Sandstrom SSP21BT19 Manuale utente
Bluetooth®
2.1 Speaker System
Instruction Manual
SSP21BT19
Contents
Safety Warnings..................................................................................................................................... 4
Unpacking..............................................................................................................................................5
Product Overview..................................................................................................................................6
Front & Side View...............................................................................................................................................................6
Rear View ..............................................................................................................................................................................6
Connections ...........................................................................................................................................7
Connecting Speakers .......................................................................................................................................................7
Connecting the Power .....................................................................................................................................................7
General Operation................................................................................................................................. 8
Powering ON/OFF..............................................................................................................................................................8
Adjusting the Volume.......................................................................................................................................................8
Energy Saving Function ........................................................................................................................ 8
Bluetooth Pairing ..................................................................................................................................8
AUX Operation.......................................................................................................................................9
Maintenance ..........................................................................................................................................9
Hints and Tips ......................................................................................................................................10
Specications.......................................................................................................................................10
Safety Warnings
Read all instructions before using these speakers and keep them for future reference.
• Use only voltage specied on the rating label of the speaker.
• Do not place speakers close to heat sources, such as radiators and heaters.
• These speakers are intended for household use only and not for commercial or industrial use.
• Use these speakers only as described in this manual. Any other use is not recommended by the
manufacturer and may cause re, electric shock or injury.
• Always operate on a at horizontal surface. Do not place the speakers on an unstable table, stand,
tripod or bracket.
• If the mains cable is damaged, it must be replaced by a qualied electrician in order to avoid a
hazard.
• Do not use these speakers outdoors, or on wet surfaces. Avoid spilling liquid on the speakers. Keep
the speakers dry and avoid contact with damp or wet areas.
• Do not block the openings in the speaker cabinets, never push objects into the speaker vents or
slots because of re or electric shock hazards, and provide sucient space around the speakers for
proper ventilation.
• Only use attachments/accessories specied by the manufacturer.
• For added protection during lighting storms, unplug the speakers from the mains socket and turn
o the computer.
• Unplug the speakers when not in use for a long period of time.
• Do not expose these speakers to rain or moisture to reduce the risk of electric shock.
• Place the speakers away from strong electromagnetic environments.
• These speakers are not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the speakers by a person responsible for their
safety.
• Children should be supervised to ensure that they do not play with the speakers.
• This appliance is intended for normal indoor, household use only.
5
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction manual in order
that you fully understand all the operational features it oers. You will also nd some
hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual
for future reference.
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0344 800 3456 for assistance.
Subwoofer Speaker x 2
3.5mm to 3.5mm
Stereo Audio Cable
Instruction Manual
Instruction
Manual
6
VOLUME
Product Overview
Front & Side View
1
1
2
3
2
ON
OFF
R
AUDIO OUTPUT
AUDIO INPUT
L
Rear View
1. Volume Control
Adjust the volume.
2. LED Indicator
1. Audio Input Sockets
Connect to your audio device.
2. Audio Output Socket (L/R)
L - Connects to the left speaker,
R - Connects to the right speaker.
3. On/O Button
Switch the unit on/o
4. Power Cord
7
Connections
Ensure all system and devices are turned o before connecting any cables.
Connecting Speakers
Connect the speaker cables at the back of the speakers to the AUDIO OUTPUT (L/R)
sockets at the side of the subwoofer.
ON
OFF
R
AUDIO OUTPUT
AUDIO INPUT
L
Connecting the Power
• This unit is designed to operate with an AC power supply.
• Connecting the unit to any other power source may cause
damage to the unit. Unwind the mains cable to its full length.
Connect the mains plug to a mains socket. Make sure the mains
plug is fully inserted into the mains socket. The unit is now
connected and ready to use.
• To switch the unit o completely, switch ON/OFF to the OFF
position or unplug the mains plug from the mains socket.
8
General Operation
Powering ON/OFF
When you rst connect the unit to the mains socket, the unit will be in OFF mode.
• Press the ON/OFF button to switch the unit to ON mode. The LED indicator will light up
blue.
• Press the ON/OFF button to switch the unit to OFF mode. The LED indicator will turn o.
Adjusting the Volume
Turn the Volume Control to adjust the volume.
Energy Saving Function
After approximately 15 minutes of not receiving an input signal, it will enter to energy
saving mode (the LED indicator will light up red and the unit will stop working). The unit
will wake up by pressing the Volume Control.
If you do not use the unit for longer periods of time, switch the ON/OFF switch
into the OFF position to save energy.
• The unit will exit pairing mode if no Bluetooth device is paired within 5
minutes.
• If the unit is already paired with a Bluetooth device before, it will
automatically connect with the last paired device when both are in pairing
mode.
Bluetooth Pairing
1. Press the ON/O button to switch on the unit, it will enter pairing mode automatically.
The LED indicator will ash in blue rapidly.
2. Activate the Bluetooth feature on your Bluetooth device and start searching. Then select
“SSP21BT19”.
3. If necessary, enter the passcode, “0000”, to pair and connect the earphones. Some device
also ask to conrm the headset connection after paring.
4. The LED indicator will light up blue after you have successfully paired.
9
ON
OFF
R
AUDIO OUTPUT
AUDIO INPUT
L
AUX Operation
1. Adjust the volume to minimum rst to avoid the voice is over.
2. Use a 3.5mm to 3.5mm stereo audio cable to connect your PC or other audio device to
the subwoofer’s AUDIO INPUT socket.
3. Adjust the volume to your desired level by turning the volume control.
4. Check that your device’s volume level is sucient.
Ensure the unit is fully unplugged from the computer before cleaning.
Maintenance
• To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray aerosol at or near the unit.
10
Specications
Model SSP21BT19
Power Supply AC 100-240V ~50/60Hz 300mA
Output Power Subwoofer 16 W
Speakers 7 W x 2
Frequency Band(s) 2404 – 2482 MHz
Max. Radio Frequency
Power Transmitted
4 dBm
Dimension (L x W x H) Subwoofer 223 x 157 x 241 mm
Speaker (1 pc) 60 x 86 x 143 mm
Net Weight Subwoofer 1.83 kg
Speakers 0.23 kg x 2
Features and specications are subject to change without prior notice.
If any functional abnormality is encountered, unplug the unit from the mains
socket and reconnect it again.
Hints and Tips
If a problem does occur, it may often be due to something very minor. The following table
contains various tips.
Issue Cause / Solution
No power • Make sure the mains plug is fully inserted into the mains
socket.
• Make sure that the ON mode is selected.
No Sound • Adjust the volume dial, it may not be turned up.
• Check the unit is fully connected.
• Check your computer is not united.
Static Sound • Another device may be interfering with the unit. Move the
device away from the unit.
I cannot find
“SSP21BT19” on my
Bluetooth® device
• Ensure the Bluetooth® function is activated on your
Bluetooth® device.
• Re-pair the unit with your Bluetooth® device.
