Sandstrom S3MPWC10 Manuale utente
3MP ALUMINIUM
WEBCAM
Quick Start Guide
A30BWCB09
Aluminium HD Webcam
S3MPWC10
Instruction Manual
Congratulations on the purchase of your new Sandstrøm
Aluminium HD Webcam.
Before commencing the installation and set up, please check that you
have all the items and familarise yourself with this Instruction Manual.
UNPACKING
Webcam
GB-2
Application Disc
(P.N.: 2D1-HP30AW-D0161)
Remove all packaging from the unit. Retain the packaging. If you dispose of it
please do so according to local regulations.
The following items are included:
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0844 800 3456 for assistance.
SYSTEM REQUIREMENTS
Hardware:
• 1 Available USB port
• 1 Available CD-ROM drive
• Windows compatible sound card
and speakers
• 500MB free hard disk space
Operation System:
• Microsoft®Windows®XP SP2 /
2000 / Vista™ & Windows®7
PRODUCT OVERVIEW
Auto Focus Lens
Webcam stand
GB-3
Microphone
1. If your system is Windows XP Service
Pack I, please go to www.microsoft.com
to update your system to Windows XP
Service Pack II.
2. Please ensure you have Windows Media
Player Version 9 or above prior using
the bundled software ArcSoft WebCam
Companion 3.0.
INSTALLATION
GB-4
ArcSoft WebCam Companion 3.0
1. In the main menu of the CD disc, select and
click on ArcSoft WebCompanion 3.
2. Select the language for this installation
and click OK to confirm.
3. Click Next and follow the instructions to
continue the installation.
4. Click Finish to complete the installation.
Insert the application disc into the CD-ROM.
The main menu of the CD will display on the
screen:
GB-5
ArcSoft Magic-i
1. In the main menu of the CD disc, select and
click on
ArcSoft Magic-i.
2
.
Select the language for this installation
and click OK to confirm.
3. Click Next and follow the instructions to
continue the installation.
4.When bonus offers page appears you can
select the free and intro products that you
would like to download and install or click
Skip to skip it.
5.Click Finish to complete the installation.
Plug the webcam into a USB port.
SET UP AND MOUNTING THE WEBCAM
GB-6
GB-7
1. Click on the “WebCam Companion 3” icon on the
desktop.
2. Click “Capture”.
3. Click “Capture” for capture image.
5. Click “Record Video” for recording.
4.Click “Burst” for sequential image
capture (5 images).
SNAPSHOT BY ARCSOFT WEBCAM COMPANION 3.0
SPECIFICATION
Model: S3MPWC10
Image Sensor: 3-MP CMOS Sensor
Lens Specification: F2.8, f=3.85mm, 4P, Auto Focus Lens
White Balance: Auto
Exposure: Auto
Frame Rate: Up to 30-frames-per-second video
Focus Range: Auto focus, 10cm to infinity
Depth of Field: 10cm to infinity
PC Interface: USB2.0
Video Format: WMV / MPG
Audio: Built-in microphone
Video Capture Res.: 640 x 480 pixels/ 352 x 288 pixels
Still Capture Res.: Up to 12M pixels (interpolated by software)
Bundled Software: Arcsoft WebCam Companion 3.0
Arcsoft Magic-i
GB-8
Features and specifications are subject to change without prior notice.
Windows is a registered trademark of Microsoft Corporation in the United
States and other countries.
(P.N.: 2D1-HP30AW-D0161)
This symbol on the product or in the instructions means that your electrical and
electronic equipment should be disposed at the end of its life separately from your
household waste. There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where you
purchased the product.
Visit Partmaster.co.uk today for the easiest way to buy electrical
spares and accessories. With over 1 million spares and accesso-
ries available we can deliver direct to your door the very next
day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK
customers only) Calls charged at National Rate.
DSG Retail Ltd. • Maylands Avenue Hemel Hempstead • Hertfordshire HP2 7TG England
