lace the was her on a s turdy flat s urface.

If the washer is placed on an uneven or weak

surface, noise or vibration may be occured.

(Allowable is 2û)

Never ins tall the was her near water.

Do not place the washer in s teamy rooms or

where the washer is directly exposed to rain.

Moisture may destroy the electrical insulation

and cause an electrical shock hazard.

Avoid direct s unlight or heating devic es .

As plastic and electrical components are

affected by direct heat, never place the

washer near heaters, boilers ,etc.

Do not place under direct s unlight.

CLEANING THE MACHINE

E NV IR ONME NT

1. OV E R F L OW F ILT E R

P ull the upper s ide of the

overflow filter with

your fingers into the holes

in the direction of arrow as

shown in the figure.

2. C L E A NING T HE F ILT E R

P ush the strainer(filter) out and take up the

filter as shown in figure.

Wash the filter and washing tub.

3. C L E A NING THE WAS HE R B ODY

Wipe off strains on the cabinet and operation panel with s oft cloth.

Do not use benzene,thinners,cleanser,or wax, nor s crub the was her with a brush.

P ainted surfaces or plastic parts will be damaged.

P lace a rag under the washer filter

not to wet the floor.

R otate the filter counterclockwise

and pull out the filter.

3. R emove dirts and rotate

the filter clockwise until it

locks in pos ition.

HOW TO C L E A N T HE F ILT E R (In case drain pump)

Ins tall the drain hos e about

70~80cm above the ground

for pump model.

After pres s ing the joint ring(a), insert the drain hose(b)

to drain direction.

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 5

TR OUB L E

The was her

does not work.

C lothes will

not move freely.

Incomplete

s pinning

TR OUB L E

Incomplete

draining

The s pin dryer

bas ket will not

run.

C HE C K P OINT

C hec k that the power cord is

connected to a power outlet well.

P ower s toppage?

Is the laundry overloaded?

Are the laundry arranged evenly?

WAS HING TIME

LAUNDRY GUIDE

MAINTENANCE

TROUBLE SHOOTING

S P IN DRY T IME

DE TE R G E NT

WHE N Y OU L OA D THE L A UNDRY INTO

THE S P IN B AS K E T.

P ress the laundry evenly and put the safety

cover into the spin basket drum as shown in

the figure.

K INDS OF C L OTHING

E xtremely solid heavy fabric

Linen,cotton,etc.

Ordinary clothes

(underwear,etc)

S lightly solied synthetic

fiber

100%wool,mixed wool knitting,

thin synthetic fiber with tags

indicating hand washing

WAS HING T IME

10 to15minutes

8 to10minutes

7minutes

2 to 5minutes

TIME

1min.

1~2min.

3~5min.

5min.

T YP E OF L A UNDR Y

Thin(synthetic fiber)

wool

cotton

thick(cotton)

In case the water level is at High ,

amount of water is 42l.

-H-

Follow the directions printed on the

package for amount of detergent.

C hoos e the amount of detergent

depending on the fabric type and

water level.

C HE C K POINT

Is thefilter clogged

with lint?

S ee ÒC leaning the

machineÓon page 5.

Is the s pin dryer lid clos ed

completely?

Are laundry(s ocks ,etc.)falling

out of the s pin dryer bas ket and

clinging to the axle?



S ee ÒT o pic k out...Ó

on page 6.

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 6

‘

B efore operating the unit, please read this manual throughly,

and retain for future reference.

B E F OR E US ING THE WAS HE R 1

C AUT IONS 1

P R E C AUTIONS W HE N OP E R ATING 1

DE S C R IP TION OF PA R T S 2

C ONT R OL PA NE L 2

WA S HING P R OC E DUR E 3

TO WAS H 3

S P IN DR Y 3

R INS ING 4

OV E R F L OW R INS E 4

ADDIT IONAL R INS E 4

INS TA L L AT ION 5

E NV IR ONME NT 5

HO W T O C L E AN T HE F ILT E R 5

C ONNE C T ING DR AIN HOS E 5

C L E ANING T HE MA C HINE 5

L A UNDR Y G UIDE 6

MAINTE NA NC E 6

TR OUB L E S HOOT ING 6

S P E C IF IC AT IONS

Owner's Ins tructions

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 7

W715mmxD430mmxH870mm

0.05~0.78 MPa

0.5 ~ 8.0 kg.f/cm2

60 %

42 l

Washing : 3.8 kg S pinning : 3.8 kg

Washing : 280 W S pinning : 110 W

350 W

Washing 1Hour S pinning 15minutes

IF Y OU NE E D HE L P.

Do not hes itate to call your local s amsung service center.

They will be willing to help you.

B e sure to give them your name,address ,telephone number and the purpose of the call.

S P E C IF IC AT ION

DIME NS IONS (mm)

WAT E R P R E S S UR E

WE IG HT

E XTR AC TION E F F IC IE NC Y

S TA NDA R D QUANT ITY OF WAT E R

NOMA L C APA C IT Y

MOTOR INP UT

MOTOR MA X INP UT

R AT ING T IME

With out pump 19kg With pump 21kg

DC 68-01282A

SWT60H1-gbEq-01282A 22/09/03 7:50 PM Page 8

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Samsung Rondella

Samsung

Samsung WF602W2BD Series Manuale utente

Samsung

Samsung WA422PRHDWR/AA Manuale utente

Samsung

Samsung WF218ANB Manuale utente

Samsung

Samsung SW51ASP Manuale utente

Samsung

Samsung WA10F5S4 Manuale utente

Samsung

Samsung WF210 series Manuale utente

Samsung

Samsung WF219ANW/XAA Manuale utente

Samsung

Samsung WF9904RWE Manuale utente

Samsung

Samsung WW11B Series Manuale utente

Samsung

Samsung WW70K5 Series Manuale utente

Samsung

Samsung WF1802LSW2 Manuale utente

Samsung

Samsung WF42H5700A Series Manuale utente

Samsung

Samsung WA11CG5745 Series Manuale utente

Samsung

Samsung WF45H6300 Manuale utente

Samsung

Samsung WA62H3H3 Manuale utente

Samsung

Samsung WA44A32 A Series Manuale utente

Samsung

Samsung WF511ABR/XAA Manuale utente

Samsung

Samsung WF8600NGA Manuale utente

Samsung

Samsung WW80J5 Series Manuale utente

Samsung

Samsung WD22T6300 Series Manuale utente

Samsung

Samsung WF393BTPAWR/A1-0001 Manuale utente

Samsung

Samsung WD22T6500 Series Manuale utente

Samsung

Samsung DC68-02657F Manuale utente

Samsung

Samsung LDD1PA2DU24 Series Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
