Swift BT Speaker User Manual
INTRODUCTION
Thank you for purchasing the Swift BT Speaker. The speaker is a high quality wireless audio device that
provides users the freedom to share music and calls whenever you want.
OVERVIEW
The Speaker contains the following parts as show in the figure:
1. Multi-function button (MFB)
2. LED light
3. USB charging port
4. On/Off Button
5. Microphone
OPERATION
1. Turn on: When the speaker is in the OFF state, switch the On/Off Button to “ON” and the LED will flash
with a blue light along with an audible tone.
2. Turn off: When the speaker is in the ON state, switch the On/Off Button to “OFF” and the LED will flash
with a red light along with an audible tone.
3. Pairing: When the speaker is in the ON state, press the MFB button for about 6 seconds until the LED
flashes blue and red. The speaker is now in the pairing mode. Go to your device’s Bluetooth settings and
select the speaker and enter “0000” for the passcode.
- Answer a call: press the MFB once
- Reject an incoming call: press and hold the MFB for 2 seconds
- End a call: Press the MFB once
- Redial last number: Press the MFB for about 3 seconds when on standby mode
- Voice dialing: It is possible to make a call directly from the headset using voice recognition. To use this
voice dialing function, your mobile phone must support this option: enable voice recognition on your
phone; when no call is in progress, press and hold the MFB.
- Voice transfer: During a call, press and hold the MFB for about 3 seconds until a beep is heard from the
speaker. The call will be transferred from the speaker to your phone or vice versa.
- Muting: Mute the built-in microphone by double pressing the MFB.
- Support for A2DP / No support for AVRCP: Some phones may not support Bluetooth AVRCP which
allows some of these MFB functions to perform; Bluetooth A2DP only allows for audio to be transmitted.
SPECIFICATIONS
- Bluetooth Specification: v3.0 Class 2
- Bluetooth Profiles supported: HSP v1.2, HFP v1.5, A2DP v1.2
- RF Frequency Range: 2.402 –2.480GHz, 2.4G ISM Band
- Radio Performance: Receive Sensitivity of -90dBm, TX Power Max 4dBm
- Wireless Range: up to 32’
- 2W Speaker Output Level: 80dB @0.5m
- Built-in noise cancelling Microphone
- Rechargeable 400mAh Li-Polymer Battery
- Charging Adapter Output: DC 5V –200mA
- Nominal Charging Time : 2 hours max
- Talk Time: Up to 4 hours
- Playback Time: Up to 3 hours
- Standby Time: Up to 300 hours
- Operating Tempterature: 14°F ~ 122°F
- Storage Tempterature: -4°F ~ 176°F
TROUBLESHOOTING
If you cannot connect the speaker to your phone, try the following:
- Ensure that the speaker is charged, switched on, paired and connected to your phone.
- Ensure that the Bluetooth feature is activated on your phone.
- Ensure that the speaker is within 30 feet of your phone and that there are no obstructions between the
headset and the phone, such as walls or other electronic devices.
If no pairing is made over a period of time, the Bluetooth speaker will retreat from pairing mode. You have to
turn the speaker off and start over.
BATTERY INFORMATION
The speaker is powered by a rechargeable battery. The full performance of a new battery is achieved only
after two or three complete charge and discharge cycles. The battery can be charged and discharged
hundreds of times, but it will eventually wear out.
Unplug the charger from the electrical plug and the device when not in use. Do not leave a fully charged
battery connected to a charger, since overcharging may shorten its lifetime. If left unused, a fully charged
battery will lose its charge over time.
Leaving the device in hot or cold places, such as in a closed car in summer or winter, will reduce the
capacity and lifetime of the battery. Always try to keep the battery between 59°F and 77°F. A device with a
hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is
particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also explode if damaged. Dispose
of batteries according to local regulations. Please recycle when possible. Do not dispose as household
waste.
CARE & MAINTENANCE
The speaker is a product of superior design and craftsmanship and should be treated with care. The
suggestions below will help you protect your warranty coverage.
- Keep all accessories and enhancements out of reach from small children.
- Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that
will corrode electronic circuits. If your device does gets wet, allow it to dry completely.
- Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can be
damaged.
- Do not store the device in hot areas. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
- Do not store the device in cold areas. When the device returns to its normal temperature, moisture can
form inside the device and damage electronic circuit boards.
- Do not drop, knock, or shake the device. Rough handling can break internal circuit boards and fine
mechanics.
- Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device.
- Do not paint the device. Paint can clog the moving parts and prevent proper operation.
All of the above suggestions apply equally to your device, battery, charger, or any enhancement. If the
speaker is not working properly, take it to the nearest authorized service facility.
