SCIEX MSR 90 Manuale

SCIEX Dry Pump MSR 90

OPERATOR GUIDE

RUO-IDV-05-13982-A Original instructions

Disclaimer

This document is provided to customers who have purchased SCIEX equipment to use in

the operation of such SCIEX equipment. This document is copyright protected and any

reproduction of this document or any part of this document is strictly prohibited, except as

SCIEX may authorize in writing.

Software that may be described in this document is furnished under a license agreement. It

is against the law to copy, modify, or distribute the software on any medium, except as

specifically allowed in the license agreement. Furthermore, the license agreement may

prohibit the software from being disassembled, reverse engineered, or decompiled for any

purpose. Warranties are as stated therein.

Portions of this document may make reference to other manufacturers and/or their products,

which may contain parts whose names are registered as trademarks and/or function as

trademarks of their respective owners. Any such use is intended only to designate those

manufacturers' products as supplied by SCIEX for incorporation into its equipment and does

not imply any right and/or license to use or permit others to use such manufacturers' and/or

their product names as trademarks.

SCIEX warranties are limited to those express warranties provided at the time of sale or

license of its products and are the sole and exclusive representations, warranties, and

obligations of SCIEX. SCIEX makes no other warranty of any kind whatsoever, expressed or

implied, including without limitation, warranties of merchantability or fitness for a particular

purpose, whether arising from a statute or otherwise in law or from a course of dealing or

usage of trade, all of which are expressly disclaimed, and assumes no responsibility or

contingent liability, including indirect or consequential damages, for any use by the

purchaser or for any adverse circumstances arising therefrom.

Trademarks and/or registered trademarks mentioned herein, including associated logos, are

the property of AB Sciex Pte. Ltd., or their respective owners, in the United States and/or

certain other countries (see sciex.com/trademarks).

For Research Use Only. Not for use in Diagnostic Procedures

AB Sciex™ is being used under license.

Made in Czechia

Manufactured for:

AB Sciex LLC

500 Old Connecticut Path

Framingham, Massachusetts 01701

USA

Published: 1/23/2023

Contents

1. Safety and compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1. Definition of Warnings and Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2. Safety symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2. General description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.1. Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2. Control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.2.1. Auxiliary connector socket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3. Logic interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.4. Auto-run. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.5. Pump controller configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.6. Pump controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3. Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.1. Operating and storage conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.2. Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.3. Materials exposed to gases pumped. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.4. Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.1. Installation safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.2. Unpack and inspect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.3. Mechanical installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.4. Leak test the system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.5. Electrical installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.5.1. Connect the electrical supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.6. Connection for remote control and monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5. Commission the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

6. Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6.1. Operation safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6.2. Operational modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6.2.1. Manual control mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6.3. Logic interface data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

6.4. Parallel control and monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.5. Analogue speed control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

6.6. Hardware configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.7. Operational modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.8. Start the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.9. Shut down the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.10. Restart the pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6.11. Gas ballast adaptor fit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6.12. Gas ballast operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

7. Maintenance and service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

SCIEX Dry Pump MSR 90

Page 3 of 40

Operator Guide

RUO-IDV-05-13982-A

7.1. General maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.2. Maintenance plan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.3. Inspect and clean the inlet strainer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.4. Clean the external fan grill. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.5. Electrical safety check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

7.6. Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.6.1. Return the equipment or components for service (SCIEX). . . . . . . . . . . . . . . . . . . . 35

8. Fault finding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

8.1. Alarm indicator codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

9. Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

10. Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Operator Guide

RUO-IDV-05-13982-A

SCIEX Dry Pump MSR 90

Page 4 of 40

List of Figures

Figure 1: Pump features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 2: Control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Figure 3: Valve connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 4: Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 5: MSR 90 performance curve at 250 Hz. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 6: Speed vs Power graph. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 7: Logic interface connections - parallel control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Figure 8: Logic interface connections - analogue speed control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 9: Analogue speed control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 10: Gas ballast open-close. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

SCIEX Dry Pump MSR 90

Page 5 of 40

Operator Guide

RUO-IDV-05-13982-A

1. Safety and compliance

For safe operation from the start, read these instructions carefully before you install or

commission the equipment and keep them safe for future use. Read all the safety instructions

in this section and the rest of this manual carefully and make sure that you obey these

instructions.

