SC&T VE05AL Manuale utente

Smart Cabling & Transmission Corp. V1.0

VGA Extender

User Manual

Model : VE05AL

1 x 5 VGA & Stereo Audio Distribution Amplifier CAT5e

Extender, Transmiter

User Manual

VE05AL

Introduction

VE05AL is a VGA extender designed to use a cost-effective CAT5e UTP cable to carry the signal with

stereo audio signal and split the signals for 4 video & 4 audio outputs. Its RX unit has a built-in chainable

RJ45 output to connect another chainable RX for more working distance and VGA outputs. It's a optimal

solution used in Shopping malls, airports, train & bus stations, boardrooms, and tradeshows...etc.

Features

Extends and split a VGA into 5 ones.

Extends and splits a VGA into multiple ones.

Built-in equalization, gain adjustment, chainable CAT5 output at VE02ALR remote unit.

Resolution up to 1920x1200@60Hz.

Signal extension up to 300M over a CAT5e cable.

Build-in VGA loop-out for a local display.

Installation View

User Manual

VE05AL

Panel View

VE05ALT

VE02ALR

RJ45 Define

Link Cable (TIA/EIA-568-B)

1. Orange-white

Red +

2. Orange

Red -

3. Green-white

Green +

4. Blue

Audio -

5. Blue-white

Audio +

6. Green

Green -

7. Brown-white

Blue +

8. Brown

Blue –

VE02ALT/VE05ALT LED

Blue (front panel): power on/off

RJ45 LED (Link cable connector)

Green: status (Refer the below)

Yellow: status (Refer the below)

LED status indication

CH1 ~ CH4

Green on/off:

VGA Signal

Green flash:

EDID checksum error

Yellow on:

Use monitor DDC

Yellow off:

Use built in DDC

Yellow flash:

monitor EDID checksum Error

Yellow, Green, Blue all flash:

Memory error

User Manual

VE05AL

VE05ALT local unit EDID set up

Setup Monitor EDID:

When Yellow LED off, press “SETTING” button until Blue LED flash, then release

the “SETTTING” button, yellow LED will be on.

Setup Built in EDID:

When Yellow LED on, press “SETTING” button until Blue LED flash, then release

the “SETTTING” button, yellow LED will be off.

Reset factory default:

First to unplug the power, then press “SETTTING” button until reconnect

power and Blue LED flash.

Auto Backup EDID:

Change new monitor, it will start the monitor EDID backup.

VE02ALR Remote unit adjustment

equalization (sharpness)

Gain

signal boost (brightness)

VE02ALR LED

Blue (front panel): power on/off

RJ45 LED (Link cable connector)

Green: signal lock (LED on)

Caution

The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, radio

equipment, high voltage lines.

Installation Tips

Due to the inside of CAT5 cable that the pairs of wires are twisted at different rates, AND the different

quality on cable itself and installation that will cause different signal arrival time at each pair. If there

are big different at arrival time, that will cause RGB skew status. This is seen on the monitor as separation,

or lack of convergence in colors. Normally it happens on long CAT 5 cable runs.

User Manual

VE05AL

Recommend to use following cabling way to reduce skew status, to add special made “skew immunized

adaptor”, 2 pieces included at the package.

CAUTION

To avoid display equipment damaged, be sure to make correct cable connection and power for VE02ALT,

VE05ALT, and VE02ALR before connecting VE02ALT, VE05ALT, and VE02ALR.

Installation Cable

Video Link cable using hi quality CAT5E UTP/STP or CAT6 UTP cable.

Please noted STP cable could enhance noise rejection, but also less transmission range and picture

sharpness quality.

User Manual

VE05AL

Specification

ITEM NO.

VE05ALT

VE02ALR

Support

Compliance

TTL

Max. Video Resolution

1920 x 1200@60Hz

Max. Transmission Distance

300M over CAT5e or Greater

Video Bandwidth

700 MHz, -3dB (Remote 350MHz, -3dB)

150MHz

Audio Bandwidth

20 to 20KHz, -3dB

Frequency

Horizontal at 30 to 95KHz, Vertical at 50 to 180Hz

Ports & Interfaces

Video Input

1 x DB15 (75Ω, 0.7Vp-p)

1 x RJ45

Video Output

4 x RJ45

1 x DB15 (75Ω, 0.7Vp-p)

Video Loop-out

1 x DB15 (75Ω, 0.7Vp-p)

1 x RJ45

Audio Interface

2 x 3.5mm Stereo Phone Jack (10KΩ,

3Vp-p)

1 x 3.5mm Stereo Phone Jack (10KΩ, 3Vp-p)

Power

Power Supply

DC 12V 2A

Power Consumption

700mA (Max)

Ambient Temperature

Operation

0 to 55℃

Storage

-20 to 85℃

Humidity

up to 95%

Physical Characteristics

Dimensions

125 x 95 x 30mm

88 x 95 x 30mm

Weight

275g

205g
