Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding. 4
1. General Information
1.3. Environment
This equipment is tted with a pair of lead
acid batteries which contain a corrosive gel.
These batteries must be regularly inspected
for damage and condition. Lead acid batteries
are classied as hazardous waste and must
be disposed by an authorised and licensed
recycler. They must not be disposed of in
household waste or ‘general waste’ skips.
Redundant electronic products are classied as
hazardous waste under the WEEE regulations
(Waste Electrical and Electronic Equipment).
Electronic parts must be disposed by an authorised
and licensed recycler. They must not be disposed
of in household waste or ‘general waste’ skips.
If recycling facilities are not locally available,
contact SE Controls who can arrange for recycling
and disposal of old electronic products.
1.4. User Responsibilities
United Kingdom Only: BS 7346-8:2013 is
a British Standard code of practice for the
planning, design, installation, commissioning and
maintenance of smoke control systems. Section
9 of the standard (Maintenance and Servicing)
states that frequent inspection of the system
should be undertaken by a named suitably-trained
member of the premises management team.
Routine inspection of the system should be carried
out in accordance with BS 9999:2008, Annex V.
For countries outside the United Kingdom:
Please check with the local the re authority in
your area regarding smoke control legislation,
dierent user responsibilities may apply.
Smoke control equipment should only be
maintained by a competent person with specialist
knowledge of smoke control systems and
sucient information regarding the system.
1.1. General Safety Information
Read and observe the information
contained in these instructions.
Please keep these safety instructions for
future reference and maintenance. Reliable
operation and the prevention of damage
and risks are only granted if the equipment
is assembled carefully and the settings are
carried out according to these instructions and
to the operating instructions of the drives.
Please observe the exact terminal assignment,
the minimum and maximum power ratings (see
technical data) and the installation instructions.
1.2. Health and Safety
Electrical Safety: Warning 230 V AC mains supply
can cause death, serious injury or considerable
material damage. Disconnect the equipment
from the power supply at all poles before
opening, assembling or carrying out any work.
Electrical safety of batteries: Short circuiting
of the lead acid batteries can cause high
currents to ow which can cause rapid heating
and a re risk. Take care to avoid this when
transporting and handling batteries. Keep
batteries disconnected during installation
and modication of the installation.
Competence: This equipment is designed for
professional installation only by qualied, trained
and safety conscious electricians or skilled and
trained sta with considerable knowledge of
electrical equipment installation. These instructions
must be followed and retained for future reference.
Application: this equipment is designed
exclusively for the purposes of controlling
automatically opening smoke and
environmental ventilation equipment.
Personal Protective Equipment: It is
recommended that suitable PPE is worn at all
times during the installation and connection
of actuator products in accordance with a
recommended safe system of work.
Handling and storage: This equipment is
heavy. Care must be taken in transportation to
the installation location and during tting. The
equipment must not be dropped, impacted,
allowed to get wet or abused in any other way.
Mishandling can result in serious damage to
the housing and the components therein.
Risk of crushing: this equipment can
automatically close windows and other appliances
without warning. Beware risk of serious
injury from crushing of hands or ngers.