The instruction manual is an important safety document that we often deliver digitally. It is

your responsibility to keep the instruction manual available and visible while working with the

equipment. Please download the digital version of the instruction manual for use on your

device or print it if a device will not be available.

1.1. Definition of Warnings and Cautions

For safe operation from the start, read these instructions carefully before you install or

commission the equipment and keep them safe for future use.

Read all the safety instructions in this section and the rest of this manual carefully and make

sure that you obey these instructions. The equipment must only be operated and maintained

by trained personnel in the proper condition and as described in this instruction manual.

Obey local and state requirements and regulations. If you have any questions about safety,

operation or maintenance of the device, please contact our nearest subsidiary.

Important safety information is highlighted as warning and caution instructions which are

defined as follows. Different symbols are used according to the type of hazard.

WARNING:

If you do not obey a warning, there is a risk of injury or death.

CAUTION:

If you do not obey a caution, there is a risk of damage to equipment, related equipment or

process.

NOTICE:

Information about properties or instructions for an action which, if ignored, will cause

damage to the equipment.

We reserve the right to change the design and the stated data. The illustrations are not

binding.

1.2. Safety symbols

The safety symbols on the products show the areas where care and attention is necessary.

The safety symbols that we use on the product or in the product documentation have the

following meanings:

Operator Guide

RUO-IDV-05-13982-A

SCIEX Dry Pump MSR 90

Page 6 of 40

Warning/Caution

An appropriate safety instruction must be followed or caution to a potential

hazard exists.

Warning - Heavy object

Identifies a possible hazard from a heavy object.

Warning - Dangerous voltage

Identifies possible hazards from hazardous voltages.

Warning - Protective earth (ground)

Earth point for electrical equipment.

WEEE symbol

The equipment must be discarded carefully. Obey local and national regula-

tions for disposal of this equipment.

Warning - Use protective equipment

Use appropriate protective equipment for the task.

SCIEX Dry Pump MSR 90

Page 7 of 40

Operator Guide

RUO-IDV-05-13982-A

2. General description

2.1. Overview

WARNING: INCORRECT USE OF EQUIPMENT

Risk of injury or damage to the equipment. Incorrect use of the equipment can cause

damage to the equipment or injury to people. The user is responsible for the safe operation,

installation and monitoring of the system.

CAUTION: GAS BALLAST INSTALLATION

Risk of damage to the equipment. If water vapour is present within the system or is pumped

by the product the gas ballast must be used to prevent damage to the product. The gas

ballast should continue to be applied with the pump running, for at least 1 hour after the

water vapour source has been removed to enable the pump to dry.

The MSR 90 is a dry, multi-stage roots vacuum pump that offers high pumping speed in a

compact form. The pump is connected by a power cord and is designed for use on clean duty

applications.

The cord rating is:

Supply voltage (V) Current (A) Frequency (Hz)

200 ‑ 240 7 50 or 60

The pump is not designed for use with flammable, corrosive, toxic or other hazardous gases.

Gas or oxygen can mix in the pump system.

The dry pump can be used in either transient or steady state gas load conditions. The pump

can sustain operation with a maximum continuous power consumption of 850 W. If the gas

load causes this value to be exceeded, then the pump will temporarily slow down. If the load

is subsequently reduced; or the transient overload protection has recovered, then the pump

will return to full speed operation. Refer to Table: Performance data for information on

maximum inlet pressure.

Refer to Figure: Pump features, the system is supplied with a NW40 inlet port (1) and a

NW25 exhaust port (10).

The pump mechanism is operated by an electric motor driven by an internal pump controller.

The rotational elements of the pumping mechanism are simply supported at the end by

lubricated bearings. PFPE lubricant is used and this is contained in both the gearbox and

motor ends of the pump module. These are "sealed for life" and the lubricant does not need

to be replaced until the pump service interval is reached.

The system is air cooled by a fan installed internally in the pump enclosure. The pump has a

thermal protection device that will stop the motor if a thermal overload occurs, for example in

high ambient temperatures. You must restart the pump after the pump is cooled down.

The pump is designed to pump the residual gases used in high vacuum systems. The gases

are:

▪Air

▪Oxygen (O2) < 21% by volume

▪Nitrogen

▪Krypton

▪Argon

Operator Guide

RUO-IDV-05-13982-A

SCIEX Dry Pump MSR 90

Page 8 of 40

▪Helium

You can use the pump to pump water vapour. You must use the gas ballast when water

vapour is pumped. The water vapour must not condense in the pump.

Note:

Make sure that the water vapour does not condense inside the pump.

To use the pump for a gas that is not listed, contact the supplier for advice. Failure to contact

the supplier can invalidate the warranty of the pump. Do not use the pump for aggressive or

corrosive gases.

Figure 1 Pump features

1. Inlet port 2. Control dashboard

3. Gas ballast 4. Vibration isolators

5. Castors x 2 6. 15-way D-type connector

7. Auxiliary connector 8. Mains circuit breaker

9. Mains connector port 10. Exhaust port

11. Protective earth stud 12. Lifting eye positions

1. Inlet port 2. Control dashboard

3. Gas ballast 4. Vibration isolators

5. Castors x 2 6. 15-way D-type connector

7. Auxiliary connector 8. Mains circuit breaker

9. Mains connector port 10. Exhaust port

11. Protective earth stud 12. Lifting eye positions

SCIEX Dry Pump MSR 90

Page 9 of 40

Operator Guide

RUO-IDV-05-13982-A

2.2. Control panel

Figure 2 Control panel

1. Start button 2. Sleep button*

3. Standby increase button 4. Standby decrease button

5. Alarm indicator LED 6. Service indicator LED

7. Auto‑run indicator LED 8. Standby decrease indicator LED

9. Standby increase indicator LED 10. Standby indicator LED

11. Run indicator LED 12. Stop button

13. Power status LED

1. Start button 2. Sleep button*

3. Standby increase button 4. Standby decrease button

5. Alarm indicator LED 6. Service indicator LED

7. Auto‑run indicator LED 8. Standby decrease indicator LED

9. Standby increase indicator LED 10. Standby indicator LED

11. Run indicator LED 12. Stop button

13. Power status LED

* Enables STANDBY functionality

2.2.1. Auxiliary connector socket

An auxiliary control connection on the rear panel controls an optional inlet valve. This inlet

valve can be operated in parallel with the normal pump output signal. Refer to Figure: Pump

features, (7). The valve is usually closed and:

▪will open when the normal signal becomes active (pump at speed)

▪will close when you select the stop button or if there is a fault condition

The reaction time will be in line with the valve selection and the output signal is 24 V d.c.

Refer to Figure: Valve connector for polarity of the connector pins when the connector is

energized.

The auxiliary connector is regulated to 24 V d.c. to control the accessories. If the auxiliary

load current exceeds the value in Table: Auxiliary load currents, the output will shut down to

protect the pump controller. Refer to Table: Recommended mating connector for the

recommended mating plugs.

Operator Guide

RUO-IDV-05-13982-A

SCIEX Dry Pump MSR 90

Page 10 of 40

Indice

Altri manuali SCIEX Pompa dell'acqua

SCIEX

SCIEX MSR 130 Manuale

Manuali Pompa dell'acqua popolari di altre marche

Neptun

Neptun NPHW 5500 Manuale utente

Sensidyne

Sensidyne Gilian BDX-II Istruzioni per l'installazione e il funzionamento

Draper

Draper 47808 Manuale utente

Trolla

Trolla 12820 Manuale utente

Sunfab

Sunfab SVH Series Manuale utente

WilTec

WilTec 50740 Manuale utente

Fieldmann

Fieldmann FVC 5015 EK Manuale utente

Everbilt

Everbilt EFSUB5-122HD Manuale utente

Graco

Graco Husky 3300e Manuale utente

esotec

esotec 101018 Manuale utente

moyno

moyno 2000 CC Manuale utente

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuale utente

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guida alla risoluzione dei problemi

DUROMAX

DUROMAX XP WX Series Manuale utente

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuale utente

Franklin Electric

Franklin Electric IPS Manuale utente

Xylem

Xylem e-1532 Series Manuale utente

Milton Roy

Milton Roy PRIMEROYAL Manuale utente
