Instructions:
Dimension Drawings:
70.0mm
110.0mm
132.0mm
46.0mm
26.0mm
Ø19/25mm
Ø28.5mm
31.5mm
31.5mm
3
page
Accessories:
Optional Angle Fitting
Standard Stright Fitting
Rotation Function
360°
13C/13D/13E Pump Body
Rotation Function
360°
Split quick-connect joint
design no need to disconnect
base or plumbing when
replacing pump.
Explaination:
1.The fittings are designed as a split quick connect joint, which adopts the split design of lock nut. This solution can
quickly disassemble and replace the fitting without dismantling the water pipe which can meet the needs of most
users. The lock nut is universal.1-1/8”29mm 90º fitting sold separately with 360° rotation function to meet any
angle requirement.
2.Pump Body 360° rotation function only availbale for 13C/13D/13E.
User safety:
! DANGER: This product is not intended for damage control or to deal with flooding resulting from hull damage. This
product is intended to be used in Bilge Pumping Systems for small craft with a hull length up to 24 meters. Bilge
Pumping Systems are limited to normal amounts of water in an intact boat due to spray, rain, seepage, spillage, and
occasional small amounts of water shipped from boat movements in heavy weather. Use of product in any other way
could result in flooding, catastrophic damage to craft, serious personal injury, or death.
General safety rules. These are safety rules that apply:
Always keep work area clean
Pay attention to the risks presented by gas and vapors in the work area
Avoid all electrical dangers. Pay attention to the risks of electric shock or arc flash hazards
Always bear in mind the risk of drowning, electrical accidents and burn injuries
! WARNING: This pump is designed for use with fresh water and salt water ONLY. Use with any other hazardous,
caustic, or corrosive material could result in damage to the pump and the surrounding environment, possible exposure
to hazardous substances and injury.
2
page
13A/13B 600-800-1100GPH
1"(25mm) or
1-1/8"(29mm)
1-1/8"(29mm)
Suitable for 600-800-1100-1500-2000GPH Only
13A/B/C/D/E 600-800-1100GPH
Straight Fitting
1-1/8"(29mm)
Elbow Fitting
1-1/8"(29mm)
13A/B 1500-2000GPH 13A 3000-3700-4700GPH
Straight Fitting
1-1/2"(40mm)
Straight Fitting
2"(52mm)
44.5mm
Ø84.6mm Ø4.8mm
4-
44.5mm
145mm
140mm
145mm
33mm
Ø28.5mm
140mm
85mm
13A/13B 1500-2000GPH
192mm
187mm
40mm
52mm
120mm
187mm
81.4mm
81.4mm
120mm 4- 5.4mm
13A 3000-3700-4700GPH
