Savin 2027 Manuale di servizio

Printer/Scanner Unit

Type 2027

Operating Instructions

Printer Reference 2

For safe and correct use of this machine, please be sure to read the Safety Information in the

"General Settings Guide" before you use it.

Setting Up the Printer Driver and Canceling a Print Job

Using the Document Server

Sample Print/Locked Print

Troubleshooting

Printer Features

Appendix

Introduction

This manual describes detailed instructions on the operation and notes about the use of this machine.

To get maximum versatility from this machine all operators are requested to read this manual carefully

and follow the instructions. Please keep this manual in a handy place near the machine.

Important

Contents of this manual are subject to change without prior notice. In no event will the company be li-

able for direct, indirect, special, incidental, or consequential damages as a result of handling or oper-

ating the machine.

Warning:

Use of controls or adjustment or performance of procedures other than those specified in this manual

might result in hazardous radiation exposure.

Trademarks

Microsoft®, Windows®and Windows NT®are registered trademarks of Microsoft Corporation in the

United States and/or other countries.

Adobe®, PostScript®, Acrobat®are registered trademarks of Adobe Systems Incorporated.

PCL®is a registered trademark of Hewlett-Packard Company.

AppleTalk, Apple, Macintosh and Mac are registered trademarks of Apple Computer, Incorporated.

served.

UNIX is a registered trademark in the United States and other countries, licensed exclusively through

X/Open Company Limited.

Bluetooth is a Trademark of the Bluetooth SIG, Inc. (Special Interest Group) and licensed to RICOH

company limited.

The Bluetooth Trademarks are owned by Bluetooth SIG, Inc. USA

Other product names used herein are for identification purposes only and might be trademarks of their

respective companies. We disclaim any and all rights in those marks.

The proper names of the Windows operating systems are as follows:

• The product name of Windows®95 is Microsoft®Windows®95

• The product name of Windows®98 is Microsoft®Windows®98

• The product name of Windows®Me is Microsoft®Windows®Millennium Edition (Windows Me)

• The product names of Windows®2000 are as follows:

Microsoft®Windows®2000 Advanced Server

Microsoft®Windows®2000 Server

Microsoft®Windows®2000 Professional

• The product names of Windows®XP are as follows:

Microsoft®Windows®XP Professional

Microsoft®Windows®XP Home Edition

• The product names of Windows Server™ 2003 are as follows:

Microsoft®Windows Server™ 2003 Standard Edition

Microsoft®Windows Server™ 2003 Enterprise Edition

Microsoft®Windows Server™ 2003 Web Edition

• The product names of Windows®NT are as follows:

Microsoft®Windows NT®Server 4.0

Microsoft®Windows NT®Workstation 4.0

Microsoft®Windows NT®Workstation operating system Version 4.0

Notes:

Some illustrations in this manual might be slightly different from the machine.

Certain options might not be available in some countries. For details, please contact your local dealer.

TABLE OF CONTENTS

Manuals for This Machine.....................................................................................1

How to Read This Manual .....................................................................................3

1. Setting Up the Printer Driver and Canceling a Print Job

Accessing Printer Properties................................................................................5

Windows 95/98/Me - Accessing Printer Properties .................................................... 5

Windows 2000/XP - Accessing Printer Properties .....................................................6

Windows NT 4.0 - Accessing Printer Properties ........................................................ 7

Macintosh - Setting Up for Printing ............................................................................ 9

Canceling a Print Job ..........................................................................................10

Windows - Canceling a Print Job .............................................................................10

Macintosh - Canceling a Print Job ...........................................................................11

2. Using the Document Server

Accessing the Document Server........................................................................13

3. Sample Print/Locked Print

Sample Print ......................................................................................................... 15

Printing a Sample Print File......................................................................................15

Deleting a Sample Print File.....................................................................................17

Checking the Error Log ............................................................................................17

Locked Print .........................................................................................................19

Printing a Locked Print File ......................................................................................19

Deleting Locked Print Files ......................................................................................20

Checking the Error Log ............................................................................................21

Form Feed.............................................................................................................22

Print Using a Selected Tray .....................................................................................22

Canceling Form Feed...............................................................................................23

4. Troubleshooting

Error & Status Messages on the Display Panel ................................................25

