USER MANUAL
Please read and keep these instrucons
HARD CANOPY
SE-HC
AUGUST 2019
scooterxtras.com.au
SCOOTER XTRAS owns the copyright to the Hard Canopy user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of Scooter Xtras.
SCOOTER XTRAS strives to provide the highest quality products possible.
Products are subject to change without noce.
© Copyright SCOOTER XTRAS 2019
SCOOTER XTRAS is part of FOR-DE Group Pty Ltd
scooterxtras.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS
4. ASSEMBLY - BAG / WALKER CARRIER LOCATION
5. ASSEMBLY - FRONT MOUNT KIT LOCATION
6. ASSEMBLY - FRONT MOUNT KIT LOCATION (Connued)
7. ASSEMBLY - LOWER WINDSCREEN LOCATION
8. ASSEMBLY - CANOPY PRE-ASSEMBLY
9. ASSEMBLY - CANOPY ON SCOOTER
10. USAGE GUIDELINES - DO’s + DON’Ts
11. PRODUCT CARE - INSPECTIONS / CLEANING
12. WARRANTY
13. SCOOTER XTRAS OPTIONAL EXTRAS
14. SCOOTER XTRAS WEATHER CURTAINS
15. SCOOTER XTRAS PRODUCT RANGE
16. NOTES
scooterxtras.com.au
INTRODUCTION
Thank you for purchasing this quality SCOOTER XTRAS product.
If you have any issues or quesons about the Hard Canopy
please contact your supplier or Scooter Xtras direct:
T: +61 8 9248 4180
F: +61 8 9248 9452
E: sales@for-de.com.au
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance to these guidelines.
Failure to follow these guidelines may result in damage to the product and injury
to the user. It is the responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate healthcare
professional if unsure of the correct product usage for their unique circumstances.
Only use your Hard Canopy for the purpose for which it is intended, which is as a
wind and sun shelter soluon - it is not designed to be a rain shelter soluon as
mobility scooters should not be operated in the rain.
IMPORTANT NOTE
This equipment MUST be assembled
by competent people. We recommend
that 2 people install the hard canopy
onto the mobility scooter.
Tools required (not supplied) for assembly:
- 4mm Allen Key
- 10mm Spanner
- Rubber Mallet
Using a mobility scooter ed with
a Hard Canopy in strong winds and
adverse weather can seriously
compromise your safety and may
damage the mobility scooter beyond
repair.
1.
scooterxtras.com.au
PRODUCT OVERVIEW
FEATURES
- Provides excellent wind + sun protecon
- Clear polycarbonate windscreens
- Lightweight metal framework
- Used in conjuncon with SE-BC: Bag Carrier
- Accessory mount brackets
(for rear vision mirrors / bole - mobile phone holders)
- Easily removable for servicing
- Retro able to certain Shoprider mobility scooters
Oponal Extras (Contact your supplier or Scooter Xtras direct)
- Retro able Clear PVC side + rear enclosure curtains
SPECIFICATIONS (All dimensions shown are nominal)
Overall Dimensions:
Length: 1300mm
Width: 720mm
Height: 1400mm
Product Weight:
8kg
IMPORTANT NOTE:
Hard Canopy can only be ed to the following Mobility Scooters:
SHOPRIDER ROCKY 4 (Mount Kit 1 required)
SHOPRIDER ROCKY 6 (Mount Kit 1 required)
SHOPRIDER ALLROUNDER (Mount Kit 2 required)
SHOPRIDER 889SL (Mount Kit 2 required)
SE-BC: Bag + Walking Scker Carrier or SE-WWC: Wheelie Walker Carrier is required
to t Hard Canopy to any mobility scooter.
Please contact SCOOTER XTRAS if you would like any further informaon
on your Hard Canopy.
2.
scooterxtras.com.au
ASSEMBLY- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
PARTS:
IMPORTANT NOTE
Check the product for any visible damage. If you see any damage or suspect a fault,
DO NOT USE YOUR PRODUCT and contact your supplier for support.
