SCOTSMAN EUROPE - FRIMONT SPA
Via Puccini, 22 - 20010 Pogliano M.se - Milano - Italy
Tel. +39-02-93960.1 (Aut. Sel.)- Telefax +39-02-93550500
Direct Line to Service & Parts:
Phone +39-02-93960350 - Fax +39-02-93540449
Website: www.scotsman-ice.com
E-Mail: [email protected]
ISO 9001 - Cert. n. 0080
SERVICE MANUAL
MVP 456
MVP 606
MVP 806
MVP 1006
REV. 10/2008
Page 2
Page 2
TABLE OF
CONTENTS Page
Specifications 3 ÷10
Water 11
General Installation - Air or Water Cooled 11
Adjustments 13
Water purge setting 13
Prodigy Cuber System Information 14
Controller Information 14
How It Works 15
Electrical Sequence - Air or Water Cooled. 15
Electrical Component Details 16
Refrigeration 18
Water System 18
Control Operation 19
Control Safeties 19
Restarts 19
Control Button Use (from standby) 20
Service Specification 21
Diagnostics – Air Cooled 22-23
Test Procedures - Sensors 24
Ice Thickness Sensor 24
Water Level Sensor 24
Temperature Sensors 25
Test Procedures - Loads 25-28
Controller Differences 28
Wiring diagrams 29-30
Repair Procedures 31
Cleaning, sanitation and maintenance 32-33
INTRODUCTION
This technical manual covers the New Prodigy MVP line.
All models are shipped with an Installation and User’s manual, which can be referred to separately.
General installation information is included in this manual.
Page 3
Page 3
SPECIFICATIONS
MODULAR CUBER MVP 456
NOTE. TokeepyourModularcuberperformingat its maximum capacity, itis necessary to perform
periodic maintenance as outlined on last pages of this manual.
ice making capacity
ICE PRODUCED PER 24 HRS
Kg.
32 °C
15 10
AIR COOLED MODELS
WATER TEMPERATURE
AMBIENT TEMPERATURE
°C
10
21
32
38
WATER COOLED MODELS
21
240
220
200
180
160
140
120
ICE PRODUCED PER 24 HRS
Kg.
32 °C
15 10
AMBIENT TEMPERATURE
°C
10
21
32
38
21
255
235
215
195
175
155
135
WATER TEMPERATURE
Page 4
Page 4
SPECIFICATIONS (CONT'D)
Model Cond. unit Finish Comp. HP
MVP 456 - MACHINE SPECIFICATIONS
Water req.
lt/24 HR
Model Basic
electr. amps Start
amps watts Electric power cons.
Kwhx24 HR. N. of wires Amps
Fuse
220-240/50/1
MVP 456 - AS
MVP 456 - WS 3x1,5 mm216
Cubes per harvest: 234 Full - 468 Half
* With water at 15°C
Stainless Steel 7/8
4.5
4.0 29 1000
850 23
19.5
Dimensions:
HEIGHT 575 mm. (22" 1/2)
WIDTH 760 mm. (30")
DEPTH 620 mm. (24" 1/2)
WEIGHT 77 Kgs.
MVP 456 - AS Air 410*
MVP 456 - WS Water 2400*
Page 5
Page 5
SPECIFICATIONS
MODULAR CUBER MVP 606
NOTE. Tokeep your Modular cuber performingat its maximum capacity, itis necessary to perform
periodic maintenance as outlined on last pages of this manual.
ice making capacity
Kg.
32 °C
15 10
°C
10
21
32
38
21
335
315
295
275
255
235
215
195
175
Kg.
32 °C
15 10
°C
10
21
32
38
21
335
315
295
275
255
235
215
ICE PRODUCED PER 24 HRS
AIR COOLED MODELS
WATER TEMPERATURE
AMBIENT TEMPERATURE
WATER COOLED MODELS
ICE PRODUCED PER 24 HRS
AMBIENT TEMPERATURE
WATER TEMPERATURE
Page 6
Page 6
SPECIFICATIONS (CONT'D)
Model Cond. unit Finish Comp. HP
MVP 606 - MACHINE SPECIFICATIONS
Water req.
lt/24 HR
Model Basic
electr. amps Start
amps watts Electric power cons.