The Machine Does Not Print ...............................................................................30

Other Printing Problems .....................................................................................34

5. Printer Features

Printer Features Menu .........................................................................................39

Adjusting Printer Features..................................................................................41

Printer Features Parameters...............................................................................42

Paper Input...............................................................................................................42

List/Test Print ...........................................................................................................42

Maintenance............................................................................................................. 45

System .....................................................................................................................46

Host Interface...........................................................................................................48

PCL Menu ................................................................................................................49

PS Menu ..................................................................................................................50

6. Appendix

Finisher.................................................................................................................51

Staple .................................................................................................................... 52

Staple Position .........................................................................................................52

Stapling Precautions ................................................................................................53

Collate ...................................................................................................................55

Spool Printing ......................................................................................................57

Covers...................................................................................................................59

Slip Sheets............................................................................................................61

Chaptering............................................................................................................63

User Defined Pages .............................................................................................65

System Settings (Parallel Connection) ..............................................................66

Specifications.......................................................................................................67

Options .....................................................................................................................68

INDEX......................................................................................................... 71

Manuals for This Machine

The following manuals describe the operational procedures of this machine. For

particular functions, see the relevant parts of the manual.

Note

❒Manuals provided are specific to machine type.

❒Adobe Acrobat Reader is necessary to view the manuals as a PDF file.

❒Two CD-ROMs are provided:

• CD-ROM 1“Operating Instructions for Printer/Scanner”

• CD-ROM 2“Scanner Driver & Document Management Utilities”

❖

❖❖

❖General Settings Guide

Provides an overview of the machine.

It also describes System Settings (such as paper trays and user codes settings),

Document Server functions, and troubleshooting.

❖

❖❖

❖Network Guide (PDF file - CD-ROM1)

Describes procedures for configuring the machine and computers in a net-

work environment.

❖

❖❖

❖Copy Reference

Describes operations, functions, and troubleshooting for the machine’s copier

function.

❖

❖❖

❖Facsimile Reference <Basic Features>

Describes operations, functions, and troubleshooting for the machine’s fac-

simile function.

❖

❖❖

❖Facsimile Reference<Advanced Features>

Describes advanced functions and settings for key operators.

❖

❖❖

❖Printer Reference 1

Describes system settings and operations for the machine’s printer function.

❖

❖❖

❖Printer Reference 2 (PDF file - CD-ROM1) (this manual)

Describes operations, functions, and troubleshooting for the machine’s print-

er function.

❖

❖❖

❖Scanner Reference (PDF file - CD-ROM1)

Describes operations, functions, and troubleshooting for the machine’s scan-

ner function.

❖

❖❖

❖Manuals for DeskTopBinder V2 Lite

DeskTopBinder V2 Lite is a utility included on the CD-ROM labeled “Scanner

Driver & Document Management Utilities”.

•DeskTopBinder V2 Lite Setup Guide (PDF file - CD-ROM2)

Describes installation of, and the operating environment for DeskTop-

Binder V2 Lite in detail. This guide can be displayed from the [Setup]dia-

log box when DeskTopBinder V2 Lite is installed.

•DeskTopBinder V2 Lite Introduction Guide (PDF file - CD-ROM2)

Describes operations of DeskTopBinder V2 Lite and provides an overview

of its functions. This guide is added to the [Start]menu when DeskTop-

Binder V2 Lite is installed.

•Auto Document Link Guide (PDF file - CD-ROM2)

Describes operations and functions of Auto Document Link installed with

DeskTopBinder V2 Lite. This guide is added to the [Start]menu when

DeskTopBinder V2 Lite is installed.

❖

❖❖

❖Manuals for ScanRouter V2 Lite

ScanRouter V2 Lite is a utility included on the CD-ROM labeled “Scanner

Driver & Document Management Utilities”.

•ScanRouter V2 Lite Setup Guide (PDF file - CD-ROM2)

Describes installation of, settings, and the operating environment for Scan-

Router V2 Lite in detail. This guide can be displayed from the [Setup]dia-

log box when ScanRouter V2 Lite is installed.

•ScanRouter V2 Lite Management Guide (PDF file - CD-ROM2)

Describes delivery server management and operations, and provides an

overview of ScanRouter V2 Lite functions. This guide is added to the [Start]

menu when ScanRouter V2 Lite is installed.