3.
Not included but required to t Hard Canopy to any mobility scooter:
SE-BC: Bag + Walking Scker Carrier or SE-WWC: Wheelie Walker Carrier / Relevant Mount Kit
1 x Canopy
1 x Upper Windscreen
1 x Rear Frame
1 x Lower Windscreen
2 x Short Bolt
2 x Long Bolt
4 x Bolt Cover 12 x Saddle Washer
*Fasteners not shown to scale
4 x Nut
MOUNT KIT 1
Suitable for:
SHOPRIDER ROCKY 4
SHOPRIDER ROCKY 6
MOUNT KIT 2
Suitable for
SHOPRIDER ALLROUNDER
SHOPRIDER 889SL
scooterxtras.com.au
4.
ASSEMBLY- BAG / WALKER CARRIER LOCATION
Before the Hard Canopy can be ed to a mobility scooter...
SE-BC: Bag + Walking Sck Carrier or SE-WWC: Wheelie Walker Carrier
must rst be ed. Assemble the carrier as required and then t to scooter.
Ensure the carrier is fully located into
the mount tube under the seat.
Lock the carrier in posion
by ghtening both bolts
unl the carrier is
rmly held in place. Carrier
to be
ed
Fully insert
Carrier
prior to
fastening
in place
Note:
Carrier shown as basic frame
for illustraon purposes
Ensure BOTH
Bolts are to be
ghtened prior
to ng Hard
Canopy
scooterxtras.com.au
5.
ASSEMBLY- FRONT MOUNT KIT LOCATION
Before the Hard Canopy can be ed to a mobility scooter, a front mount kit needs to be
ed. Please ensure you have been supplied with the correct mount kit for your mobility
scooter model:
SHOPRIDER ROCKY 4 (Mount Kit 1 required)
SHOPRIDER ROCKY 6 (Mount Kit 1 required)
SHOPRIDER ALLROUNDER (Mount Kit 2 required)
SHOPRIDER 889SL (Mount Kit 2 required)
Insert the outrigger into the mount tube located above the front tyres of the scooter and
underneath the cover. The uprights on ends of mounts to be posioned just o the cover
- ready to accept the front mount tube.
Mount Kit 1
Mount Kit 2
Secondary tube(s) on
outriggers sit on top of
sheet bracket
Outrigger
Outrigger
scooterxtras.com.au
6.
ASSEMBLY- FRONT MOUNT KIT LOCATION (Connued)
Once the outriggers have been ed to the scooter, the front mount tube can be located:
(refer to sequence stated and shown below):
1. Reposion the outriggers to line
up with front mount tube.
2. Locate the tube onto the uprights.
3. Feed the bolt cover and saddle
washer onto the short bolt,
4. Pass the short bolt through
the hole in the front mount
tube and the upright,
5. Feed saddle washer onto bolt
and screw on nut to hold
all in place.
6. Using an Allen Key and
Spanner, ghten fastener
assembly.
(Close lid on bolt cover)
Repeat process for other xing.
Mount Kit 1 shown
for illustraon purposes
Front Mount Tube
Short Bolt
Bolt Cover
Saddle Washer
Saddle Washer
Nut
scooterxtras.com.au
7.
ASSEMBLY- LOWER WINDSCREEN LOCATION
The lower windscreen fastens
onto the front mount tube
(refer to sequence stated and shown below):
1. Feed the bolt cover and saddle washer
onto the long bolt,
2. Pass the long bolt through the hole
in the lower windscreen frame,
3. Feed 2 x saddle washers onto the bolt
(back to back),
4. Pass the bolt through the hole in the
front mount tube,
5. Feed saddle washer onto bolt and
screw on nut to hold all in place.
6. Using an Allen Key and Spanner,
ghten fastener assembly.
(Close lid on bolt cover)
Repeat process for other xing.
Long Bolt
Bolt Cover
Saddle Washer
Saddle Washer
Saddle Washer
Saddle Washer
Long Bolt
Assembled
Lower Windscreen