Kwhx24 HR. N. of wires Amps
Fuse
220-240/50/1
MVP 606 - AS
MVP 606 - WS 3x1,5 mm216
Cubes per harvest: 234 Full - 468 Half
* With water at 15°C
Stainless Steel 1 3/8 1 1/2
6,2
5,2 32 1300
1050 28
23
Dimensions:
HEIGHT 575 mm. (22" 1/2)
WIDTH 760 mm. (30")
DEPTH 620 mm. (24" 1/2)
WEIGHT 77 Kgs.
MVP 606 - AS Air 440*
MVP 606 - WS Water 2750*
Page 7
Page 7
SPECIFICATIONS
MODULAR CUBER MVP 806
NOTE.To keep your Modularcuber performing at its maximumcapacity, it is necessary toperform
periodic maintenance as outlined on the last pages of this manual.
ice making capacity
Kg.
32 °C
15 10
°C
10
21
32
38
21
445
425
405
385
365
345
325
305
285
265
245
225
Kg.
32 °C
15 10
°C
10
21
32
38
21
390
370
350
330
310
290
270
ICE PRODUCED PER 24 HRS
AIR COOLED MODELS
WATER TEMPERATURE
AMBIENT TEMPERATURE
WATER COOLED MODELS
ICE PRODUCED PER 24 HRS
AMBIENT TEMPERATURE
WATER TEMPERATURE
Page 8
Page 8
MVP 806 - AS Air 580*
MVP 806 - WS Water 3900*
SPECIFICATIONS (CONT'D)
Model Cond. unit Finish Comp. HP
MVP 806 - MACHINE SPECIFICATIONS
Water req.
lt/24 HR
Model Basic
electr. amps Start
amps watts Electric power cons.
Kwhx24 HR. N. of wires Amps
Fuse
MVP 806 - AS
MVP 806 - WS 3x1,5 mm216
Cubes per harvest: 342 Full - 684 Half
* With water at 15°C
Stainless Steel 1 5/8 2.5
231 1850
1450 40
33.4
Dimensions:
HEIGHT 725 mm. (28" 1/2)
WIDTH 760 mm. (30")
DEPTH 620 mm. (24" 1/2)
WEIGHT 97 Kgs.
220-240/50/1
9.0
8.0
Page 9
Page 9
SPECIFICATIONS
MODULAR CUBER MVP 1006
NOTE. Tokeep your Modular cuber performingat its maximum capacity, itis necessary to perform
periodic maintenance as outlined on the last pages of this manual.
ice making capacity
Kg.
32 °C
15 10
°C
10
21
32
38
21
475
455
435
415
395
375
355
335
315
295
275
Kg.
32 °C
15 10
°C
10
21
32
38
21
425
405
385
365
345
325
305
ICE PRODUCED PER 24 HRS
AIR COOLED MODELS
WATER TEMPERATURE
AMBIENT TEMPERATURE
WATER COOLED MODELS
ICE PRODUCED PER 24 HRS
AMBIENT TEMPERATURE
WATER TEMPERATURE
Page 10
Page 10
MVP 1006 - AS Air 600*
MVP 1006 - WS Water 3800*
SPECIFICATIONS (CONT'D)
Model Cond. unit Finish Comp. HP
MVP 1006 - MACHINE SPECIFICATIONS
Water req.
lt/24 HR
Model Basic
electr. amps Start
amps watts Electric power cons.
Kwhx24 HR. N. of wires Amps
Fuse
MVP 1006 - AS
MVP 1006 - WS 5x1,5 mm210
Cubes per harvest: 342 Full - 684 Half
* With water at 15°C
224 1900
1600 41.3
37
Dimensions:
HEIGHT 725 mm. (28" 1/2)
WIDTH 760 mm. (30")
DEPTH 620 mm. (24" 1/2)
WEIGHT 104 Kgs.
380-400/50/3
Stainless Steel 2
3.5
3.3