❖

❖❖

❖Other manuals

•PS3 Supplement (PDF file - CD-ROM1)

•UNIX Supplement (available from an authorized dealer, or as a PDF file on

our Web site)

How to Read This Manual

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation which, if instructions

are not followed, could result in death or serious injury.

CAUTION:

This symbol indicates a potentially hazardous situation which, if instructions

are not followed, may result in minor or moderate injury, or damage to proper-

ty.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might misfeed, originals might be dam-

aged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates prior knowledge or preparation is required before opera-

tion.

Note

This symbol indicates precautions for operation, or actions to take after mal-op-

eration.

Limitation

This symbol indicates numerical limits, functions that cannot be used together,

or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys and buttons that appear on the computer's display.

Keys that appear on the machine's display panel.

{}

Keys built into the machine's control panel.

Keys on the computer's keyboard.

1. Setting Up the Printer Driver

and Canceling a Print Job

Accessing Printer Properties

Windows 95/98/Me -

Accessing Printer Properties

Changing default settings

AOn the [Start]menu, point to [Set-

tings], and then click [Printers].

The [Printers]window appears.

BClick the icon of the machine

whose default you want to

change.

COn the [File]menu, click [Proper-

ties].

The printer properties dialog box

appears.

DMake the settings you require,

and then click [OK].

Note

❒With some applications, printer

driver settings are not used, and

the application's own settings

are applied.

Making settings from an application

To make settings for a specific appli-

cation, open the printer properties di-

alog box from that application. The

following example describes how to

make settings for the WordPad appli-

cation that comes with Windows

95/98/Me.

Note

❒Actual procedures for opening the

printer properties dialog box may

vary depending on the applica-

tion. For more information, see the

operating instructions that come

with the application you are using.

❒Any setting you make in the fol-

lowing procedure is valid for the

current application only:

AOn the [File]menu, click [Print].

The [Print]dialog box appears.

BIn the [Name]list, select the ma-

chine you want to use, and then

click [Properties].

The printer properties dialog box

appears.

CMake the settings you require,

and then click [OK].

DClick [OK]to start printing.

Setting Up the Printer Driver and Canceling a Print Job

Windows 2000/XP - Accessing

Printer Properties

Changing default settings - Printer

properties

Limitation

❒Changing machine settings re-

quires Manage Printers permis-

sion. Members of Administrators

and Power Users groups have

Manage Printers permission by de-

fault. When you set up options, log

on using an account that has Man-

age Printers permission.

AOn the [Start]menu, point to [Set-

tings], and then click [Printers].

The [Printers]window appears.

Note

❒In Windows XP Professional,

open the [Printers and Faxes]

window on the [Start]menu.

❒In Windows XP Home Edition,

open the [Printers and Faxes]

window by clicking [Control Pan-

el]from the [Start]button on the

taskbar, click [Printers and Other

Hardware], and then click [Print-

ers and Faxes].

BClick the icon of the machine

whose default you want to

change.

COn the [File]menu, click [Proper-

ties].

The printer properties dialog box

appears.

DMake the settings you require,

and then click [OK].

Note

❒Normally you do not have to

change the “Form to Tray As-

signment”settings on the [De-

vice Settings]tab in the

PostScript 3 printer driver.

❒Settings you make here are used

as default for all applications.

Changing default settings - Printing

preferences properties

Limitation

❒

Changing machine settings requires

Manage Printers permission. Mem-

bers of the Administrators and

Power Users groups have Manage

Printers permission by default.

When you set up options, log on us-

ing an account that has Manage

Printers permission.

AOn the [Start]menu, point to [Set-

tings], and then click [Printers].

The [Printers]window appears.

Note

❒In Windows XP Professional,

open the [Printers and Faxes]

window on the [Start]menu.

❒In Windows XP Home Edition,

open the [Printers and Faxes]

window by clicking [Control Pan-

el]from the [Start]button on the

taskbar, click [Printers and Other

Hardware], and then click [Print-

ers and Faxes].

BClick the icon of the machine

whose default you want to

change.

COn the [File]menu, click [Printing

Preferences...].

The [Printing Preferences]dialog box

appears.

Altri manuali per 2027

Indice

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente
